Summary of Contents for Lexicon RV-8

  • Page 1: Service Manual

    RV-8 Receiver Service Manual Harman Specialty Group 3 Oak Park, Bedford, MA, 01730-1413 USA Customer Service: Telephone: 781-280-0300 | Service Fax: 781-280-0499 | www.lexicon.com Part No. 070-17537 | Rev 0...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS 1. Read and keep these instructions. 2. Heed all warnings. 3. Follow all operation instructions. 4. Do not use this apparatus near water. 5. Clean only with a dry cloth. 6. Do not block any ventilation openings. 7.

  • Page 3: Safety Summary

    SAFETY SUMMARY The following general safety precautions must be observed during all phases of operation, service, and repair of this unit. Failure to comply with these precautions or with specific warnings elsewhere in these instructions violates manufacturer safety standards and intended use of this unit. Harman Specialty Group assumes no liability for failure to comply with these requirements.
  • Page 4 Bedford, MA 01730-1413 USA performing any service. Telephone: 781-280-0300 Fax: 781-280-0490 www.lexicon.com “Lexicon” and the Lexicon logo are registered trademarks of Harman International Industries, Incorporated. Customer Service Telephone: 781-280-0300 U.S. patent numbers and other worldwide patents issued Sales Fax: 781-280-0495 and pending.

  • Page 5: Table Of Contents

    CHAPTER 6 – THEORY OF OPERATION .............6-1 RV-8 Amplifier Theory ....................... 6-1 RV-8 Analog Board Theory ....................6-4 RV-8 Main Board Theory....................6-9 RV-8 Phono/Microphone Input Board Theory ..............6-47 RV-8 Tuner Board Theory ....................6-48 RV-8 Video System Theory ..................... 6-50...
  • Page 6 CHAPTER 7 – PARTS LIST ..................... 7-1 Main Board Assembly ......................7-1 VCO Masterclock Board Assembly..................7-3 Microphone/Preamplifier Board Assembly................7-4 Tuner Board Assembly ......................7-4 IR/Encoder Board Assembly....................7-5 Switch/LED Board Assembly ....................7-5 Headphone Board Assembly ....................7-6 Analog Input/Output Board Assembly...................
  • Page 7 ASSEMBLY DRAWINGS 080-14834 PC,ASSY DWG,MECH VCO 080-15508 PC,ASSY DWG,VIDEO IN BD 080-15518 PC,ASSY DWG,VIDEO OUT BD 080-15528 PC,ASSY DWG,MIC/PREAMP BD 080-15538 PC,ASSY DWG,HEADPHONE BD 080-15548 PC,ASSY DWG,TUNER BD 080-15558 PC,ASSY DWG,MAIN BD 080-15568 PC,ASSY DWG,SW/LED BD 080-15578 PC,ASSY DWG,ANLG I/O BD 080-15588 PC,ASSY DWG,VIDEO BD 080-16158...

  • Page 9: Chapter 1 - Reference Document & Equipment Lists

    CD disc for a test audio source • DVD disc for a test video source • DAT recorder with digital coaxial and optical record inputs, for testing the digital output of the RV-8 • A pair of stereo headphones •...
  • Page 10 • 2 Video cables with S-Video connectors on both ends • 2 Video cables with 3-wire component RCA connectors on both ends • RV-8 AC power cord • RV-8 remote control. Required Tools • Clean, antistatic, well lit work area with grounding wrist strap •...

  • Page 11: Chapter 2 - General Information

    Return Authorization. No equipment will be accepted without Return Authorization from HSG/Lexicon. If HSG/Lexicon recommends that a RV-8 be returned for repair and you choose to return the unit to HSG/Lexicon for service, HSG/Lexicon assumes no responsibility for the unit in shipment from the customer to the factory, whether the unit is in or out of warranty.
  • Page 12 RV-8 Service Manual Please enclose a brief note describing any conversations with HSG/Lexicon personnel (indicate the name of the person at HSG/Lexicon) and give the name and daytime telephone number of the person directly responsible for maintaining the unit. Do not include accessories such as manuals, cables, remote control, etc. with the unit, unless specifically...

  • Page 13: Chapter 3 - Specifications

    Lexicon CHAPTER 3 – SPECIFICATIONS Audio Input and Output Connectors Analog Audio Inputs 8 stereo (RCA) or 5 stereo and one 5.1-channel or 2 stereo and two 5.1-channel connectors Digital Audio Inputs 4 S/PDIF coaxial (RCA) and 4 S/PDIF optical connectors; coaxial and...
  • Page 14 RV-8 Service Manual Preamp Output Level 150mVrms typical, 6Vrms maximum (RCA connectors) Maximum value with full-scale input signal and volume at +12dB Preamp Output Impedance 500Ω in parallel with 150pF (RCA connectors) * Combined measurements of preamplifier and power amplifier sections Zone 2 and Zone 3 Audio Performance 24-bit, 44.1 to 96kHz, multi-bit ∆Σ...
  • Page 15 Lexicon Input Return Loss >40dB Differential Gain <0.5% Differential Phase <0.5° Bandwidth >25MHz K Factor <0.3% Gain ±0.15dB Signal-to-Noise Ratio >65dB Frequency Response 10Hz to 10MHz + 0.1/-0.3dB Component Video Performance Compatibility 3-Channel (Y/Pb/Pr), format-independent Switching Passive Impedance 75Ω Bandwidth >150MHz...
  • Page 16 RV-8 Service Manual Rack Mounting Optional brackets are available for installation in a standard 19-inch equipment rack (4 rack units required) Environment Operating Temp: 0° to 35°C (32° to 95°F) Storage Temp: -30° to 75°C (-22° to 167°F) Relative Humidity: 95% maximum without condensation Remote Control Hand-held, backlit infrared remote control unit, preprogrammed &...
  • Page 17 Lexicon Phono Performance (MM) Frequency Response 50Hz to 20kHz, ±0.5dB, rumble filter -4dB at 10Hz THD + Noise Below 0.02%, 20Hz to 20kHz, 4.7mV input Signal-to-Noise Ratio 72dB minimum Compatible Amplifier Connectors Banana Plugs Standard 0.75 inch plugs Spade Connectors...
  • Page 18 RV-8 Service Manual...

  • Page 19: Chapter 4 - Functional Verification

    J14=220VAC, J15=120VAC. 7. Put the cover back on. 8. Connect the AC cord. Using the main power switch on the back of the RV-8, verify that the unit runs through its Power On Diagnostics. 9. Check each of the front panel switches for smooth mechanical operation. Verify each LED turns on and off when the associated switch is depressed, and that the display acknowledges each switch function.
  • Page 20 These tests will verify that the High Current Power Supply operates properly. Setup: 1. Set the rear panel power switch of the RV-8 to the “0” (OFF) position. 2. Disconnect the AC Line cord from the unit. 3. Plug the transformer primary wiring harness into the connector J15 “120VAC” on the Power Supply Board to the left of the transformer.
  • Page 21 Setup: 1. Set the rear panel power switch of the RV-8 to the “0” (OFF) position. 2. Connect one end of the AC power cord to the RV-8 and the other end to the Variac. 3. Power on the Variac.
  • Page 22 Whenever the RV-8 covers are removed, the amplifier channels carry a lethal voltage. Stay clear of them when testing the inside of the RV-8. When replacing the channels, it is important to discharge them before removing them from the chassis. Follow the safety and handling procedures below when service is required inside the RV-8.
  • Page 23 1. Disconnect power. 2. Wait ten minutes. 3. Remove the top cover of the RV-8. 4. With the RV-8 facing you, locate the switching power supply mounted vertically on the left side of the chassis. 5. Power on the unit.
  • Page 24 4. Press the remote control MAIN soft button. Press the remote TUNER soft button. 6. The RV-8’s display will display “Tuner” in the upper left, and the AM or FM radio station it is tuned to in the upper right.
  • Page 25 Lexicon Trigger Test This test will verify the trigger circuits of the RV-8. For this test you will need the RV-8 remote control and a Digital Multimeter (DMM). Test: 1. Power on the RV-8. 2. Turn on the DMM and set it to read DC voltage for a 12V level.

  • Page 26: Functional Audio I/O Tests

    RCA Zone 2 output. Setup: 1. Connect the video monitor to the main composite output of the RV-8 and turn the monitor on. This will allow full viewing of the of the RV-8’s menus. 2. Connect the RCA left and right outputs labeled “Fix” from Zone 2 to an external amplifier.
  • Page 27 8. Connect the oscillator output to the left and right audio inputs labeled 1 on the rear panel of the RV-8. 9. Confirm DVD 1 is selected in the Main Zone as well as the Zone 3 section of the front panel.
  • Page 28 12. Connect the oscillator output to the left and right audio inputs labeled 1 on the rear panel of the RV-8. 13. Confirm DVD 1 is selected in the Main Zone as well as the Zone 2 section of the front panel.
  • Page 29 13. Place the DAT machine into Record mode. 14. Power on the external amplifier. 15. Insert a disc into the DVD or CD player and press Play. Slowly increase the volume on the RV-8 to a comfortable listening level. 16. Verify that clean, undistorted audio can be heard.
  • Page 30 6 to the next appropriate input. 19. To test the S/PDIF Optical I/O, use the S/PDIF optical output on the RV-8 to the S/PDIF optical input of the DAT player. Repeat steps 1-18 to test S/PDIF optical Inputs 1 through 4. Change the DVD1 DIGITAL IN selected in step 6 from COAX to Optical and use the appropriate digital cable.
  • Page 31 Setup: 1. Connect the video monitor to the main composite output of the RV-8 and turn the monitor on. This will allow full viewing of the RV-8’s menus. 2. Connect the S/PDIF coaxial digital output on the RV-8 rear panel to the digital record input jack of the DAT machine.
  • Page 32 7. Press the Menu arrow button five times to exit the setup menus. 8. Insert a disc into the DVD or CD player and press Play. Slowly increase the volume on the RV-8 to a comfortable listening level. 9. Verify that clean, undistorted audio can be heard.
  • Page 33 4. In the AUDIO I/O TEST menu, highlight AUDIO INPUT 1 TEST. Press the Menu arrow to engage the test. The RV-8 is now set to route audio from the left and right analog inputs labeled 1 to all Main Zone outputs.
  • Page 34 4. In the AUDIO I/O TESTS menu, highlight AUDIO PHONO TEST. Press the remote control Menu arrow to engage the test. The RV-8 is now set to route audio from the Phono left and right inputs to all Main Zone outputs.
  • Page 35 1. Connect the S/PDIF coaxial digital output of the CD player to the S/PDIF coaxial digital input 1 on the RV-8 rear panel. 2. Connect the Zone 2 RCA left and right Fixed outputs of the RV-8 to the external amplifier left and right inputs.
  • Page 36 RV-8 Service Manual Digital Inputs To Zone 3 Outputs Test This test will verify the audio path between the RV-8 S/PDIF coaxial digital input 1 to the Zone 3 RCA analog outputs. Note: This test requires the use of a CD player as a source. The tests to follow will be run using a PCM signal at a 44.1kHz sample rate.

  • Page 37: Audio Performance Verification

    1. Connect an audio cable between the output of the Low Distortion Oscillator and the RV-8 left RCA input 1. 2. Connect an audio cable between the front left RCA output of the RV-8 and the input of the Distortion Analyzer.
  • Page 38 4. In the AUDIO I/O TEST menu, highlight AUDIO INPUT 1 TEST. Press the Menu arrow on the RV-8 remote control to engage the test. The RV-8 is now set to route audio from the left and right RCA inputs labeled 1 to all amplifier outputs.
  • Page 39 4. In the AUDIO I/O TEST menu, highlight S/PDIF INPUT OP1 TEST. Press the Menu arrow to engage the test. The RV-8 is now set to route audio from the left and right RCA inputs labeled 1 to all RCA analog outputs.

  • Page 40: Video Input/Output Tests

    1. Connect the composite video output from the DVD player to the RV-8’s composite video input 1. 2. Connect the first main composite output of the RV-8 to the composite input of the video monitor. 3. Turn on the DVD player, monitor, and the RV-8.
  • Page 41 3. Turn on the DVD player, monitor, and the RV-8. 4. The monitor should display a blue screen. 5. On the RV-8 remote control, press the MAIN button, then press the DVD1 button to select DVD1 as the input for testing the video paths.
  • Page 42 3. Turn on the DVD player, monitor, and the RV-8. 4. The monitor should display a blue screen. 5. On the RV-8 remote control, press the MAIN button, then press the DVD1 button to select DVD1 as the input for testing the video paths.
  • Page 43 3. Turn on the DVD player, monitor, and the RV-8. 4. The monitor should display a blue screen. 5. On the RV-8 remote control, press the MAIN button, then press the DVD1 button to select DVD1 as the input for testing the video paths.
  • Page 44 3. Turn on the DVD player, monitor, and the RV-8. 4. The monitor should display a blue screen. 5. On the RV-8 remote control, press the MAIN button, then press the DVD1 button to select DVD1 as the input for testing the video paths.
  • Page 45 VIDEO parameter and press the Menu arrow to select it. This will set the RV-8 to up-convert composite and S-video inputs to component video. 18. Press the Menu arrow three times to exit to the SETUP menu.
  • Page 46 RV-8 Service Manual Note: During this procedure all tests are performed with NO INPUT SIGNAL applied to the amplifier inputs and with NO RESISTIVE LOAD connected to the amplifier outputs. Bias Adjustment On The 4 Channel Module: Channel # 1 1.

  • Page 47: Lexicon Audio Precision Ate Summary

    This chart represents a summary of Audio Precision test settings and parameters used by Lexicon in production testing of all RV-8 products. The ATE chart and ATE summary are provided as a reference and supplement of bench test settings found in the rest of the Performance Verification chapter. The Audio ATE Test Chart is located on the next page.
  • Page 48 TEST PROC, ATE, RV8 RV8 AUDIO ATE TEST SUMMARY 010-15834 A-D Tests Analog Generator Digital Analyzer Switcher Module Bal/ Gnd/ Typical Upper Lower Clock Sample Audio Test Name Note: Left Right Freq (Hz) EQ Curve Z-out Unbal Float Level Measure Reading Limit Limit...
  • Page 49 TEST PROC, ATE, RV8 RV8 AUDIO ATE TEST SUMMARY 010-15834 A-D Tests Analog Generator Digital Analyzer Switcher Module Bal/ Gnd/ Typical Upper Lower Clock Sample Audio Test Name Note: Left Right Freq (Hz) EQ Curve Z-out Unbal Float Level Measure Reading Limit Limit...
  • Page 50 TEST PROC, ATE, RV8 RV8 AUDIO ATE TEST SUMMARY 010-15834 D-A Tests Digital Generator Analog Analyzer Switcher Module Bal/ Gnd/ Typical Upper Lower Clock Sample Audio Test Name Note: Left Right Freq (Hz) EQ Curve Z-out Unbal Float Level Measure Reading Limit Limit...
  • Page 51 TEST PROC, ATE, RV8 RV8 AUDIO ATE TEST SUMMARY 010-15834 A-A Tests Analog Generator Analog Analyzer Switcher Module Bal/ Gnd/ Typical Upper Lower Clock Sample Audio Test Name Note: Left Right Freq (Hz) EQ Curve Z-out Unbal Float Level Measure Reading Limit Limit...
  • Page 52 TEST PROC, ATE, RV8 RV8 AUDIO ATE TEST SUMMARY 010-15834 A-A Tests Analog Generator Analog Analyzer Switcher Module Bal/ Gnd/ Typical Upper Lower Clock Sample Audio Test Name Note: Left Right Freq (Hz) EQ Curve Z-out Unbal Float Level Measure Reading Limit Limit...
  • Page 53 TEST PROC, ATE, RV8 RV8 AUDIO ATE TEST SUMMARY 010-15834 A-A Amplifier Tests Analog Generator Analog Analyzer Switcher Module Bal/ Gnd/ Typical Upper Lower Clock Sample Audio Test Name Note: Left Right Freq (Hz) EQ Curve Z-out Unbal Float Level Measure Reading Limit...

  • Page 55: Chapter 5 - Troubleshooting

    (SYSTEM) OFF button will put the unit into a low power/standby mode. When the RV-8 is in standby mode, pressing any of the front panel or remote control Main, Zone 2 or Zone 3 input select buttons, and/or pressing the front panel standby button or the remote control POWER button will bring the RV-8 out of standby mode.

  • Page 56: Diagnostic Reporting

    Diagnostic status and data is also available on an external PC or a terminal, via the serial debug port located at the D9 connector labeled RS 232 on the rear panel of the RV-8. In the event a diagnostic failure occurs for those diagnostic tests that report additional failure information, such as data sent, data received, address location, etc., can be viewed on the VFD display, or it can be sent to the serial debug...
  • Page 57 The cable required to connect the RS232 serial debug port to the computer is a straight-through serial interface cable. A null modem adapter or cable should not be used. The RV-8 RS232 connector on the rear panel is a D9 female; so one end of the serial cable must be a D9 male. The other connector on the cable depends upon the RS232 connector used on the computer.
  • Page 58 RV-8 Service Manual VFD_RAM_ERROR TEST_INCOMPLETE RS232_WRAP_FAILURE SRAM_PREBURNIN_FAILURE 0x13 SRAM_BURN_IN_FAILURE 0x14 EPROM_CHKSUM_FROM_FLASH 0x15 DRAM_FAILURE 0x16 FIFO_ERROR_OVERRUN 0x17 PIC_SN_INVALID 0x18 FLASH_BURN_FAIL 0x19 FLASH_BURN_NO_ROOM_LEFT 0x1A FLASH_BURN_NOT_FLASH_PART 0x1B SHARC_TIMEOUT_REBOOT 0x1C DSP_FPGA_ID_NO_MATCH 0x1D DEC_FPGA_ID_NO_MATCH 0x1E DIAG_TEST_NOT_EXIST 0x20 THERMOSTAT_FAILURE 0x21 EXPANSION_BRD_FAILURE 0x22 ERROR_ID_BAD_VALUE 0x40 ERROR_PARAM_SEMA_CREATE 0x60...
  • Page 59 Lexicon CS49400_CHECKSUM_FAIL 0x11B CS8420_INIT_ERROR 0x200 CS8420_ISC_WR_TIMEOUT 0x201 CS8420_ISC_RD_TIMEOUT 0x202 CS8420_WRONG_VERSION 0x203 CS8420_WRONG_ID 0x204 These codes are used to interpret the diagnostic results from the Extended Diagnostic Repair Menu. The Error code is 16-bits with the most significant byte always being 0x03.

  • Page 60: Power On Diagnostics

    The actual value (in hexadecimal) that was read from the address where the failure occurred. POWER ON DIAGNOSTICS As described earlier there are two power-on modes in the RV-8. You can power on via the rear panel power switch or by bringing the RV-8 out of standby mode. Power-on diagnostics are executed every time the rear panel power switch is switched on.
  • Page 61 The dots increment in number from both sides simultaneously, as the rest of the power-on diagnostic tests are completed. This keeps you informed as to the functioning of the RV-8. If a failure occurs, the test will attempt to enter a loop to exercise signal lines to aid in debugging.

  • Page 62: Extended Diagnostics Tests

    These tests are referred to as Repair diagnostics. Two groups of tests are executed for every RV-8. These are the Loop Tests and the Functional Test Suite. The Loop Tests and the Functional suite comprise the automated sets of tests used to verify proper operation of every unit.
  • Page 63 Lexicon being executed. Pressing and holding the Mode button returns the user to the top-level diagnostic menu. Repair Diagnostics Suite The repair tests suite is the section where every diagnostic test can be executed individually. Additionally, the repair test suite allows you to run any single diagnostic test infinitely. The encoder knob is used to scroll through each diagnostic test.
  • Page 64 RV-8 Service Manual OSD CHAR TEST PAGE: (0-11) SWITCH TEST LED TEST ENCODER TEST SET TRIGGERS TRIGGER 0 TRIGGER: OFF/ON TRIGGER 1 TRIGGER: OFF/ON AMP RELAY TESTS MAIN RELAY RELAY: OFF/ON CHANNEL 1 RELAY: OFF/ON CHANNEL 2 RELAY: OFF/ON CHANNEL 3...

  • Page 65: Functional Diagnostic Descriptions

    1. Verify the three LEDS at the right side of the VFD display light: RED, AMBER and BLUE. 2. In approximately three seconds, verify the display indicates: “**LEXICON **” 3. When the “** LEXICON **” display appears, within eight seconds press and hold the Zone 2 DVD2 and Zone 3 DVD2 buttons.
  • Page 66 1. Create two (2) RS 232 wrap around plugs by connecting pins 2 & 3 of a female DB9 connector. 2. Install the two RS 232 wrap around plugs onto the RS 232 1 and 2 ports located on the RV-8 rear panel.
  • Page 67 The LCD display on the remote control should appear as in Figure B below. Figure A: HOME MENU Figure B: MAIN MENU Note: The RV-8 will NOT respond to the PAGE, HOME, FAV, M1, M2 and M3 buttons. 3. RV-8 Setup: The front panel display should indicate: “IR REMOTE TEST Remote Test:”...
  • Page 68 RV-8 Service Manual Test: 1. Press and hold the DVD2 button on the remote. 2. Verify the yellow IR ACK LED is blinking on the RV-8 front panel. 3. Verify the display indicates: “IR REMOTE TEST Remote Test: 21 IR”...
  • Page 69 Lexicon Test: 1. Press each switch and verify that the front panel display indicates the correct name for the switch. Standby = STANDBY Mode Left = LEFT MODE Right = RIGHT MODE Mute = MUTE MODE The MAIN switches = MAIN Switch Name, where Switch Name is the name of the Switch that is labeled on the front panel.
  • Page 70 RV-8 Service Manual Test: 1. Turn the encoder knob clockwise and verify that each LED lights individually and is the correct color. See the color code table below and on the next page. 2. When all LEDs have been lit, press the Mode button to proceed to the next test.
  • Page 71 HDPhones: OUT” Test: 1. Insert a 1/4-inch headphone plug into the Phones jack on the RV-8 front panel, and verify that the display indicates: “HEADPHN INSERT TEST HDPhones: IN.” 2. Remove the 1/4-inch headphone plug from RV-8 front panel Phones jack.
  • Page 72 The fans are located at the bottom of the RV-8 chassis. Two fans are on the left side and two are on the right side of the unit.

  • Page 73: Disassembly Instructions

    3. Push the cover towards the front panel and remove from the bottom of the RV-8. To remove the Power Supply Board: 1. With the RV-8 front panel facing you, locate the power supply module mounted to the inside chassis on the left-hand side of the RV-8.
  • Page 74 2. Locate and disconnect the following power and ribbon cables: J20, 2, 23, 24, 26, 27, 29, 31,and 32 3. Locate and remove the four screws that hold the Main board to the chassis. 4. On the rear panel of the RV-8 locate the screws and other fasteners that hold the Main board to the rear panel.
  • Page 75 Lexicon 5. Carefully slide the Main board to the front of the RV-8 and up and out of the chassis. 6. Store it in a static-free area. To remove the front panel: 1. Place the RV-8 upside down with the front panel facing you.

  • Page 77: Chapter 6 - Theory Of Operation

    Using this technology allows maximum amplifier performance under the most demanding and extreme conditions. In the RV-8 there are two amplifier modules. One module consists of three amplifier channels and the other consists of four amplifier channels. Each individual channel is identical schematically, but not identical in the way they are laid out.

  • Page 78: Amplifier Operation

    RV-8 Service Manual Amplifier Operation At the heart of the amplifier is a high performance error amplifier (U2 - TLE2037). From the error amp audio signals move through the voltage translators and on to Q7 (MJE15032) and Q11 (MJE15033). Q7 and Q11 form current gain cells, which feed the paralleled main output devices (MJ21194 NPN, MJ21193 PNP).
  • Page 79 Lexicon Clip The clip signal is derived from the output signal of the error amp. This signal is called V_ERR on the schematic. V_ERR is fed into a window comparator set up by U4-A (LM339D) and U4-B. When the signal coming out of the error amp exceeds ±12.5Vdc it triggers the window comparator. The output of this stage is sent into another comparator stage set up by U4-C.

  • Page 80: Analog Board Theory

    RV-8 Service Manual RV-8 ANALOG BOARD THEORY The analog board of the RV-8 encompasses all of the analog audio inputs and outputs, level controls and A/D and D/A converters. This board is located below the RV-8 Video Board. There are three separate signal paths: Main, Zone2 and Zone3. Each of the eight analog stereo inputs, the tuner, the phono, or any of eight digital inputs can be routed to any of the three paths.
  • Page 81 Lexicon 1. An S/PDIF signal may be encoded in Dolby Digital or DTS format and pass through a decoder that outputs the 5.1-channels. These channels are then passed along to the DSP and sent to the analog board. 2. Two sets of three separate analog input pairs can be routed directly to the outputs, bypassing the DSP and converters.
  • Page 82 RV-8 Service Manual SCHEMATIC WALKTHROUGH Analog Audio Inputs (sheets 1,2 & 3) Sheets 1 and 2 are identical. The Left input jacks and associated circuitry are on sheet 1 while sheet 2 includes the Right input jacks and circuitry. Each input pair is buffered by a dual TL072 op amp. Each buffer connects to three DG408 8x1 CMOS switches.
  • Page 83 Lexicon The output of the DAC passes through a second order low-pass filter with its –3dB frequency at 187kHz. The filter topology is a compromise between the flat pass-band Butterworth filter and the Bessel filter with its superb transient response. The filter is flat out to 20kHz. It has an overall gain of 6.7dB when measured at the test points.
  • Page 84 RV-8 Service Manual L/R, Center, Sub, L/R Side, L/R Rear) whereas MAIN_DIRECT_SEL/ selects the 5.1-analog inputs directly. The rear channels are switched with separate controls REAR_DACOUT_SEL/ and REAR_DIRECT_SEL/. The output from the analog switch goes to a –6dB level shifter and ADG451 output mute switch. The outputs pass through DC-blocking caps and relays before going to the RCA connectors.

  • Page 85: Main Board Theory

    Lexicon RV-8 MAIN BOARD THEORY This section provides a detailed description of the design theory embodied in the RV-8 Main Board. Each section of this document will discuss the theory of each functional subset of this board and will reference a schematic sheet for each block.
  • Page 86 CPU and each of the peripheral devices attached to the host. It will also allow the running of configuration scripts to test various functions and features included in the RV-8. Re-programming the system FLASH is also called into service via the debugger.
  • Page 87 Lexicon The user port is implemented by PA3_RXD1 (48) and PA4_TXD1 (47). Connecting an HDI emulated hyperterminal to this port allows access to the system software at the code level. This port is also used to download new code to the FLASH device.
  • Page 88 AN7 A/D Converter port (99). It is currently not used. Front Panel Boot Level Monitoring and Control Signals: OVLED, SYSLED, FP_IR_ACK, FPSWITCH[3:1] The user has the option of starting the RV-8 into three modes: • Normal start-up (default) •...
  • Page 89 10-bit address beginning at CPUADDR1 instead of CPUADDR0. Boot Mode Jumper Selection The RV-8 supports multiple booting options to aid in software development. In the final product, only one of these modes is available, booting from FLASH, as described on page 6-15. For development, booting...
  • Page 90 RV-8 Service Manual implemented in W3, W4, and W5. The following table illustrates the various modes available to the developer. Boot Mode Jumper Configuration Usage Uninstalled Uninstalled Default; Boot and Program Run from FLASH Open 2 - 3 1 - 2...
  • Page 91 Lexicon used in the released version of this product, and therefore is installed during software development cycles only. Emulator Support (J14) The Emulator socket is designed to accept a 40-position emulator pod for boot code development. When the pod is in place, it acts exactly like the EEPROM mentioned above. The BOOTCS/ signal is routed to the chip enable pin by placing a jumper plug between pins 2 and 3 on W5.
  • Page 92 RV-8 Service Manual External Registers (U20 and U21) U20 and U21 are octal D-flops that provide software control for the following: • Resets to the DSP engines • Resets to the expansion ports • Control of external trigger voltages •...
  • Page 93 Lexicon DSP 1 and 2 Configuration (U16 and U34) DSP 1 and DSP 2 are Analog Devices ADSP21161N 32-bit SHARC Microcomputers. They come packaged in a 255 position Ball Grid Array. The IO pins on these devices are not 5 volt tolerant, necessitating the level shifters on sheet 2 of this schematic set.
  • Page 94 RV-8 Service Manual EMU/ EMU/ TRST TRST Series Connection Diagram U18 JTAG ENABLED U37 JTAG ENABLED U37 + U18 JTAG ENABLED General Purpose I/O Device Pins: FLAG[9:4] (F3, E3, F2, F4, F1, G3) Each flag pin may be configured as input or an output. In this application the flag pins listed above are configured by software as outputs.
  • Page 95 Lexicon incorporation of the bank bits within the address space. The following table illustrates the internal to external address multiplexing. SHARC DSP Internal to External Address bit mapping Row Address Bank Bits Column Address Internal External Internal External Internal External...
  • Page 96 RV-8 Service Manual Proprietary DSP A (U16) The Memory interface and control block for U16 is shown on this page. The on-chip memory controller provides all the necessary interface to the SDRAM. The DSP accesses the memory data bus 32-bits at one time, eliminating the more conventional four data mask controls.
  • Page 97 Lexicon Link Ports Signals: DSPABLDATA[7:0], DSPBALDATA[7:0], L0CLK, L0ACK, L1CLK, L1ACK The link port is a full duplex pathway that allows 100MHz bit rate transfers of audio data between the SHARCs. The L0DAT[07:00] ports on each device are configured as transmitters while the L1DAT[07:00] ports are configured as receivers.
  • Page 98 RV-8 Service Manual Power and Ground Distribution (U16 and U34) The SHARC devices require two supply voltages. One voltage powers the 3.3V IO while the inner core of the device runs off of 1.8V. There are 13 pins on each device that require 3.3V, 14 pins that require 1.8V, and one pin that requires a separate 1.8V to power the internal PLL circuitry.
  • Page 99 Lexicon Address == 0x00C00000 AMPMRLY EXPBRST EXPARST ETRGEN1 ETRGEN0 DSPCRST DSPBRST DSPARST • AMPMRLY – Amp Mains Relay CTRL = 0: Relay is open. = 1: Relay is closed. • EXPBRST – Expansion Slot 1 Reset = 0: Expansion Slot 1 is reset.
  • Page 100 RV-8 Service Manual External Register U21 bit map RESREGDECH is decoded from chip select CPUCS3/, write strobe CPUWRH/, and the condition CPUADDR[3:1]==000. The result is an active high strobe when a write operation is performed at CPU address 0x00C00000. This strobe acts as a clock signal for register device U20 on sheet 2. The following table illustrates the register control.
  • Page 101 Lexicon DISP_RS is a decode of CPUCS3/ and the condition CPUADDR[3:1] == 001. This is an active low signal and is a function bank select signal for the VFD. DISP_RW is a read/write strobe for the VFD. When this signal is high, the VFD registers are in read mode.
  • Page 102 DSPATXD, CRY_FCS/, CRY_FINTREQ/, HINBSY During the boot phase of RV-8, algorithm code is loaded into the format FLASH and then into the on- board SRAM. All external memory is accessed through DSPC via its SPI port. As demonstrated with the SHARC devices, the two SPI ports for DSPAB and DSPC are shared, with each one selected by independent chip select signals.
  • Page 103 When this signal is low, the internal clock source is the internal PLL. When high, then all internal logic is driven by the CLKIN pin directly. This signal is significant during the boot phase of RV-8 when the algorithm FLASH U19 is being loaded. Writing to this FLASH can only happen reliably when CLKSEL is high.
  • Page 104 RV-8 Service Manual from the propagation delay of a gate within U7. The resultant signal DELWE/ is the write enable for U19. Software requirements dictate that the FLASH address space begin at 0x80000. U13 decodes out the start address with chip select. When CRY_A19 is high and CRY_NVCS/ is low, pin 4 of U13 goes low.
  • Page 105 Lexicon coming up. This is a likely scenario given the fact that the 3.3V rail is more heavily loaded than the 2.5V rail. There are seven ground pins associated with the core supply, and four associated with the I/O supply. In addition, there are five no connect pins that are recommended by the manufacturer to be tied to GND.
  • Page 106 RV-8 Service Manual FPGA Programming Source Configuration Table FPGA PROGRAMMING CONFIGURATION R128 R129 R130 R131 R133 R134 R135 R148 R149 R150 R157 R158 MODE Host Programming (Default) EPROM Programming (Development) Host Bus Interface Signals: CPUADDR[9:0], LVDATA[7:0], CPUCS2/, CPUWRL/, CPURD/, BUFDIR, CPUCLKOUT, RESET/ The AVRX FPGA internal registers are contained entirely within the CS2/ memory space of the host CPU.
  • Page 107 Lexicon LVCRYIRQ/ is an interrupt to the host CPU that is generated whenever a read or write transaction via the Format Decoder SPI ports has been completed. This carries a host interrupt priority of level 3. This signal is level shifted to 5V prior to being presented to the CPU. At present, this interrupt is masked off and unused by system software.
  • Page 108 Digital Audio I/O Signals: SPDIF_COAX_IN[4:1], SPDIF_OPTO_IN[4:1], DIG_REC_OUT Provision is made within the RV-8 for eight S/PDIF inputs, four from coaxial sources, and four from optical fiber sources. The coax sources are signal conditioned and buffered prior to being routed to the AVRX FPGA.
  • Page 109 Lexicon CRY_INTREQ/ is an interrupt line that indicates that DSPC has out-going control data and should be serviced by the host CPU. When this interrupt occurs, bit 2 in the Interrupt Status Register is set. This bit is then cleared after the host CPU polls this register. This interrupt is active low.
  • Page 110 RV-8 Service Manual to the SPI DMA Block Size Register. Once this register is written, then a SPI transfer occurs to the SHARC. When the transfer is done, the host CPU is interrupted by DSPABIRQ/. The system software must then clear bit 4 in the SPI Chip Select Register to zero.
  • Page 111 Lexicon Tuner Board Control Interface Signals: ADA_TUN_CE/, TUN_RDS_CLK, TUN_RDS_DAT ADA_TUN_CE/ is a chip select that enables SPI transfers to the Tuner Board. The rest of the SPI port is comprised of ADA_SDATA_IN, ADA_SDATA_OUT, and ADA_LATCH from the Analog Board Control Interface.
  • Page 112 RV-8 Service Manual MAIN_I2S_OUT1 is the 24-bit serial data stream sourced from the AVRX FPGA to the LEFT/RIGHT FRONT D/A Converter on the Analog Board. MAIN_I2S_OUT2 is the 24-bit serial data stream sourced from the AVRX FPGA to the CENTER/SUB D/A Converter on the Analog Board.
  • Page 113 Lexicon Address Bits Signal Base + 0 Ready control for channels 4:1 (RDY_CON[4:1]) Base + 0 (Not used) Base + 1 (Not used) Four Channel Control RAM Table SER_CLKA is the serial shift clock with which the control and status data are synchronous.
  • Page 114 MAIN_PLL_FPGA_MCKO, ZONE2_PLL_PUMP_UP, ZONE2_PLL_PUMP_DN, ZONE2_PLL_LOCK_DN/, REC_DAC_SEL[1:0], ZONE2_PLL_FPGA_MCKO, AUDIO_OSC The AVRX FPGA uses the output frequency of each VCO implemented on RV-8 as a 512FS master clock at 44.1/48kHz and a 256FS master clock at 88/96kHz. Within the AVRX, the incoming clock frequencies are divided by 512 or 256 and is phase compared to a corresponding frequency derived from the reference clock source.
  • Page 115 Signals: EXP[17:0] The RV-8 has built in capacity for future expansion capabilities. A general purpose 18-bit bus is shared between two expansion ports. To date, the only use for this expansion bus is for a test fixture that may be plugged into either port to test continuity of the signals to the FPGA.
  • Page 116 RV-8 Service Manual FB15 provides a cleaner 3.3V supply to the oscillator, minimizing contamination of the output clock signal by the switching characteristics of other devices connected to the 3.3VD plane. C142 is a standard high frequency de-coupling capacitor for U35.
  • Page 117 RESET is an active high signal generated by Reset Generator U31. It provides power-up reset to the Analog Board and is the only positive going reset signal in use in the RV-8 system. Amp Board Connectors (J18 and J22) J18 is a 14 position FFC connector that provides interconnection with the Crown Four Channel Amplifier Module.
  • Page 118 RV-8 Service Manual OVLD_LED is a buffered equivalent of the OVLED signal, which is driven directly by the Host CPU. The OVERLOAD LED is one of three LEDs located behind the VFD lens on the front panel. U15 provides the buffered signals from the CPU to the Front Panel Board.
  • Page 119 BROWN_OUT is a monitoring signal from the amp power supply that will trigger an NMI if the power supply rails drop by more than 10% of their nominal voltage. This will place the RV-8 into a standby mode with the amplifiers shut off until the supplies have stabilized.
  • Page 120 J7 accepts a composite video signal from the Video Board and passes it to the outside world. J7 is spark gap protected. Trigger Outputs (Sheet 14) The RV-8 provides two 12V voltage sources for remote powering external accessories in the user’s home theater. Each trigger output can provide up to 1 Amp to an external load.
  • Page 121 Lexicon The regulator provides the external 12VDC when the ON/OFF pin is brought to a logic 0. This pin is software controlled via the external registers on sheet 2. See page 6-23 for further information. Inverter U14 permits us to use positive logic in the software register.
  • Page 122 RV-8 Service Manual D16 prevents the control voltage from going much below 2V, ensuring that the VCO is never driven to a non-oscillating state. D21 prevents the duty cycle integrator from being driven to the wrong polarity when the loop is out of lock.

  • Page 123: Phono/Microphone Input Board Theory

    ZONE 2 Remote Input Remote control of the RV-8 is made possible via an infra-red detector behind the front panel lens. Control from the Main Zone is made by pointing the remote at the front panel and activating functionality on the remote control surface panel.

  • Page 124: Tuner Board Theory

    RV-8. FM is brought into the tuner via a 75-ohm F-type connector. FM signals may be provided to the tuner via cable television service, or with the use of a 75/300 ohm Balun transformer and a Y-style twin-lead antenna.
  • Page 125 Left and Right audio signals are presented to the rest of the RV-8 system via LFOUT and RFOUT (pins 27 and 28, respectively). C12 and C13 provide an AC couple path to the output of the board, while R8 and R9 ensure equal path impedance for these signals.

  • Page 126: Video System Theory

    3 of J2. This bulk voltage is noise filtered by FB1. Pins 4 and 6 provide the LEFT and RIGHT stereo signals from the tuner to the rest of RV-8, while the common return path for both of these is provided by pin 5.
  • Page 127 Lexicon S-video inputs (Video board schematic sheet 1) Specific references are to input 1; other inputs are similar. S-video luminance inputs (pin 3 of the mini-din jacks) are terminated and buffered the same as composite inputs. AC-coupling is applied after buffering;...
  • Page 128 U18 feeds two 75-ohm outputs, connecting to rca jacks on the Video Out board via ribbon cable J16. Zone3 Composite video (Video board schematic sheet 4) Zone3 is an additional video path in the RV-8 which provides one composite video output. Zone 3 video functionality corresponds to zone2 audio functionality in previous products and the signal-naming nomenclature reflects this legacy.
  • Page 129 One normally-open pole of RY2 disconnects the luminance component CNV_Y in order to effectively disable component output. The signals generated by the RV-8 OSD are compatible only with the 480i Y Pb Pr component format. When incompatible formats are in use, the component OSD is inapplicable, and is not accessed by the operating system software.
  • Page 130 RV-8 Service Manual In overlay mode, composite or s-video luminance from the input amplifier is applied to YIN, and similarly, s-video chrominance (if applicable) is applied to CIN. The video applied to YIN is shifted to have a back- porch dc-level of about 1.57Vdc by U31 and associated circuitry. C123/C73 passively couple the ac- content of the luminance signal, with the op-amp providing the dc response.
  • Page 131 Lexicon Video Control Registers (Video board schematic sheet 8). Control registers are implemented within CPLD U14, through a serial interface. The serial clock and data are VIDEO_SCLK and VIDEO_DATA, shared in common with the OSD. A transfer is initiated by a pulse on VIDEO_REG/, followed by a burst of clock and data that update all 56 control register bits within the CPLD in approximately 4.5 sec.

  • Page 133: Chapter 7 - Parts List

    CHAPTER 7 – PARTS LIST PART NO DESCRIPTION EFFECT. INACT. REFERENCE INFO. Main Board Assembly 022-14458 PL,MECH ASSY,VCO,MC12/B 2.00 J9,11 202-09794 RESSM,RO,0 OHM,0805 1.00 202-09795 RESSM,RO,5%,1/10W,2.2K OHM 5.00 R6,8,10,12,25 202-09871 RESSM,RO,5%,1/10W,1K OHM 1.00 202-09874 RESSM,RO,5%,1/10W,2.2M OHM 4.00 R47,49,96,98 202-09894 RESSM,RO,5%,1/10W,1M OHM 1.00 R145 202-09899...
  • Page 134 PART NO DESCRIPTION EFFECT. INACT. REFERENCE INFO. 240-15668 CAPSM,ELEC,330uF,6.3V,20%,105C 4.00 C39,75,133,134 240-20028 CAP,ELEC,6800uF,6.3V,RAD,20% 2.00 C73,130 241-09798 CAPSM,TANT,10uF,10V,20% 3.00 C52,94,122 241-11799 CAPSM,TANT,4.7uF,6.3V,20% 4.00 C54,67,100,127 241-15206 CAPSM,TANT,33uF,10V,20% 2.00 C74,131 244-10423 CAP,MYL,.22uF,50V,RAD,5%,BOX 3.00 C168,172,175 245-09291 CAPSM,CER,470pF,50V,COG,5% 1.00 C118 245-09869 CAPSM,CER,.001uF,50V,Z5U,20% 14.00 C34,38,58,69,76,81 C97,106,132,137,146 C147,151,152 245-09876 CAPSM,CER,.01uF,50V,Z5U,20%...

  • Page 135: Vco Masterclock Board Assembly

    PART NO DESCRIPTION EFFECT. INACT. REFERENCE INFO. 340-12119 ICSM,LIN,TL7705,+5V MON,SOIC 1.00 340-13137 IC,LINEAR,LM2941CT,ADJ,TO-220 2.00 U8,9 340-13883 ICSM,LIN,LM2937,2.5V REG,TO263 1.00 340-14535 IC,LIN,1585A,3.3V REG,TO220 1.00 340-15088 ICSM,LIN,LM1117,ADJ,800mA,SOT 2.00 U22,39 345-13140 ICSM,INTER,RS232 XCVR,+5V,SOIC 1.00 350-13879 ICSM,SDRAM,512KX32X4,3.3V,TSOP 2.00 U6,27 350-15096 ICSM,FPGA,XC2S200-6,28X42,PQFP 1.00 350-15209 ICSM,DRAM,1MX16,60NS,SOJ 1.00 350-15249 ICSM,GAL,16V8,RV8,V1.00...

  • Page 136: Microphone/Preamplifier Board Assembly

    PART NO DESCRIPTION EFFECT. INACT. REFERENCE INFO. Microphone/Preamplifier Board Assembly 202-09795 RESSM,RO,5%,1/10W,2.2K OHM 4.00 R1,3,4,6 202-09871 RESSM,RO,5%,1/10W,1K OHM 1.00 202-10559 RESSM,RO,5%,1/10W,100 OHM 12.00 R19,20,23,24,33 R41-43,45,48,52,54 202-10586 RESSM,RO,5%,1/4W,100 OHM 2.00 R26,29 202-10598 RESSM,RO,5%,1/10W,330 OHM 2.00 R2,5 203-10578 RESSM,RO,1%,1/10W,2.21K OHM 4.00 R35,39,44,50 203-11077 RESSM,RO,1%,1/10W,237 OHM 1.00...

  • Page 137: Ir/Encoder Board Assembly

    PART NO DESCRIPTION EFFECT. INACT. REFERENCE INFO. 245-10562 CAPSM,CER,150pF,50V,COG,10% 2.00 C14,15 245-10588 CAPSM,CER,33pF,50V,COG,10% 1.00 245-10976 CAPSM,CER,47pF,50V,COG,5% 2.00 C6,7 245-14588 CAPSM,CER,.01uF,25V,X7R,10%,06 2.00 C2,19 245-15691 CAPSM,CER,.001uF,25V,X7R,10%06 2.00 C9,11 245-15692 CAPSM,CER,.1uF,25V,X7R,10%,06 3.00 C3,8,10 245-15736 CAPSM,CER,.22uF,16V,X7R,10% 1.00 270-00779 FERRITE,BEAD 1.00 270-15728 INDUCTORSM,6.8uH,10% 1.00 340-15088 ICSM,LIN,LM1117,ADJ,800mA,SOT 2.00 U1,3...

  • Page 138: Analog Input/Output Board Assembly

    PART NO DESCRIPTION EFFECT. INACT. REFERENCE INFO. 430-13888 LEDSM,RED,60MCD,AX,ZBEND,2.5MM 12.00 D2-10,21,32,39 430-14527 LEDSM,SYEL,250MCD,AX,ZBEND,2.5 9.00 D12-19,34 453-13899 SWSM,PBM,1P1T,6.2MMSQ,200GF 45.00 SW1-45 510-13145 CONN,POST,.100,HDR,2X7MCG,LP 2.00 J1,2 510-15690 CONN,FFC,1.25MM,40 POS,VERT 1.00 710-15560 PC BD,SW/LED,RV8 1.00 PICK REV 1 PC BOARD 740-11287 LABEL,S/N,PCB,PRINTED 1.00 Headhone Board Assembly 245-10562 CAPSM,CER,150pF,50V,COG,10% 2.00...
  • Page 139 PART NO DESCRIPTION EFFECT. INACT. REFERENCE INFO. R198,306-309,393-396 R408,409 203-10896 RESSM,RO,1%,1/10W,1.00K OHM 24.00 R116,118,124,125,127 R128,130,131,133,134 R236,237,239,241-243 R245,247,249,253-255 R257,259 203-11078 RESSM,RO,1%,1/10W,422 OHM 9.00 R110,202,203,296,298 R300,403,416,418 203-11697 RESSM,RO,1%,1/10W,909 OHM 2.00 R248,251 203-11726 RESSM,RO,1%,1/10W,301 OHM 2.00 R303,401 203-11734 RESSM,RO,1%,1/10W,4.32K OHM 8.00 R137,140,143,146,149 R152,155,158 203-11993 RESSM,RO,1%,1/10W,357 OHM 1.00...
  • Page 140 PART NO DESCRIPTION EFFECT. INACT. REFERENCE INFO. C123,273,275,277,281 C283,285,289,291,293 C297,299,301,305,307 C309,311,312,315,316 C319,322,324,327,330 C332,335,338,340,343 C346,403,405,407,410 C415,417,419,422,427 C429,431,434,439,441 C446 245-10561 CAPSM,CER,100pF,50V,COG,5% 16.00 C349,350,354,355 C359,360,363,365 C375,376,380,381 C385,386,390,391 245-10562 CAPSM,CER,150pF,50V,COG,10% 36.00 C1-30,448,450,451 C453,454,456 245-10587 CAPSM,CER,18pF,50V,COG,10% 12.00 C86,89,93,96,153,156 C157,160,161,164,165 C168 245-11594 CAPSM,CER,2200pF,50V,COG,5% 8.00 C400,401,412,413 C424,425,436,437 245-11598 CAPSM,CER,8200pF,50V,COG,5% 10.00...

  • Page 141: Channel Amplifier Board Assembly

    PART NO DESCRIPTION EFFECT. INACT. REFERENCE INFO. C216,217 270-00779 FERRITE,BEAD 15.00 FB1-14,33 270-06671 FERRITE CHOKE,2.5 TURN 3.00 FB25-27 270-09799 FERRITESM,CHIP,600 OHM,1206 20.00 FB15-24,28-32,34-38 300-10563 DIODESM,DUAL,SERIES,GP,SOT23 26.00 D1-24,28,29 300-11599 DIODESM,GP,1N4002,MELF 10.00 D25-27,30-36 310-10566 TRANSISTORSM,2N4401,SOT23 3.00 Q1-3 330-13865 ICSM,DIGITAL,74VHC04,SOIC 1.00 330-13882 ICSM,DIGITAL,74LCX14,SOIC 2.00 U76,91 330-14642...
  • Page 142 PART NO DESCRIPTION EFFECT. INACT. REFERENCE INFO. R247,305,330,331 203-12722 RESSM,THIN,1%,1/10W,49.9K OHM 3.00 R138,222,306 203-13134 RESSM,THIN,1%,1/10W,1.00K OHM 9.00 R144,155,165,228,231 R249,312,315,333 203-13638 RESSM,THIN,1%,1/10W,2.49K OHM 15.00 R86,88,91,93,150 R170,172,175,177 R234,254,256,259 R261,318 203-14566 RESSM,THIN,1%,1/10W,20.0K OHM 9.00 R151,154,235,238,319 R322,372,383,394 203-14891 RESSM,THIN,1%,1/10W,9.09K OHM 6.00 R98,101,182,185 R266,269 203-16175 RESSM,RO,1%,1/4W,365K OHM 6.00 R239,240,242,245...
  • Page 143 PART NO DESCRIPTION EFFECT. INACT. REFERENCE INFO. 244-16267 CAP,MYL,.33uF,63V,RAD,10% 3.00 C66,105,144 245-10416 CAPSM,CER,1000pF,50V,COG,5% 6.00 C179-184 245-10544 CAPSM,CER,220pF,50V,COG,5% 12.00 C51,52,55,56,90,91 C94,95,129,130 C133,134 245-10561 CAPSM,CER,100pF,50V,COG,5% 6.00 C163,164,167,168 C171,172 245-10973 CAPSM,CER,22pF,50V,COG,5% 6.00 C40,42,79,81,118,120 245-16269 CAPSM,CER,22pF,200V,COG,5% 15.00 C44,47-50,83,86-89 C122,125-128 245-16270 CAPSM,CER,100pF,200V,COG,5% 6.00 C53,57,92,96,131,135 245-16293 CAPSM,CER,.1uF,50V,X7R,10% 37.00 C4,43,45,46,63,71-78...

  • Page 144: Channel Amplifier Board Assembly

    PART NO DESCRIPTION EFFECT. INACT. REFERENCE INFO. 600-16416 FUSE CLIP,5X20MM,PC,.217"LS 4.00 HW4-7 600-16419 BUS BAR,CU,3CH,RV8 1.00 680-16417 WIRE,16G,#6RINGX2/PC,80/150MM 1.00 680-16418 WIRE,16G,#6RINGX2/PC,170/150MM 1.00 710-16150 PC BD,AMP MOD,3CH,RV8 1.00 PICK REV 2 PC BOARD 740-11287 LABEL,S/N,PCB,PRINTED 1.00 PLACE NEXT TO TP8 4-Channel Amplifier Board Assembly 201-16214 RES,TRM,1T,PC,1K OHM,SA,TOP 1.00...
  • Page 145 PART NO DESCRIPTION EFFECT. INACT. REFERENCE INFO. 203-16243 RESSM,THIN,1%,1/10W,280K OHM 4.00 R46,130,214,298 203-16244 RESSM,THIN,1%,1/10W,33.2K OHM 12.00 R48,51,62,132,135 R146,216,219,230,300 R303,314 203-16245 RESSM,THIN,1%,1/10W,47.5 OHM 4.00 R12,96,180,264 203-16249 RESSM,THIN,1%,1/10W,750.0 OHM 12.00 R13,24,55,97,108,139 R181,192,223,265,276 R307 203-16250 RESSM,THIN,1%,1/10W,75.0 OHM 4.00 R22,106,190,274 203-16251 RESSM,THIN,1%,1/10W,95.3 OHM 16.00 R20,21,30,31,104,105 R114,115,188,189,198 R199,272,273,282,283...

  • Page 146: Speaker Emi Filter Board Assembly

    PART NO DESCRIPTION EFFECT. INACT. REFERENCE INFO. 300-10509 DIODESM,1N914,SOT23 64.00 D1-4,6-9,11-13,16-18 D24-27,29-32,34-36 D39-41,47-50,52-55 D57-59,62-64,70-73 D75-78,80-82,85-87 D97,98-104 300-16200 DIODESM,ZENER,5.1V,225mW,SOT23 8.00 D20,21,43,44,66,67 D89,90 300-16201 DIODESM,ZENER,17V,225mW,SOT23 8.00 D19,42,65,88,93-96 300-16202 DIODESM,ZENER,16V,500mW,SOD123 8.00 D22,23,45,46,68,69 D91,92 300-16203 DIODESM,RECT,400V,50A,50NS,SMB 8.00 D14,15,37,38,60,61 D83,84 300-16205 DIODESM,SW,250V,625mA,MELF 8.00 D5,10,28,33,51,56 D74,79 310-10510 TRANSISTORSM,2N3904,SOT23 12.00...

  • Page 147: Video Board Assembly

    PART NO DESCRIPTION EFFECT. INACT. REFERENCE INFO. Video Board Assembly 202-09795 RESSM,RO,5%,1/10W,2.2K OHM 1.00 202-09871 RESSM,RO,5%,1/10W,1K OHM 13.00 R4,11,17,85,88,108 R111-113,139,239 R241,244 202-09873 RESSM,RO,5%,1/10W,10K OHM 13.00 R84,107,136,146,170 R214,225,230,231,243 R247,249,250 202-09874 RESSM,RO,5%,1/10W,2.2M OHM 1.00 R240 202-09894 RESSM,RO,5%,1/10W,1M OHM 2.00 R75,232 202-09899 RESSM,RO,5%,1/10W,47 OHM 4.00 R79,80,224,226 202-10426...
  • Page 148 PART NO DESCRIPTION EFFECT. INACT. REFERENCE INFO. 203-11740 RESSM,RO,1%,1/10W,9.09K OHM 4.00 R3,7,12,18 203-11743 RESSM,RO,1%,1/10W,100K OHM 5.00 R34,44,53,62,71 203-11889 RESSM,RO,1%,1/10W,110 OHM 4.00 R233-236 203-12198 RESSM,RO,1%,1/10W,2.15K OHM 5.00 R172,185,186,188,189 203-12298 RESSM,RO,1%,1/10W,30.1K OHM 1.00 R253 203-12491 RESSM,RO,1%,1/10W,205 OHM 4.00 R140,143,210,213 203-12497 RESSM,RO,1%,1/10W,8.25K OHM 4.00 R86,109,137,237 203-12841...

  • Page 149: Video In Board Assembly

    PART NO DESCRIPTION EFFECT. INACT. REFERENCE INFO. 330-10505 ICSM,DIGITAL,74HC02,SOIC 1.00 330-12321 ICSM,DIGITAL,74VHCT08,TSSOP 1.00 340-01525 IC,LINEAR,7905,-5V REG 1.00 340-09244 ICSM,LINEAR,78LS05,5V REG,SOIC 1.00 340-10502 ICSM,LIN,LF353,DUAL OPAMP,SOIC 2.00 U31,41 340-11495 ICSM,LIN,LT1229,VID OPAMP,SOIC 3.00 U18,28,30 340-13445 ICSM,LIN,TLC2933,PLL,TSOP 1.00 340-14535 IC,LIN,1585A,3.3V REG,TO220 1.00 340-15586 ICSM,LIN,MAX4310,VIDAMP,W/MUX 5.00 U4,15-17,38 340-15683...

  • Page 150: Chassis Assembly

    PART NO DESCRIPTION EFFECT. INACT. REFERENCE INFO. 203-14566 RESSM,THIN,1%,1/10W,20.0K OHM 4.00 R211,213,214,216 203-16235 RESSM,THIN,1%,1/10W,100 OHM 2.00 R222,226 203-16238 RESSM,THIN,1%,1/10W,14.7K OHM 1.00 R212 203-16246 RESSM,THIN,1%,1/10W,6.19K OHM 2.00 R217,219 203-16247 RESSM,THIN,1%,1/10W,61.9K OHM 2.00 R208,209 240-16258 CAP,ELEC,5600uF,35V,SNAP,20% 2.00 C81,82 240-16259 CAP,ELEC,27000uF,80V,SNAP,20% 4.00 C40,77,78,79 240-16264 CAPSM,ELEC,10uF,50V,NPOL,20% 1.00...
  • Page 151 PART NO DESCRIPTION EFFECT. INACT. REFERENCE INFO. 635-15322 SPCR,M3X8MM,RD,HEXHD,BLIND,ZN 16.00 FANS TO CHASSIS 640-01711 SCRW,6-32X1/4,FH,PH,ZN 4.00 PS TO PS MTG PLATE 640-01721 SCRW,8-32X3/8,PNH,PH,ZN 4.00 HANDLES TO R.PANEL 640-02377 SCRW,4-40X1/4,PNH,PH,BLK 1.00 MAIN BD TO R.PANEL 640-10498 SCRW,M3X6MM,PNH,PH,BZ 6.00 CTR PLT TO CHAS L&R 640-10498 SCRW,M3X6MM,PNH,PH,BZ 2.00...

  • Page 152: Fp Mechanical Assembly

    PART NO DESCRIPTION EFFECT. INACT. REFERENCE INFO. 702-15806 PLATE,BOTTOM,RV8 1.00 CHASSIS BOTTOM 702-15807 PLATE,MTG,PS,RV8 1.00 702-15808 PANEL,OPTION,BLANK,RV8 1.00 REAR PANEL 720-15425 PAD,FOOT,1.438OD,.563IDX.06THK 4.00 720-16123 TAPE,FOAM,DBL-STK,1.75X.4X.025 1.00 FERRITE TO TUNER CBL 740-08556 LABEL,GROUND SYMBOL,0.5"DIA 1.00 740-09538 LABEL,S/N,CHASSIS,PRINTED 1.00 REAR PANEL 740-14888 LABEL,LIC/PAT/WARN,MC12 1.00 CHASSIS BOTTOM...

  • Page 153: Fan Assembly

    PART NO DESCRIPTION EFFECT. INACT. REFERENCE INFO. 641-13116 SCRW,TAP,AB,4X3/8,FH,PH,BZ 1.00 RCA CONN TO BRKT 641-13116 SCRW,TAP,AB,4X3/8,FH,PH,BZ 2.00 TUNER BD TO BRKT 701-15814 BRACKET,TUNER,RV8 1.00 Fan Assembly 410-15839 FAN,60X60X10MM,12VDC,10CFM 1.00 525-12536 CONN,CONT,CRIMP,22-26AWG,AMP 2.00 527-12537 CONN,HSG,CRIMP,.100X2,POL,LK 1.00 Power Supply Mechanical Assembly 023-15826 PL,PS BD SUBASSY,RV8 1.00 440-16212...

  • Page 154: Single Positive Heatsink Assembly

    PART NO DESCRIPTION EFFECT. INACT. REFERENCE INFO. 490-16280 CONN,BDGPOSTX2G,10-32,RED/BLK 4.00 630-16283 WSHR,SHLDR,.312SHNK,#6CL,NYL 4.00 630-16284 SPCR,#6CLX.090,.25RD,NYL 4.00 640-01710 SCRW,6-32X1/4,PNH,PH,ZN 8.00 P3-10 640-16298 SCRW,6-32X.25,UFH,PH,ZN 2.00 641-16288 SCRW,TAP,6-32X.312,PNH,TORX,ZN 24.00 643-16290 NUT,6-32,KEP,CONICAL WSHR,ZN 4.00 644-03668 WSHR,LOCK,EXT STAR,#6,SS 4.00 680-16423 HARNESS,AMP,4CH,RV8 1.00 701-16425 BRACKET,AMP,4CH,RV8 1.00 702-16428 PLATE,AMP,4CH,RV8 1.00...
  • Page 155 BAT,ALK,AAA 4.00 480-15840 ANTENNA,AM,LOOP,75X168MM 1.00 480-15841 ANTENNA,FM,"F",1.5M L 1.00 480-15842 ANTENNA,FM,PAL,1.5M L 1.00 560-16125 ADPTR,RF CONN,F-MALE>PAL-MALE 1.00 730-15818 BOX,26.75X23.375X15.25,BLANK 1.00 OUTER BOX 730-15819 BOX,25.875X22.5X14,LEXICON 1.00 INNER BOX 730-15821 INSERT,FOAM,BASE,4UX19 1.00 730-15822 INSERT,FOAM,TOP,4UX19 1.00 730-15823 BOX,18.75X12.625X2.5 1.00 730-15829 TRAY,ACCESSORY,RV8 1.00 7-23...
  • Page 157 RELEASED COPY MAY 15 2003...
  • Page 158 JUL 22 2005 RELEASED COPY...
  • Page 159 JUL 22 2005 RELEASED COPY...
  • Page 160 JUL 09 2004 RELEASED COPY...
  • Page 161 JUL 22 2005 RELEASED COPY...
  • Page 162 JUL 22 2005 RELEASED COPY...
  • Page 163 JUL 15 2004 RELEASED COPY...
  • Page 164 JUL 22 2005 RELEASED COPY...
  • Page 166 JUL 22 2005 RELEASED COPY...
  • Page 167 JUL 22 2005 RELEASED COPY...
  • Page 173 RELEASED COPY MAY 20 2004...
  • Page 174 RELEASED COPY JAN 07 2004...
  • Page 175 APR 2 2004 RELEASED COPY...
  • Page 176 RELEASED COPY DEC 18 2003...
  • Page 177 RELEASED COPY...
  • Page 178 RELEASED COPY...
  • Page 179 RELEASED COPY...
  • Page 180 JUL 22 2005 RELEASED COPY...
  • Page 181 RELEASED COPY JUL 09 2004...
  • Page 186 REVISIONS DRAFTER Q.C. DESCRIPTION CHECKER AUTH. CHANGED PER DCR 000327-00 3/27/00 4/28/00 4/10/00 4/10/00 CHANGED PER DCR 000925-01 10/13/00 10/23/00 10/20/00 10/20/00 CHANGED R3 FROM 2.4K TO 1.5K PER ECO 1/30/01 1/30/01 010130-00 1/30/01 1/30/01 +5VD IRM-8755-H2 SEE NOTE 4 +5VD GPIU281 IR FLASHER...
  • Page 187 EXPO5 EXPO6 EXPO7 +5VD EXPCS1/ EXPCS0/ EXP_RESET/ NC7WZU04 RESET/ SPARE +5VD NC7WZU04 .1/25 .1/25 © 2003 Lexicon, Inc. CONTRACT exicon 3 OAK PARK BEDFORD, MA 01730 TITLE APPROVALS DATE SCHEM, EXP TEST BD, RV8 DRAWN 4/29/03 CHECKED SIZE CODE NUMBER...
  • Page 188 75.0 CVID4 YEL RCA 3.3K .1/25 -15V +5VV .1/25 2N3904 75.0 CVID5 YEL RCA 3.3K .1/25 © 2002 Lexicon, Inc. CONTRACT exicon -15V 3 OAK PARK BEDFORD, MA 01730 TITLE APPROVALS DATE SCHEM,VIDEO IN BD,RV8 DRAWN 8/7/02 RCA INPUTS CHECKED...
  • Page 189 CVID_ZON21 YEL RCA NOTES 1 LAST REFERENCE DESIGNATORS USED: J5 CVID_MAIN2 YEL RCA MAIN COMPOSITE VIDEO CVID_MAIN1 1(OSD) YEL RCA © 2002 Lexicon, Inc. CONTRACT exicon 3 OAK PARK BEDFORD, MA 01730 TITLE APPROVALS DATE SCHEM,VIDEO OUT BD,RV8 DRAWN 8/7/02...
  • Page 190 SHEET REVISION TITLE -15VA PHONO PREAMP MIC INPUTS 20.0K 47.5K 4.7PF 4.75K 2.37K .068/63 10/25 47/6 © 2003 Lexicon, Inc. CONTRACT exicon 3 OAK PARK BEDFORD, MA 01730 TITLE APPROVALS DATE SCHEM, MIC/PREAMP BD,RV8 DRAWN 8/15/02 PHONO PREAMP CHECKED SIZE...
  • Page 191 REVISIONS DRAFTER Q.C. DESCRIPTION CHECKER AUTH. CHANGED PER DCR 021030-00 11/27/02 11/26/02 11/20/02 11/26/02 CHANGED PER DCR 030317-00 5/21/03 5/22/03 5/22/03 5/22/03 +15VA 10.0K +15VA +15VA +15VA 47PF 2.2K 10.0K 10/16 MIC IN 1 BAV99 150PF .1/25 .1/25 MC33078 BAV99 MC33078 2.2K MIC1_OUT...
  • Page 192 CHASSIS POWER GROUND GROUND GROUND GROUND 3 LAST REFERENCE DESIGNATORS USED: C2, FB3, J2 4 COMPONENTS MARKED WITH ARE NOT ON BOM. © 2003 Lexicon, Inc. CONTRACT exicon 3 OAK PARK BEDFORD, MA 01730 TITLE APPROVALS DATE SCHEM,HEADPHONE BD,RV8 DRAWN...
  • Page 193 2200PF DGND NC10 1/4W RDSGND NC11 150PF 150PF 47/16 AGND NC12 TUN_RDS_CLK TUN_RDS_DAT 47PF 47PF © 2003 Lexicon, Inc. CONTRACT exicon 3 OAK PARK BEDFORD, MA 01730 TITLE APPROVALS DATE DRAWN SCHEM, TUNER BD, RV8 12/3/02 CHECKED SIZE CODE NUMBER...
  • Page 194 REVISIONS CPUADDR[20:0] [7/B5,9/C7] DRAFTER Q.C. DESCRIPTION CPUDATA[15:0] CHECKER AUTH. [2/D7,7/A5] CHANGED PER DCR 020913-00 RP11 11/05/02 12/20/02 CPUADDR20 +5VD AT49C1024 +5VD 11/06/02 12/20/02 CPUADDR1 RP11 CPUADDR19 CPUADDR2 CPUDATA0 CHANGED PER DCR 030307-00 DRAM 5/2/03 5/20/03 CPUADDR3 CPUDATA1 CPUADDR1 CPUADDR4 CPUDATA2 RP11 CPUADDR2 5/14/03...
  • Page 195 +5VD REVISIONS +5VD DRAFTER Q.C. DESCRIPTION CHECKER AUTH. 74VHCT245 CHANGED PER DCR 020913-00 11/05/02 12/20/02 CPU_WRDCLK_MON WRDCLKMON [1/A3] [9/C8] CPU_KYBDIRQ/ LVKYBDIRQ/ [1/B8] [9/D2] 11/06/02 12/20/02 CPU_DSPABIRQ/ LVDSPABIRQ/ CHANGED PER DCR 030307-00 [1/B8] [9/D2] 5/2/03 5/20/03 CPU_CRYIRQ/ LVCRYIRQ/ [1/C8] [9/C2] CPU_VIDTUNIRQ/ LVVIDTUNIRQ/ [1/D8] [9/C2]...
  • Page 196 REVISIONS R164 CLK12500C DRAFTER Q.C. DESCRIPTION [8/B8] CHECKER AUTH. 74LCX14 CHANGED PER DCR 020913-00 11/05/02 12/20/02 R167 12.500MHZ CLK12500B [7/B5] 11/06/02 12/20/02 R165 74HCU04 +3.3VD CHANGED PER DCR 030307-00 5/2/03 5/20/03 1.3M 5/14/03 5/20/03 +5VD CHANGED PER DCR 030626-00 +3.3VD 9/29/03 10/9/03 ABT16244...
  • Page 197 REVISIONS DRAFTER Q.C. DESCRIPTION CHECKER AUTH. CHANGED PER DCR 020913-00 11/05/02 12/20/02 11/06/02 12/20/02 CHANGED PER DCR 030307-00 5/2/03 5/20/03 5/14/03 5/20/03 CHANGED PER DCR 030626-00 9/29/03 10/9/03 DSPA_A[19:0] 10/2/03 10/9/03 +3.3VD VDDQ DSPA_A14 DSPA_A13 DSPA_D31 ADDR23 DATA47 DQ31 DSPA_D30 DSPA_AD10 ADDR22 DATA46...
  • Page 198 REVISIONS DRAFTER Q.C. DESCRIPTION CHECKER AUTH. CHANGED PER DCR 020913-00 11/05/02 12/20/02 11/06/02 12/20/02 CHANGED PER DCR 030307-00 5/2/03 5/20/03 5/14/03 5/20/03 CHANGED PER DCR 030626-00 9/29/03 10/9/03 10/2/03 10/9/03 DSPB_A[14:0] +3.3VD +3.3VD RP12 RP12 RP12 VDDQ DSPB_A14 DSPB_A13 EBOOT LBOOT BMS STATE DSPB_D31 ADDR23...
  • Page 199 REVISIONS DRAFTER Q.C. DESCRIPTION CHECKER AUTH. CHANGED PER DCR 020913-00 11/05/02 12/20/02 11/06/02 12/20/02 CHANGED PER DCR 030307-00 5/2/03 5/20/03 +3.3VD 5/14/03 5/20/03 CHANGED PER DCR 030626-00 9/29/03 10/9/03 10/2/03 10/9/03 DSPASEL/ DSPABLDATA7 [9/C2] SPIDS L0DAT07 DSPASPICLK DSPABLDATA6 [8/C8,9/C2] SPICLK L0DAT06 DSPARXD DSPABLDATA5...
  • Page 200 REVISIONS DRAFTER Q.C. +3.3VD +3.3VD DESCRIPTION CHECKER AUTH. CHANGED PER DCR 020913-00 11/05/02 12/20/02 VDDEXT1 11/06/02 12/20/02 VDDEXT1 VDDEXT2 GND1 VDDEXT2 GND1 CHANGED PER DCR 030307-00 VDDEXT3 GND2 5/2/03 5/20/03 VDDEXT3 GND2 VDDEXT4 GND3 VDDEXT4 GND3 VDDEXT5 GND4 5/14/03 5/20/03 VDDEXT5 GND4 VDDEXT6...
  • Page 201 REVISIONS DRAFTER Q.C. DESCRIPTION CHECKER AUTH. CHANGED PER DCR 020913-00 11/05/02 12/20/02 +3.3VD +2.5VD 11/06/02 12/20/02 CHANGED PER DCR 030307-00 +3.3VD 5/2/03 5/20/03 +2.5VD 5/14/03 5/20/03 SPICLK R109 3.3K 3.3K 3.3K 3.3K 3.3K 3.3K CHANGED PER DCR 030626-00 +3.3VD CRST 9/29/03 10/9/03 3.3K...
  • Page 202 REVISIONS DRAFTER Q.C. DESCRIPTION +3.3VD +2.5VD CHECKER AUTH. +5VD CHANGED PER DCR 020913-00 +3.3VD 11/05/02 12/20/02 11/06/02 12/20/02 +3.3VD CHANGED PER DCR 030307-00 5/2/03 5/20/03 VCCO 3.3V VCCINT 2.5V R148 FPGA_CCLK R158 [1/A6] R149 XFLASH_CCLK CCLK [10/D8] 5/14/03 5/20/03 R131 R129 R134 R133...
  • Page 203 REVISIONS DRAFTER Q.C. DESCRIPTION FPGA FLASH PROM (for development only) CHECKER AUTH. CHANGED PER DCR 020913-00 11/05/02 12/20/02 11/06/02 12/20/02 FPGA PROGRAMMING PORT +5VD +3.3VD +3.3VD CHANGED PER DCR 030307-00 5/2/03 5/20/03 5/14/03 5/20/03 CHANGED PER DCR 030626-00 9/29/03 10/9/03 VCCO YEL CCLK 10/2/03...
  • Page 204 REVISIONS DRAFTER Q.C. DESCRIPTION CHECKER AUTH. CHANGED PER DCR 020913-00 11/05/02 12/20/02 11/06/02 12/20/02 EXPA[17:0] EXP0 6 RP32 EXPA0 [10/B8] CHANGED PER DCR 030307-00 5/2/03 5/20/03 EXPB[17:0] 5 RP32 EXPB0 [10/B6] 5/14/03 5/20/03 EXP1 7 RP32 EXPA1 CHANGED PER DCR 030626-00 9/29/03 10/9/03 8 RP32...
  • Page 205 REVISIONS DRAFTER Q.C. DESCRIPTION CHECKER AUTH. ANALOG BOARD CONNECTORS +5VD CHANGED PER DCR 020913-00 11/05/02 12/20/02 RS-232 TRANSCEIVER RS-232 11/06/02 12/20/02 (FEMALE) MAX202E RESET CHANGED PER DCR 030307-00 +5VD [1/A3] 5/2/03 5/20/03 ADA_VC_SEL/ [9/B2] 4.7K 4.7K ADA_LATCH DE9F [9/B2] 5/14/03 5/20/03 ADA_SCLK [9/B2]...
  • Page 206 REVISIONS DRAFTER Q.C. DESCRIPTION CHECKER AUTH. +5VD CHANGED PER DCR 020913-00 11/05/02 12/20/02 11/06/02 12/20/02 CHANGED PER DCR 030307-00 5/2/03 5/20/03 BAV99 2.2K .01/50 +5VD 5/14/03 5/20/03 33PF CHANGED PER DCR 030626-00 9/29/03 10/9/03 1/4W SPDIF_COAX_IN[4:1] SPDIF_COAX_IN1 10/2/03 10/9/03 [9/C7] 74HCU04 74HCU04 +5VD...
  • Page 207 REVISIONS DRAFTER Q.C. DESCRIPTION CHECKER AUTH. CHANGED PER DCR 020913-00 11/05/02 12/20/02 11/06/02 12/20/02 CHANGED PER DCR 030307-00 5/2/03 5/20/03 5/14/03 5/20/03 CHANGED PER DCR 030626-00 9/29/03 10/9/03 10/2/03 10/9/03 REMOTE POWER CONTROL DRIVERS +3.3VD REMOTE_PWREN1 [2/C3] 74VHC04 +15V CASE=GND ON-OFF VOUT LM2941CT...
  • Page 208 REVISIONS DRAFTER Q.C. DESCRIPTION CHECKER AUTH. CHANGED PER DCR 020913-00 11/05/02 12/20/02 11/06/02 12/20/02 CHANGED PER DCR 030307-00 5/2/03 5/20/03 +5VD 5/14/03 5/20/03 +15V CHANGED PER DCR 030626-00 9/29/03 10/9/03 10/2/03 10/9/03 1N4002 1N4002 78L05 VOUT COMMON .1/25 2 3 6 7 10/10 +5V_A VCOA_5V...
  • Page 209 REVISIONS DRAFTER Q.C. DESCRIPTION CHECKER AUTH. CHANGED PER DCR 020913-00 11/05/02 12/20/02 11/06/02 12/20/02 CHANGED PER DCR 030307-00 5/2/03 5/20/03 +5VD 5/14/03 5/20/03 +15V CHANGED PER DCR 030626-00 9/29/03 10/9/03 10/2/03 10/9/03 1N4002 1N4002 78L05 VOUT COMMON .1/25 2 3 6 7 10/10 +5V_B VCOB_5V...
  • Page 210 REVISIONS DRAFTER Q.C. DESCRIPTION CHECKER AUTH. CHANGED PER DCR 020913-00 2.5V REGULATOR 11/05/02 12/20/02 11/06/02 12/20/02 +2.5VD CHANGED PER DCR 030307-00 5/2/03 5/20/03 +5VD +2.5VD 5/14/03 5/20/03 CHANGED PER DCR 030626-00 9/29/03 10/9/03 LM2937 VOUT 10/2/03 10/9/03 TERM POWER CONNECTOR 4.7/6.3 47/16 +5VD...
  • Page 211 REVISIONS DRAFTER Q.C. DESCRIPTION CHECKER AUTH. CHANGED PER DCR 020913-00 11/05/02 12/20/02 11/06/02 12/20/02 CHANGED PER DCR 030307-00 5/2/03 5/20/03 5/14/03 5/20/03 CHANGED PER DCR 030626-00 9/29/03 10/9/03 10/2/03 10/9/03 +5VD REAR PANEL IR INPUT GPIU281 IR_IN2 [9/C8] 2.2K SHIELD BAV99 BAV99 FP_IR_BLINK...
  • Page 212 REVISIONS DRAFTER Q.C. DESCRIPTION +3.3V CHECKER AUTH. +3.3VD CHANGED PER DCR 020913-00 11/05/02 12/20/02 11/06/02 12/20/02 CHANGED PER DCR 030307-00 5/2/03 5/20/03 C124 C136 C145 C150 .1/25 .1/25 .1/25 .1/25 .1/25 .1/25 .1/25 .1/25 .1/25 .1/25 .1/25 .1/25 5/14/03 5/20/03 CHANGED PER DCR 030626-00 9/29/03 10/9/03...
  • Page 213 REVISIONS DRAFTER Q.C. DESCRIPTION CHECKER AUTH. CHANGED PER DCR 021028-00 11/4/02 11/6/02 11/5/02 11/6/02 CHANGED SHEET 4 PER DCR 030320-00 3/24/03 3/26/03 3/25/03 3/27/03 CHANGED SHEETS 2 & 4 PER DCR 030821-00. 9/19/03 11/17/03 9/23/03 9/26/03 IR/ENCODER BOARD CONNNECTOR +5VD FP_IR_IN1 IR_ACK_LED FP_ENCB_IN...
  • Page 214 REVISIONS DRAFTER Q.C. DESCRIPTION CHECKER AUTH. CHANGED PER DCR 021028-00 11/4/02 11/6/02 11/5/02 11/6/02 ADDED JTAG RES. PER DCR 030821-00. 9/19/03 11/17/03 9/23/03 9/26/03 LED[12:0] [4/B7] +3.3VD ABT16244 LED0 +5VD LED1 LED2 LED3 FP_SDATA_IN [1/C4] SDATI FP_SDATA_OUT [1/C4] SDATO ABT16244 LED_ROW0 LED4 IO410...
  • Page 215 REVISIONS DRAFTER Q.C. DESCRIPTION CHECKER AUTH. SWITCHCOL_[2:0] SWITCHCOL_2 [2/B4] CHANGED PER DCR 021028-00 11/4/02 11/6/02 1N914 11/5/02 11/6/02 SWITCHCOL_1 1N914 SWITCHCOL_0 1N914 STDBY MAIN DVD1 Z2 DVD1 Z3 DVD1 TUNER 1 TUNER 3 SROW_0 SROW_8 SROW_0 SROW_8 SROW_0 SROW_8 SROW_0 SROW_8 SROW_0 SROW_8...
  • Page 216 REVISIONS DRAFTER Q.C. DESCRIPTION CHECKER AUTH. LEDCOL2 [2/C2] CHANGED PER DCR 021028-00 11/4/02 11/6/02 LEDCOL1 [2/C2] LEDCOL0 11/5/02 11/6/02 [2/C2] CHANGED LED COLOR SCHEME 3/24/03 3/26/03 MDVD1 Z2DVD1 Z3DVD1 PER DCR 030320-00 3/25/03 3/27/03 LED0 LED0 LED0 CHANGED RESISTORS PER DCR 030821-00. 9/19/03 11/17/03 MDVD2...
  • Page 217 REVISIONS DRAFTER Q.C. DESCRIPTION CHECKER AUTH. +15V LEFT ANALOG INPUTS +15V -15V 0dBFS=4.0Vrms CHANGED PER DCR 021107-00 11/14/02 11/20/02 +15V 11/20/02 11/21/02 DG408 MAIN SOURCE SELECT LEFT CHANGED PER DCR 030407-00 TL072 5/21/03 5/23/03 10/25 BAV99 1/4W 5/23/03 5/23/03 CHANGED PER DCR 030729-00 LEFT_MAIN_IN 9/29/03 10/7/03...
  • Page 218 REVISIONS DRAFTER Q.C. DESCRIPTION CHECKER AUTH. +15V RIGHT ANALOG INPUTS +15V -15V 0dBFS=4.0Vrms CHANGED PER DCR 021107-00 11/14/02 11/20/02 +15V MAIN SOURCE SELECT RIGHT 11/20/02 11/21/02 DG408 CHANGED PER DCR 030407-00 TL072 5/21/03 5/23/03 10/25 BAV99 1/4W 5/23/03 5/23/03 CHANGED PER DCR 030729-00 RIGHT_MAIN_IN 9/29/03 10/7/03...
  • Page 219 REVISIONS +15V +15V +5VD DRAFTER Q.C. DESCRIPTION CHECKER AUTH. R368 DG411 RIAA_L MC33078 CHANGED PER DCR 021107-00 [15/B3] 11/14/02 11/20/02 LEFT_PHONO_IN 4.02K R369 LEFT_MAIN_IN [1/D3,4/D8] 11/20/02 11/21/02 4.02K L PHONO INPUT CHANGED PER DCR 030407-00 +5VD 5/21/03 5/23/03 +15V R366 R367 -15V RIAA_LRET...
  • Page 220 REVISIONS +15V DRAFTER Q.C. DESCRIPTION CHECKER AUTH. 0dBFS=2.0Vrms MAIN INPUT LEVEL CONTROL CHANGED PER DCR 021107-00 11/14/02 11/20/02 LEFT_MAIN_IN MC33078 [1/D3,3/D3] R254 RIGHT_MAIN_IN 11/20/02 11/21/02 +5VA [2/D3,3/D3] 1.00K R256 CHANGED PER DCR 030407-00 R255 +5VD 5/21/03 5/23/03 +15V 100K C343 1.00K 5/23/03 5/23/03...
  • Page 221 REVISIONS DRAFTER Q.C. DESCRIPTION CHECKER AUTH. C/SUB INPUT LEVEL CONTROL CHANGED PER DCR 021107-00 11/14/02 11/20/02 +5VA 11/20/02 11/21/02 CHANGED PER DCR 030407-00 C327 5/21/03 5/23/03 +15V 5/23/03 5/23/03 CHANGED PER DCR 030729-00 C326 9/29/03 10/7/03 +5VA CENTER_IN MC33078 R242 [1/B3] 10/6/03 10/7/03...
  • Page 222 REVISIONS DRAFTER Q.C. DESCRIPTION CHECKER AUTH. RIGHT_SIDE_IN_HALF CHANGED PER DCR 021107-00 [9/C7] 11/14/02 11/20/02 LEFT_SIDE_IN_HALF [9/D7] 11/20/02 11/21/02 SIDE INPUT LEVEL CONTROL CHANGED PER DCR 030407-00 5/21/03 5/23/03 LEFT_SIDE_IN 5/23/03 5/23/03 +5VA [1/A3] RIGHT_SIDE_IN CHANGED PER DCR 030729-00 [2/A3] 9/29/03 10/7/03 C335 +5VD...
  • Page 223 REVISIONS DRAFTER Q.C. DESCRIPTION CHECKER AUTH. +15V +5VD CHANGED PER DCR 021107-00 +15V 11/14/02 11/20/02 DG411 11/20/02 11/21/02 LEFT_PHONO75_IN CHANGED PER DCR 030407-00 MC33078 R236 [3/C6,4/D8] 5/21/03 5/23/03 LEFT_REC_IN_HALF [7/B7] +5VD 1.00K 5/23/03 5/23/03 +15V R238 R237 CHANGED PER DCR 030729-00 PHONO 75U INPUT 100K 1.00K...
  • Page 224 +5VD REVISIONS +15V DRAFTER Q.C. DESCRIPTION +5VD +5VA +5VR CHECKER AUTH. REC D/A CONVERSION DG411 CHANGED PER DCR 021107-00 11/14/02 11/20/02 L_REC_DACOUT FB15 +6.7dB [7/C8,8/C7] 11/20/02 11/21/02 C277 C273 C270 +15V 0dBFS=1.98Vrms 0dBFS=4.3Vrms CHANGED PER DCR 030407-00 5/21/03 5/23/03 330/6.3 R213 R210 MC33078...
  • Page 225 REVISIONS DRAFTER Q.C. DESCRIPTION +5VD +15V CHECKER AUTH. CHANGED PER DCR 021107-00 0dBFS=4.3Vrms 11/14/02 11/20/02 DG411 11/20/02 11/21/02 REAR OUTPUT L_REC_DAC L_ZONE_DACOUT [8/D4] [9/B7] CHANGED PER DCR 030407-00 5/21/03 5/23/03 LEVEL CONTROL 5/23/03 5/23/03 +5VA CHANGED PER DCR 030729-00 9/29/03 10/7/03 C312 10/6/03...
  • Page 226 REVISIONS DRAFTER Q.C. DESCRIPTION CHECKER AUTH. LEFT & RIGHT FRONT D/A CONVERSION +15V 0dBFS=1.98Vrms +11.2dB 0dBFS=7.2Vrms CHANGED PER DCR 021107-00 11/14/02 11/20/02 +5VD C256 +5VA +5VR R232 R193 11/20/02 11/21/02 NE5532A +15V +5VD 68.1 CHANGED PER DCR 030407-00 330/6.3 R194 5/21/03 5/23/03 FB19...
  • Page 227 REVISIONS DRAFTER Q.C. CENTER & SUB D/A CONVERSION DESCRIPTION +15V 0dBFS=1.98Vrms CHECKER AUTH. +11.2dB 0dBFS=7.2Vrms +5VD CHANGED PER DCR 021107-00 +5VA +5VR 11/14/02 11/20/02 C250 R228 R183 NE5532A +15V +5VD 11/20/02 11/21/02 68.1 330/6.3 R184 FB18 CHANGED PER DCR 030407-00 C207 1.15K 5/21/03...
  • Page 228 REVISIONS LEFT & RIGHT SIDE D/A CONVERSION DRAFTER Q.C. +15V DESCRIPTION 0dBFS=1.98Vrms 0dBFS=7.2Vrms +11.2dB CHECKER AUTH. +5VD +5VA +5VR C244 CHANGED PER DCR 021107-00 R224 R173 11/14/02 11/20/02 NE5532A +5VD +15V 68.1 11/20/02 11/21/02 330/6.3 R174 FB17 1.15K C201 CHANGED PER DCR 030407-00 ADG451 C293 C289...
  • Page 229 REVISIONS DRAFTER Q.C. LEFT & RIGHT REAR D/A CONVERSION +15V DESCRIPTION 0dBFS=1.98Vrms +11.2dB 0dBFS=7.2Vrms CHECKER AUTH. +5VD +5VA +5VR C238 CHANGED PER DCR 021107-00 R220 R163 11/14/02 11/20/02 NE5532A +5VD +15V 68.1 11/20/02 11/21/02 330/6.3 R164 FB16 1.15K C195 CHANGED PER DCR 030407-00 C285 C281 C278...
  • Page 230 REVISIONS DRAFTER Q.C. DESCRIPTION CHECKER AUTH. CHANGED PER DCR 021107-00 11/14/02 11/20/02 11/20/02 11/21/02 CHANGED PER DCR 030407-00 5/21/03 5/23/03 +3.3VD +3.3VD 5/23/03 5/23/03 CHANGED PER DCR 030729-00 XC9572XL 9/29/03 10/7/03 VCCIO1 VCCINT1 VCCIO2 VCCINT2 10/6/03 10/7/03 VCCIO3 VCCINT3 VCCIO4 MAIN_ANLG_SEL0 O__0_0 [1/D5,2/D5]...
  • Page 231 REVISIONS CLOCK BUFFERS R396 DRAFTER Q.C. DESCRIPTION MAIN_FS256/ CHECKER AUTH. CONNECTORS TO AMPS DIGITAL CONNECTOR +3.3VD 74LCX14 68.1 CHANGED PER DCR 021107-00 FROM MAIN BOARD 11/14/02 11/20/02 L_FRONT_AMP FB24 [10/B2] R395 +3.3VD MAIN_ADC_MCKI 11/20/02 11/21/02 R295 [4/A4] FB21 MAIN_FS256/ 74LCX14 68.1 CHANGED PER DCR 030407-00 5/21/03...
  • Page 232 REVISIONS DRAFTER Q.C. DESCRIPTION CHECKER AUTH. +5VD CHANGED PER DCR 021107-00 12V FOR TUNER MODULE +5VA 11/14/02 11/20/02 +15V 11/20/02 11/21/02 +5VD +12V CHANGED PER DCR 030407-00 5/21/03 5/23/03 +5VD SOURCE +5VA 1N4002 +5VD +12V 5/23/03 5/23/03 FB25 CHANGED PER DCR 030729-00 CASE=VOUT 9/29/03 10/7/03...
  • Page 233 REVISIONS DRAFTER Q.C. DESCRIPTION CHECKER AUTH. CHANGED PER DCR 021107-00 11/14/02 11/20/02 11/20/02 11/21/02 CHANGED PER DCR 030407-00 5/21/03 5/23/03 +15V +15V BYPASS CAPACITORS 5/23/03 5/23/03 CHANGED PER DCR 030729-00 9/29/03 10/7/03 C100 C102 C106 C108 C110 C133 C138 C143 C147 C149 C151...
  • Page 234 REVISIONS DRAFTER Q.C. DESCRIPTION CHECKER AUTH. CHANGED PER DCR 030106-00 1/13/03 1/23/03 1/21/03 1/23/03 S-VIDEO INPUTS +5VV +5VV CHANGED PER DCR 030421-00 5/20/03 5/22/03 2N3904 2N3904 5/20/03 5/22/03 CHANGED PER DCR 030623-00 .1/25 10/8/03 10/16/03 [2/B8,3/B8,4/B8] 75.0 75.0 [2/C8,3/C8,4/C8] SC1B [2/B8,3/B8] 10/9/03 10/16/03...
  • Page 235 REVISIONS +5VV +5VV SY_MAIN1_D DRAFTER Q.C. +3.3VD DESCRIPTION [5/C8] R204 CHECKER AUTH. VIDR MAX4310 [8/C8] R144 74HC4051 CHANGED PER DCR 030106-00 1/13/03 1/23/03 SHDN OSD_Y_IN OSD_SY_OUT CVID4 [5/C8,7/D8] [7/C2] 1/21/03 1/23/03 [1/A6,3/D8,4/D8] R145 CVID2 [1/A6,3/D8,4/D8] BPCOR SY_MAIN1 CHANGED PER DCR 030421-00 [8/A5] 5/20/03 5/22/03...
  • Page 236 REVISIONS +3.3VD DRAFTER Q.C. DESCRIPTION CHECKER AUTH. 74HC4051 CHANGED PER DCR 030106-00 1/13/03 1/23/03 CVID4 R150 1/21/03 1/23/03 [1/A6,2/D8,4/D8] CVID2 [1/A6,2/D8,4/D8] CHANGED PER DCR 030421-00 6.8K 5/20/03 5/22/03 +5VV +5VV CVID1 [1/A6,2/D8,4/D8] OUT/IN 5/20/03 5/22/03 R151 CVID3 MAX4310 [1/A6] CHANGED PER DCR 030623-00 CVID5 10/8/03 10/16/03...
  • Page 237 REVISIONS DRAFTER Q.C. DESCRIPTION CHECKER AUTH. CHANGED PER DCR 030106-00 1/13/03 1/23/03 1/21/03 1/23/03 CHANGED PER DCR 030421-00 5/20/03 5/22/03 +3.3VD 5/20/03 5/22/03 74HC4051 CHANGED PER DCR 030623-00 10/8/03 10/16/03 +5VV CVID4 [1/A6,2/D8,3/D8] 10/9/03 10/16/03 CVID2 [1/A6,2/D8,3/D8] AD8072 CVID1 [1/A6,2/D8,3/D8] SYZON2 OUT/IN 47/16...
  • Page 238 REVISIONS DRAFTER Q.C. DESCRIPTION CHECKER AUTH. CHANGED PER DCR 030106-00 1/13/03 1/23/03 +3.3VD +3.3VD VIDEO DECODER VIDEO ENCODER 1/21/03 1/23/03 CHANGED PER DCR 030421-00 R230 R231 5/20/03 5/22/03 5/20/03 5/22/03 VID_I2C_SDATA [10/A6] CHANGED PER DCR 030623-00 10/8/03 10/16/03 VID_I2C_SCLK [10/A6] 10/9/03 10/16/03 SDA_D...
  • Page 239 REVISIONS COMPONENT ENCODER FILTERS DRAFTER Q.C. DESCRIPTION CHECKER AUTH. +5VV +5VV CHANGED PER DCR 030106-00 1/13/03 1/23/03 +3.3VD MAX4310 120PF 1/21/03 1/23/03 SHDN DAC_Y CHANGED PER DCR 030421-00 [5/C3] 5/20/03 5/22/03 CNV_Y R106 2.7UH 2.7UH 3.3VA_B CNV_Y1 R101 R104 [6/C2,6/C5,] 5/20/03 5/22/03 75.0...
  • Page 240 REVISIONS DRAFTER Q.C. DESCRIPTION CHECKER AUTH. +5VV CHANGED PER DCR 030106-00 +5VV 1/13/03 1/23/03 C123 R184 1/21/03 1/23/03 R190 +5VV 4.75K .1/25 4.75K CHANGED PER DCR 030421-00 5/20/03 5/22/03 R191 OSD_Y_IN LF353 [2/D5,5/C8] 5/20/03 5/22/03 470K 47/16 R189 CHANGED PER DCR 030623-00 10/8/03 10/16/03 2.15K...
  • Page 241 REVISIONS DRAFTER Q.C. DESCRIPTION CHECKER AUTH. CHANGED PER DCR 030106-00 1/13/03 1/23/03 1/21/03 1/23/03 +5VV CHANGED PER DCR 030421-00 5/20/03 5/22/03 5/20/03 5/22/03 +15V CHANGED PER DCR 030623-00 +5VAS 10/8/03 10/16/03 1N4002 1N4002 10/9/03 10/16/03 78L05 VOUT COMMON C136 C137 2 3 6 7 .1/25 10/10...
  • Page 242 REVISIONS +3.3VD DRAFTER Q.C. DESCRIPTION CHECKER AUTH. CHANGED PER DCR 030106-00 1/13/03 1/23/03 1/21/03 1/23/03 D[7:0] [7/B3] CHANGED PER DCR 030421-00 5/20/03 5/22/03 VIDEO_DATA 5/20/03 5/22/03 [10/A5] SDATI VIDEO_SCLK 0xA2 [10/A5] SDATCLK , GCK1 CHANGED PER DCR 030623-00 10/8/03 10/16/03 OSD_CS/ 10/9/03 10/16/03...
  • Page 243 REVISIONS DRAFTER Q.C. DESCRIPTION CHECKER AUTH. CHANGED PER DCR 030106-00 1/13/03 1/23/03 1/21/03 1/23/03 +3.3VD CHANGED PER DCR 030421-00 5/20/03 5/22/03 5/20/03 5/22/03 3.3V REGULATOR 3.3VD_E CHANGED PER DCR 030623-00 VDDX_E VSSX_E 10/8/03 10/16/03 C141 C142 +5VV +3.3VD VDDI_E VSSI_E0 10/9/03 10/16/03 .1/25...
  • Page 244 DIGITAL ANALOG CHASSIS POWER GROUND GROUND GROUND GROUND 5 LAST REFERENCE DESIGNATORS USED: C5, D1, FB1, J1, L1, R1, U1. © 2003 Lexicon, Inc. CONTRACT exicon 3 OAK PARK BEDFORD, MA 01730 TITLE APPROVALS DATE DRAWN SCHEM, VCO BD, MCLK...
  • Page 245 GROUND GROUND GROUND GROUND 2 LAST REFERENCE DESIGNATORS USED: BP2,C2 470PF/100 470PF/100 3 COMPONENTS MARKED WITH ARE NOT INSTALLED. © 2003 Lexicon, Inc. CONTRACT exicon 3 OAK PARK BEDFORD, MA 01730 TITLE APPROVALS DATE SCHEM,SPKR EMI FILTER BD, RV8 DRAWN...
  • Page 248 Harman Specialty Group 3 Oak Park, Bedford, MA, 01730-1413 USA Customer Service: Telephone: 781-280-0300 | Service Fax: 781-280-0499 | www.lexicon.com Part No. 070-17537 | Rev 0...

Table of Contents

Save PDF
