Specifications

960L MAINFRAME
ANALOG INPUT
Connectors
Impedance
Level (for 0 dbFS)
Freq Response @48K
Freq Response @96K
A/D Conversion
A/D Dyn Range
THD
CMRR
Crosstalk @ 1Khz
ANALOG OUTPUT
Connectors
Impedance
Level (at 0 dBFS)
Freq Response @48K
Freq Response @96K
D/A Conversion
8x oversampled @ 44.1/48kHz
4x oversampled @ 88.2/96kHz
D/A Dyn Range
THD
Crosstalk @ 1kHz
A/A PERFORMANCE
Freq Response @48K
Freq Response @96K
Dyn Range
THD
DIGITAL AUDIO IO
Connectors
Format
Word Size
SAMPLE RATES
Internal
Accuracy
External
Lock Range
Eight, Female XLR
50K Ohm, balanced
+24dBu
20Hz--20KHz, ±1dB
20Hz-40KHz, ±1dB
24 bits
128x oversampled
>110 dB (20-20kHz)
<.002%
>50dB
< -100dB
Eight, Male XLR
50 Ohm, balanced
+24dBu
20Hz-20Khz, ±1dB
20Hz-40Khz, ±1dB
24 bits
>110 dB (20-20kHz)
<.002%
< -100dB
20Hz-20Khz, ±1dB
20Hz-40Khz, ±1dB
>107 dB (20-20kHz)
<.002%
Four Male XLR Outputs
Four Female XLR Inputs
AES/EBU
24 bits
44.1/48/88.2/96kHz
within ±10ppm
44.1/48/88.2/96kHz
±1%
Home Next Page >>
GROUP DELAYS (MILLISECONDS)
44.1 kHz 48 kHz
A/D 1.44
A/A 2.42
D/A 1.59
D/D 0.54
SYNCHRONIZATION
TTL Word Clock Input *
TTL Word Clock Output*
(*Falling edge marks start of frame)
CLOCK JITTER
Intrinsic
Jitter Gain
CONTROL INTERFACES
LARC2 Ports
MIDI **
(**supports program change)
ALGORITHMS
Ambience
Chamber
Plate
Reverse
Random Hall
Ambient Chamber
STANDARD HARDWARE CONFIGURATIONS
DSP/CPU Card Compartment
Standard I/O Card Configurations
Option A:
Option B:
Storage Media
<< Go Back
Appendix
88.2 kHz 96 kHz
1.33 0.81 .0.74
2.23 1.80 1.66
1.42 1.35 1.25
0.50 0.36 0.33
75 Ohm, BNC
self-terminating loopthru
Low Z, BNC
Exceeds AES3 Amendment 1
Exceeds AES3 Amendment 1
In/Out/Thru
(48K Stereo & Surround)
(48K Stereo & Surround)
(48K Stereo & Surround)
(48K Stereo & Surround)
(48/96K Stereo & Surround)
(48K Surround)
One System CPU Card
One Reverb DSP Car d
Two Spare DSP card slots
One MIDI Card
Analog Input Card
Analog Output Card
AES/EBU Digital I/O Card
I/O Clock Card
Spare I/O Card slot
AES/EBU Digital I/O Card
I/O Clock Card
Three Spare Slots
Hard Disk
3.5" Floppy Disk Drive
CD-ROM Drive
2
A-19
