Using the Documentation
This addendum to the 960L Owner's Manual contains information about the 960L Version 2.5 software. It covers features
of Version 2.5 that differ from previous Version 2 software releases (such as Versions 2.20, 2.21, 2.22, and 2.4). Refer to the
960L Owner's Manual for general information and operating instructions.
About Version 2.5
The 960L Version 2.5 software contains several new Delay algorithms, as well as additional 96kHz Reverb algorithms. The
list below highlights Version 2.5 features:
Stereo Delay Algorithms
•
Simple Delays
•
Dual Delays
•
Random Delays
•
Stereo Frame Delay
Multi-Channel Delay Algorithms
•
Simple Surround Delays
•
Random Surround Delays
•
Surround Frame Delay
•
Octal Frame Delay (8x8 configuration only)
•
Octal Zone Delay (8x8 configuration only)
New Stereo 96kHz Reverb Algorithms
•
Chamber
•
Plate
A Harman International Company
Lexicon Part No. 070-14825 | Rev 0 | 07/01
960L Version 2.5
New Multi-Channel Reverb Algorithms
•
Surround Chamber
•
Surround Plate
Stereo Delay Factory Programs
•
Eight banks contain new preset programs that utilize
the Stereo Delay algorithms listed here. There is also a
bank
programs are described in detail later in this
document (see page 9).
Multi-Channel Factory Programs
•
Five banks contain new preset programs that utilize
the Multi-channel Delay algorithms listed here. These
programs are described in detail later in this
document (see page 13).
Lexicon, Inc.
Tel 781-280-0300
3 Oak Park
Fax 781-280-0490
Bedford, MA 01730-1441
USA
www.lexicon.com
Owner's Manual Addendum
containing
480L
Delay
Customer Support
Tel 781-280-0300
Fax 781-280-0495 (Sales)
Fax 781-280-0499 (Service)
programs.
These
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 960L V2.5 - ADDENDUM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lexicon 960L V2.5 - ADDENDUM

Summary of Contents for Lexicon 960L V2.5 - ADDENDUM

  • Page 1 (see page 13). • Plate Lexicon, Inc. Tel 781-280-0300 Customer Support 3 Oak Park Fax 781-280-0490 Tel 781-280-0300 Bedford, MA 01730-1441 Fax 781-280-0495 (Sales) www.lexicon.com Fax 781-280-0499 (Service) A Harman International Company Lexicon Part No. 070-14825 | Rev 0 | 07/01...

  • Page 2: Delay Algorithms

    Version 2.5 Software Release Lexicon, Inc. Ctr In Adjusts center input level (this is only available Delay Algorithms in 5-channel configurations). Unless the center channel audio is discrete, it is recommended to set the center input 6dB below the InLvl SIMPLE DELAYS parameter setting.

  • Page 3: Dual Delays

    Version 2.5 Software Release 960L General Parameters DUAL DELAYS FbkMST Controls the level of all feedbacks AND The Dual Delay algorithm is similar to Simple Delay, except crossfeeds. with two delay lines for each input channel. Each voice has independent delay time, output level, feedback Grain Provides further control of the input diffusor.

  • Page 4: Random Delays

    Early Reflection Modeling - Although very different in above, Dual Delay features two randomizers. Voices can scope from Lexicon's Ambience algorithms, Random be assigned to either randomizer or no randomizer at all. Delay can be used to carefully place early reflections The randomizer provides up to one second of additional in a stereo or surround field.
  • Page 5 Version 2.5 Software Release 960L Parameters Delay Voice Parameters Works like the Crossfeed parameter in Delay, Please refer to the parameter section for Simple Delay and except for the target. The crossfeed data is Dual Delay. This section will only describe parameters not sent to the opposite corner.

  • Page 6: Delay Tools

    Version 2.5 Software Release Lexicon, Inc. Delay Tools FRAME DELAY The Frame Delay algorithm is intended for use primarily in video post-production applications. It allows audio to be ZONE DELAY delayed in order to maintain synchronization with video. The Zone Delay algorithm is intended primarily for use in The Frame Delay is available in all configurations of the live sound applications.

  • Page 7: User Interface Enhancements

    Version 2.5 Software Release 960L User Interface Enhancements The 960L user interface features several enhancements that support Delay algorithms. To simplify delay algorithm editing, the algorithm parameters have been grouped into two separate Edit screens: the Delay Voice Screen and the Standard Algorithm Edit screen.
  • Page 8 Version 2.5 Software Release Lexicon, Inc. All other parameters in the delay algorithm are contained on the Standard Algorithm Edit screen shown below (Figure 2). Figure 2 - Standard Algorithm Edit Screen To select between these two screens, use the following...
  • Page 9 Version 2.5 Software Release 960L New Version 2.5 Factory Programs Stereo Bank 13: Simple Delays Simple delays. Number Name Algorithm Description Simple Delay Simple Delay A simple delay. DelMST sets overall delay time. The first four faders set individual left and right taps. Filtered Delay Simple Delay A filtered delay.

  • Page 10: Stereo Bank 15: Dual Delays

    Version 2.5 Software Release Lexicon, Inc. Stereo Bank 15: Dual Delays Dual Delays, many rhythmic presets. Number Name Algorithm Description 1/2 Delay Dual Delay 1/2 note feel. DelMST sets overall delay time. 1/4 Delay Dual Delay 1/4 note feel. DelMST sets overall delay time.

  • Page 11: Stereo Bank 17: Random Delays

    Version 2.5 Software Release 960L Stereo Bank 17: Random Delays Delays that make use of randomizers to create interesting effects. Number Name Algorithm Description Nice Delays Random Delay Works great on anything that needs subtle, nice delays - vocals, acoustic guitar, piano, etc. Going Inside Random Delay Nice early delays.

  • Page 12: Stereo Bank 19: 480 Delays

    Version 2.5 Software Release Lexicon, Inc. Stereo Bank 19: 480 Delays True to the original. Number Name Algorithm Description 4-Voice Double Random Delay Delay voices are doubled in stereo. When added to a dry signal, it’s crisp, wide, and uncluttered.

  • Page 13: Surround Bank 13: *Simple Delays

    Version 2.5 Software Release 960L Surround Bank 13: *Simple Delays Basic surround delays. Number Name Algorithm Description Nice Delay Random Surround A nice delay for surrounds. Good all around. Adds a great Delay sense of space in surrounds. Whispers Random Surround Whispers around you.

  • Page 14: Surround Bank 14: *Random Delays

    Version 2.5 Software Release Lexicon, Inc. Surround Bank 14: *Random Delays Surround delays that make use of randomizers. Number Name Algorithm Description Warm Delay Random Surround A nice surround delay with mild use of randomizers. Delay DelMST sets overall delay time.

  • Page 15: Surround Bank 15: *Delay Spaces

    Version 2.5 Software Release 960L Surround Bank 15: *Delay Spaces Surround delay spaces. The reflections of a space without the reverb. Number Name Algorithm Description Golden Room Random Surround 62ft wide and 100ft deep (the Golden Mean). DelMST Delay controls size. FbkMST controls liveness. Narrow Room Random Surround At maximum size, this room is 100ft long and only 25 feet...
  • Page 16 Version 2.5 Software Release Lexicon, Inc. Surround Bank 16: *Crazy Delays From strange to insane. Number Name Algorithm Description Metal Landscape Random Surround Crazy ring-mod taps with high feedback create a Delay metallic atmosphere. Joystick drastically changes mood. Dispersal Random Surround A set of really long delay taps spread out.

  • Page 17: Simple Delay Algorithm

    Version 2.5 Software Release 960L Algorithm Diagrams SIMPLE DELAY ALGORITHM 2 Delay Channels, 1 Pannable Delay Voice per Channel, 4 second Maximum Delay Left in Right in Channel A Input Channel B Input Output & & Dif ... .Diffusion HF .

  • Page 18: Dual Delay Algorithm

    Version 2.5 Software Release Lexicon, Inc. DUAL DELAY ALGORITHM 4 Delay Channels, 1 Pannable Delay Voice per Channel, 2 second Maximum Delay Left in Right in Xfeed Xfeed Xfeed Xfeed Output & & & & & & & & Dif ... .Diffusion Fil .

  • Page 19: Random Delay Algorithm

    Version 2.5 Software Release 960L RANDOM DELAY ALGORITHM 2 Delay Channels, 3 Pannable Delay Voices per Channel, 3 second Maximum Delay, 1 second Random Delay Left in Right in Fbk 1-3 Fbk 1-3 Xfeed 1-3 Xfeed 1-3 Fil Fil Fil Fil Fil Fil Output &...

  • Page 20: Simple Multi-Channel Delay Algorithm

    Version 2.5 Software Release Lexicon, Inc. SIMPLE MULTI-CHANNEL DELAY ALGORITHM 4 Delay Channels, 1 Pannable Delay Voice per Channel Left in Ctr in Right in Left Surround in Right Surround in Output & & & & Dif ... .Diffusion Fil .

  • Page 21: Random Multi-Channel Delay Algorithm

    Version 2.5 Software Release 960L RANDOM MULTI-CHANNEL DELAY ALGORITHM 4 Delay Channels, 3 Pannable Delay Voices per Channel Left in Ctr in Right in Left Surround in Right Surround in FSLvl FSLvl Xfeed Xfeed Xfeed RS V Xfeed LS V Left Right Fil Fil Fil...
  • Page 22 Version 2.5 Software Release Lexicon, Inc. Notes...
  • Page 23 Version 2.5 Software Release 960L Notes...
  • Page 24 Version 2.5 Software Release Lexicon, Inc. Notes (continued)
