Lexicon 960L Owner's Manual page 100

Appendix
Specifications
960L Mainframe (cont.)
REVERB CARD CONFIGURATIONS (PER CARD)
48K
Stereo Machines
1-In / 2-Out Machines
2-In / 5-Out Machines
4-In / 4-Out Machines
5-In / 5-Out Machines
96K
Stereo Machines
1-In / 2-Out Machines
2-In / 5-Out Machines
4-In / 4-Out Machines
5-In / 5-Out Machines
INTERNAL HARD DISK STORAGE
Factory Programs
User Registers
REMOVABLE 3.5" FLOPPY DISK STORAGE
User Registers
POWER
Requirements
Connector
*** Selector switch included on some units
DIMENSIONS
Rack Units
Size
WEIGHT
REGULATORY APPROVALS
FCC
CE
UL
cUL
TUV
ENVIRONMENT
Operating
Storage
Humidity
A-20
Four
Four
Two
Two
Two
Two
Two
One
One
One
240
1000
100
100-120 / 220-240 VAC ***
50-60Hz, 300W max
3-pin IEC
4U
19.0" W x 7.0" H x 17.4" L
(483mm x 178mm x 442mm)
35 lbs
Class A
EN55103-1, EN55103-2
UL1419
C22.2
EN60065
10 to 40 °C
-30 to 70 °C
95% max, non-condensing
Home
LARC2 REMOTE
DISPLAY
Type
Resolution
Colors
Backlight
Contrast
Brightness
LED METER BRIDGE
Configuration
Levels
CONTROL SURFACE
Faders
60mm throw, motorized, touch sensitive
Joystick
Dedicated Function Keys
Soft Buttons
CONNECTORS
960L
Aux. PS/2 Keyboard
Ext. Power
OPERATING DISTANCE
With power from 960L
With Ext. Power
POWER
Requirements
DIMENSIONS
Size
Weight
REGULATORY APPROVALS
FCC
CE
TUV
ENVIRONMENT
Operating
Storage
Humidity
<< Go Back
Next Page >>
Lexicon, Inc.
Passive Matrix LCD
640x240
256
Fluorescent
HW controlled (rear panel)
SW controlled
8 channels x 3 levels
-60dBFS (Signal)
-6dBFS
-0.5dBFS (Overload)
Two axis
29 (12 backlit)
9-pin D-sub
6-pin Mini-DIN
concentric, 2.5mm
up to100 feet
up to1,000 feet
12 VDC, 2 A (max)
12.7" L x 8.25" W x 5.0" H
(323mm x 210mm x 127mm)
4 lbs
Class A
EN55103-1, EN55103-2
EN60065
5 to 40 °C
-30 to 70 °C
95% max, non-condensing
8
8
