Operations in Detail

Loading Registers

Loading Registers is similar to loading Programs. Press the
REGISTER key instead of the PROGRAM key. This will bring
up a similar screen (Fig. 4-2). The only differences are the
use of the word "Register" instead of "Program" and the
addition of two soft buttons for labeling. Any selection that
is greyed out, on any screen, is unavailable. Programs and
Registers can be unavailable if they are empty or if they
are designed for sample rates and configurations that are
not currently selected.
Alternative Loading Techniques:
• You can use the Left/Right Navigation Arrows to
move between Banks and Programs (or Banks
and Registers).
• You can use the +/- buttons or the Up/Down
Arrows to scroll through Banks.
• You can use the +/- buttons or the Up/Down
Arrows to scroll though Programs and Registers.
Press the ENTER key to load the Program.
• You can repeatedly press BANK, PROGRAM or
REGISTER to scroll through the Banks, Programs
and Registers.
4-4
Shortcut:
You can instantly load any Program or Register in
the current Bank by pressing the corresponding
key on the Numeric Keypad.
Figure 4-2 — Register Load Screen
Programming Machines:
Depending on the configuration (see below), the
960L can be used as one, two, or four processing
machines per DSP card. The number of machines
available in the current configuration is shown on
the Machine Status Display. The machine whose
settings you are currently altering is highlighted.
Machines that are muted have a blinking red "M"
super-imposed on their machine number.
You must program each machine individually. To
switch to a different machine, press and hold the
MACHINE key, then enter the desired machine
number on the Numeric Keypad.
