Ruler

To create a ruler, open the Object pop-up menu by clicking
Object on the Sonar Operating Panel (or the right mouse
button), and select New ruler in the Object pop-up menu.
To open the Ruler dialogue, click on the ruler with the Select
button.
The Ruler dialogue provides information about the currently
selected ruler, its length and angle. The same information is also
provided next to the ruler on the display.
The Delete button allows you to remove the ruler from the
display.
Related topics
→
Object pop-up menu, page 82
→
Sonar Operating Panel; Select, page 37
