Display

The Display menu is shown in all display modes, and provides
access to parameters controlling the visual presentation of the
sonar views. Some of the choices on the menu are simple on/off
buttons.
Full Screen - Replica of the Menu button on the Sonar
Operating Panel.
Audio Mute - Replica of the Mute button on the Sonar
Operating Panel.
Resolution - Select 16 or 64 colours in the display presentation.
The chosen resolution is shown in the colour bar below the
button.
Other display parameters
→
Palette, page 130
→
Display Gain, page 111
→
Colour Threshold, page 105
→
Colours, page 106
→
Panel backlight, page 131
→
Mode buttons, page 128
→
Language, page 124
→
Units, page 161
→
Cosmetics, page 74
→
Bearing, page 103
→
Menu, page 125
The Help button opens the on-line help.
