Page 1 Operator manual Simrad SP70 Operator manual...
Page 3 Simrad SP70 sonar Operator manual 850- -164186 / AA000 / N/A...
Page 4 Note Simrad AS makes every effort to ensure that the information contained within this document is correct. However, our equipment is continuously being improved and updated, so we cannot assume liability for any errors which may occur. Warning The equipment to which this manual applies must only be used for the purpose for which it was designed.
Page 5 Operator manual Sections This document is the Operator manual for the Simrad SP70. sonar system. It provides the information and technical specifications necessary to operate the various system components. System description Modes of operation Operation Menu description Maintenance 850--164186 A...
Page 6 Simrad SP70 Remarks References Further information about the SP70 system may be found in the following manuals: • SP70 Installation manual Note This manual includes sections that may be revised individually. In the event of a revision to any part of this manual, this “Cover and Contents” section will be replaced.
Page 7: Table Of Contents
Operator manual Table of contents SYSTEM DESCRIPTION ........Introduction .
Page 8 Simrad SP70 Main switch ......... . .
Page 9 Operator manual GeoView index menu ........VerticalView index menu .
Page 10 Simrad SP70 Stabilizer ..........
Page 11 Operator manual Wheelhouse units ..........Cleaning .
Page 12 Simrad SP70 Document revisions Date Written by Checked by Approved by 18.04.01 SØJ SØJ (The original signatures are recorded in the company’s logistic database.) To assist us in making improvements to the product and to this manual, we would welcome comments and constructive criticism. Please send all such - in writing or by...
Page 13: System Description
System description 1 SYSTEM DESCRIPTION Introduction The Simrad SP70 sonar is a long range omnidirectional sonar, designed for medium and large sized fishing vessels, both purse seiners and trawlers. The standard frequency is 26kHz (triple and multiple frequency as option), and the beam can be electronically tilted from +10°...
Page 14: System Overview
Simrad SP70 System overview Main units The Simrad SP70 sonar consists of the following units: • Wheelhouse units: - Display Monitor - Operating Panel - Processor Unit - Loudspeaker • Sonar room units: - Transceiver Unit - Hull Unit See figure 1 for the SP70 system diagram.
Page 15 System description Display Monitor 115/230Vac mains Operating panel Processor unit Loudspeaker 115/230Vac mains Speed log Echo sounder Course gyro Trawl system Purse seine system Transceiver Unit Hull Unit 115/230Vac mains (CD5719 WMF/GIF) 230/380/440Vac 3 phase mains Figure 1 - SP70 system diagram 850--164186 A...
Page 16: Options
Note that all options are pre- programmed into the standard version, where a code word is used to make the actual option operable. Simrad offer a 1- month free test period for each option. For entering the code words, refer to the section; “Option →...
Page 17: Optional Triple-- Or Multiple--Frequency
System description In the 180_ /Vertical and Omni/Vertical modes, a trainable 180_ vertical slice is presented. Refer to section; ”Modes of operation” on page 10. → Optional triple- - or multiple- -frequency In addition to the standard 26kHz frequency, options are available triple multiple...
Page 18: Functional Principles
Simrad SP70 Functional principles When the Omni beam is tilted, the total beam picture can be compared with folding an umbrella, which means that all beams in 360_ around the vessel have the same tilt angle. Figure 3 - Omni beam In the standard version, the beam can be tilted from +10_ up, to - 60_ down.
Page 19 System description Figure 4 - Vertical slice Figure 5 - OMNI / vertical combination For the optional 90_ tilt version, the OMNI/vertical combination is used in several display modes to give the best situation overview for both purse seiners and trawlers. In these presentations the seine net and the trawl can be seen in relation to the vessel, the school of fish and the bottom.
Page 20: Reception
Simrad SP70 Reception A great effort has been made to reduce unwanted noise to get a clean and stable echo presentation. To achieve this goal the sonar receiver has the following filtering possibilities: FM CORRELATION FILTER In addition to the traditional single frequency transmitting method, the SP70 sonar is equipped with an FM correlation mode.
Page 21: Transmission
• Simrad echo sounder (EQ, ES and EK series). Gives depth readout in the menu and a bottom plot on the catch data page. • Simrad PI30 Purse Seine System. Gives the net depth in digits and bars on the vertical views.
Page 22: Modes Of Operation
Simrad SP70 2 MODES OF OPERATION General This chapter describes the SP70 modes. The various modes represent the graphical presentation of sonar data. Several display modes is generated for giving the best possible overview presentation and a flexible choice for a large range of user applications.
Page 23 Modes of operation In most display modes with multiple views, the size of each view can easily be modified by moving the boundary line between the views: Locate the cursor on the boundary line, press Select and move the cursor with the Select button in the inner position. When the Select button is released, the boundary line will be located to the actual cursor position.
Page 24: Bow Up
Simrad SP70 Bow Up Figure 6 - Bow up When the Bow Up mode is selected the vessel symbol is stationary on the screen, with the bow pointing upwards. The echo presentation covers 360° around the vessel, and all echoes will be updated for each ping.
Page 25: North Up
Modes of operation North Up Figure 7 - North up When the North Up mode is selected, true north is always up on the screen and the vessel symbol is stationary with the bow pointing in the direction of the course. The movement of the echoes across the screen will be a combination of the vessel course and speed, and the targets own movement.
Page 26: True Motion
Simrad SP70 True Motion Figure 8 - True motion When the True Motion mode is selected, the picture is locked to a geographical position, where the vessel moves around the screen according to its course and speed. All echoes are always in...
Page 27: 180_ / Audio
Modes of operation 180° / Audio Figure 9 - 180° / Audio When the 180° / Audio mode is selected, the upper half of the screen shows a 180° bow up presentation, while the lower part is used for a recording of the audio channel. The audio channel is shown with a continuous white line in the horizontal picture, and can be trained in any direction.
Page 28: 180_ / Echosounder (Option)
Simrad SP70 180° / Echosounder (Option) Figure 10 - 180° / Echo sounder When the 180° / Echosounder mode is selected, the upper half of the screen shows a 180° bow up presentation, while the lower part is used for an echo sounder recording. That means that the sonar acts alternately as a normal sonar and an echo sounder for each second transmission.
Page 29: 180_ / Vertical (Option)
Modes of operation 180° / Vertical (Option) Figure 11 - 180° / Vertical (option) When the 180° / Vertical mode is selected, the upper half of the screen shows a 180° bow up presentation, while the lower part is used for a vertical slice presentation. In that way an echo can simultaneously be presented in both horizontal and vertical dimensions.
Page 30 Simrad SP70 In addition to the normal tilt indicator, the tilt angle is also shown in the vertical slice by a continuous white line. In that way, it is easy to select the optimal tilt angle on an echo in the vertical slice, to get the best drawing of the echo in the horizontal presentation.
Page 31: 270_ / Vertical
Modes of operation 270° / Vertical Figure 12 - 270° / Vertical The 270° / Vertical mode is specially made for purse seining, where the vertical half slice is displayed in the lower left corner for normal setting of the net on starboard side. If the net is selected to be set on the port side, the vertical half slice will be displayed in the lower right- hand corner.
Page 32: Omni / Vertical (Option)
Simrad SP70 Omni / Vertical (Option) Figure 13 - Omni / Vertical (option) The Omni / Vertical mode is specially made for trawling, where a complete overview of the horizontal and vertical situation is presented. The bearing of the vertical slice on the right- hand side is as in 180°/Vertical mode indicated by the white audio line, while the...
Page 33: Omni / Echosounder (Option)
Modes of operation 2.10 Omni / Echosounder (Option) Figure 14 - Omni / Echo sounder The Omni / Echosounder mode is also specially made for trawling, but in this mode the trawl- locked vertical slice is replaced by an echo sounder recording. This to ensure a more correct depth indication in case the sonar beam is bent because of temperature layers.
Page 34: 2.11 Bow Up / Vertical
Simrad SP70 2.11 Bow Up / Vertical Figure 15 - Bow Up / Vertical When the Bow Up / Vertical mode is selected the picture is divided into three sections; where the left side is a bow up presentation equal to the bow up presentation described previously.
Page 35: 2.12 True Motion / Vertical
Modes of operation 2.12 True Motion / Vertical Figure 16 - True Motion / Vertical When the True Motion / Vertical mode is selected, the picture is divided into three sections; where the left side is a true motion presentation equal to the true motion presentation described previously.
Page 36: 2.13 Dual
Simrad SP70 2.13 Dual Figure 17 - Dual operation The Dual mode is a kind of “two sonars in one” operation, where each presentation part is updated for each second transmission. All settings can be set separately for each presentation part. This makes the dual mode especially useful for optimizing settings by directly comparing the two presentations.
Page 37: Operation
Operation 3 OPERATION Introduction All operation of the sonar is normally made from the Sonar Operating Panel. This section contains a detailed description of the start/stop procedures, the Operating Panel and the menu operation. In order to get the necessary understanding of the sonar working principle, read first through the section “System Description”.
Page 38: Procedures
Simrad SP70 Procedures Start procedure Note ! Before starting up the sonar, check that the depth is sufficient, and that the vessel’s speed is within the maximum speed specified with the transducer lowered. Start up the display monitor by pressing the POWER button on the monitor.
Page 39: Stop Procedure
S102 at the rear of the Sonar Processor Unit to the OFF position. This is because the transducer can be damaged by transmitting in air. SIMRAD (CD5880) S102 Figure 19 - Rear side of the Processor Unit...
Page 40: The Sonar Operating Panel
Simrad SP70 The Sonar Operating Panel SIMRAD MAIN SW. MODE GAIN RANGE CURSOR SYMBOL Mode POWER Gain Gain Range Range Menu Select View Object Mode Mode Gain Gain Range Range Middle Mode Down TILT VARIOUS TRAIN Position Manual Zoom Manual...
Page 41 Operation MAIN SW. Figure 21 - Main switch buttons Middle Down Raises the transducer to its upper position. The adjacent green LED blinks while the transducer is raised and remains illuminated once it is housed safely inside the hull of the vessel. The green blinking LED will also be accompanied by an audible signal selected in the Alarm menu.
Page 42: Symbol
Simrad SP70 Symbol Symbol functions provide on- screen graphic references for: targets, own ship and fishing gear SYMBOL Target marker Own ship marker Figure 22 - Symbol buttons Circle marker Gear symbol TARGET MARKER To mark a target, move the cursor over the desired target and press the triangular icon button.
Page 43 Is a useful aid in providing an overview of the trawl operation. Trawl data can be set manually using the menu or automatically by interfacing the SIMRAD FS trawl sonar or ITI trawl monitoring system with the Sonar Processor Unit.
Page 44: Mode
Simrad SP70 Mode Mode selection can be performed using the menu or the main control panel which contains four operator selectable Mode buttons. MODE Mode Mode Figure 23 - Mode buttons Mode Mode Frequently used modes that are task- specific to particular phases of the fishing operation can be pre- set in the Sort Modes menu.
Page 45: Gain
Operation Gain Gain controls are specified as either horizontal or vertical. GAIN Gain Gain Figure 24 - Gain buttons Gain Gain HORIZONTAL GAIN The two upper buttons control receiver gain effecting the horizontal presentation of the sonar. The level of gain selected is display in the Horizontal index menu and on top of the tilt indicator in the upper left- hand side of the display.
Page 46: Range
Simrad SP70 Range Range controls are specified as either horizontal or vertical. RANGE Range Range Figure 25 - Range buttons Range Range HORIZONTAL RANGE The two upper buttons control the horizontal range. The range selected is display in the Horizontal index menu and on top of the tilt indicator in the upper left- hand side of the display.
Page 47: Cursor
Operation Cursor The cursor is used for on screen cursor orientation and menu operation. CURSOR Menu Select Object View SONAR OPERATING PANEL Figure 26 - Cursor and related buttons MENU The Menu button is used for selection between Menu or Full Screen presentations.
Page 48 Simrad SP70 ROLLER BALL The roller ball controls the cursor which changes appearance in relation to its location on the screen as follows: • Orange cursor in the echo field. • An arrow in the menu field. • A negative or positive sign and an arrow at the ends of menu buttons in the menu field.
Page 49: Tilt Controls
Operation Tilt controls Tilt can be electronically adjusted from +10_ to - 60_ with the standard version and +10_ to - 90_ with the 90_ tilt version. The tilt angle is normally displayed on the tilt indicator in the upper left- hand corner of the screen in addition to the menu.
Page 50 Simrad SP70 • Position tracking mode: the tilt angle’s centre will automatically be adjusted with regard to the distance to the position being tracked. The transducer will tilt automatically in steps after each transmission. • Target tracking mode: the tilt angle will automatically be adjusted to provide the strongest echo within the selected tracking sector.
Page 51: Various
Operation Various The buttons grouped under various are: Zoom, Record, Mute and Off Centre. VARIOUS Figure 28 - Various buttons Record Centre ZOOM The zoom function magnifies an area of the display by positioning the cursor in its centre and pressing the Zoom button. The zoom button works as a toggle switch for on/off of the zoom function.
Page 52: Train
Simrad SP70 Train The audio channel is displayed as a continuous white line and can be trained either manually or automatically. The bearing angle is displayed in the upper right- hand corner of the display, indicated relative to the bow.
Page 53 Operation TARGET TRACK To track a target, place the cursor over the desired location and press the Target Track button. A circle will appear on the display and its position automatically tracked by the system using the strongest echo centred in the ”window” represented by two lines on the audio line.
Page 54: Menu Operation
Simrad SP70 Menu operation Menu- - and Full Screen presentation The menu field can be selected to be present stationary on the display, or to be present only when needed for changing parameter settings. The Menu button on the operating panels used for selection between the Menu or Full Screen presentation.
Page 55 Operation Figure 31 - Full screen presentation without menu Figure 32 - Full screen presentation with menu 850--164186 A...
Page 56: Menu Structure
Simrad SP70 Menu structure The menu field contains different menu buttons with the following structure: Figure 33 - The menu field (CD5765A) The upper menu button indicates the sonar in operation. The second menu button is used for display mode selection.
Page 57: Menu Buttons
Operation Note that the menu contains different menu indexes for each display mode. In the example in the figure, which shows the 180°/vertical/echo sounder mode, most menu indexes are shown. In order to select a new menu index, move the cursor to the menu index, and press Select.
Page 58 Simrad SP70 CURSOR Menu Select View Object SONAR OPERATING PANEL Figure 35 - The menu operating controls When the submenu for a menu button is selected, the parameters can be changed in two different ways: Refer to figure 36. →...
Page 59 Operation (C 5768) Figure 36 - Operation with submenu Note that some of the menu buttons (example Range, Gain, Tilt etc.) have a dual operation, and will normally be operated from the operating panel. In such case, the parameter value shown in the menu button will change according to the panel operation.
Page 60: Menu Description
Simrad SP70 4 MENU DESCRIPTION Introduction This section gives a detailed description of the complete menu system for the SP70 sonar, and contains the chapters listed below. For an explanation of how to operate the menu system, refer to the section “Menu Operation”.
Page 61: Alphabetical List Of Parameters
Menu description Alphabetical list of parameters The following is an overview of available parameters incorporated in the SP70 sonar system. - A - AGC, see page 98. → Audio volume, see page 101. → - B - Bearing, see page 89. →...
Page 62 Simrad SP70 Movements, see page 122. → - N - - P - Palette, see page 102. → Panel backlight, see page 106. → Ping Sector, see page 95. → PP Filter, see page 100. → Pulse Form, see page 92.
Page 63 Menu description Wind Marker, see page 134. → Wind Speed, see page 151. → - Z - Zoom Expansion, see page 152. → Zoom Scale, see page 153. → 850--164186 A...
Page 64: Menu Structure
Simrad SP70 Menu structure This chapter gives a description of the configuration of the main menu for sonar. Below the figure a page reference is given for the different menus in the following chapters. Figure 37 - The menu field (CD5765) Sonar type, see page 53.
Page 65: Sonar Type
Menu description Sonar type Figure 38 - SP70 button The upper menu button is only a sonar type indicator. Mode selection Figure 39 - Mode button The standard SP70 sonar with 60° tilt, has eight different operational modes. If the optional 90° tilt version is installed, four extra display modes will be available.
Page 66: Index Menus
Simrad SP70 For changing the order of the display modes: Sort Display Modes, see page 69. → Index menus The sonar contains a number of Index menus. The Index menus are show with vertical index cards on the right hand side in the field menu, and can easily be selected by roller ball and the Select button on the operating panel.
Page 67: Status Menu
Menu description Status menu The Status menu is the default submenu displayed in the lower, right- hand corner of the screen. Figure 42 - The status menu The Status view can not be closed, but if an other submenu is selected it will be overwritten.
Page 68: Active Index Menus
Simrad SP70 Active Index menus The active index menus are all the menus relevant for the different display modes. The index menus are shown with vertical index cards on the right hand side in the menu field, and can easily be selected by the roller ball and the select button.
Page 69: Horizontal Index Menu
Menu description Horizontal index menu The Horizontal index menu is used for the horizontal sonar presentation, which is present in all display modes. When any horizontal settings are selected in one mode, these settings will be applied to all modes. Figure 43 - Horizontal index menu...
Page 70: Vertical Index Menu
Simrad SP70 Vertical index menu The Vertical index menu is only shown in modes with a vertical slice function. All relevant settings, except the TX Power, can be selected separately for the vertical modes independent of the horizontal settings. When any vertical settings are selected in one mode, these settings will be applied to all vertical modes.
Page 71: Display Index Menu
Menu description Display index menu The Display index menu is shown in all display modes, and gives access to parameters controlling the visual presentation of the sonar views. Figure 45 - Display index menu • Full Screen - Replica of the Menu button on the operating panel.
Page 72: Setup Index Menu
Simrad SP70 Setup index menu The Setup index menu is shown in all display modes, and gives access to parameters controlling processing and algorithms to the sonar system. Figure 46 - Setup index menu The following parameters are available: Store/Recall, see page 67.
Page 73: Objects Index Menu
Menu description Objects index menu The Objects index menu is shown in all display modes, and displays the range (R), bearing (B) and depth (D) to all selected objects. Figure 47 - Objects index menu The ID abbreviations for the different objects are: AT - Automatic Target Marker Ci - Circle Marker M - Target Marker...
Page 74: Echosounder Index Menu
Simrad SP70 Echosounder index menu The Echosounder index menu is only shown in the 180_/Echosounder mode. Figure 48 - Echosounder index menu The following parameters are available: Range, see page 87. → Bearing, see page 89. → Gain, see page 91.
Page 75: Trawl Index Menu
Menu description Trawl index menu The Trawl index menu is only shown in the Omni/Vertical mode. Figure 49 - Trawl index menu The following parameters are available: Range, see page 87. → Bearing, see page 89. → Gain, see page 91. →...
Page 76: Second Ping Index Menu
Simrad SP70 Second ping index menu The Second ping index menu is only shown in the Dual mode. Figure 50 - Second ping index menu The following parameters are available: Range, see page 87. → Tilt, see page 88. →...
Page 77: Temporary Index Menus
Menu description Temporary Index menus The Temporary Index menus are the index submenus selected from the active index menus. The index menus are shown with vertical index cards on the right hand side in the menu field, and can easily be selected by the roller ball and the select button. The Temporary Index menus can be removed by a Close button in the lower part of the index menu field.
Page 78: Cosmetics Index Menu
Simrad SP70 Cosmetics index menu The Cosmetics index menu is activated by the Cosmetics menu button in the Display index menu. Figure 51 - Cosmetics index menu The following parameters are available: Slant Range, see page 126. → Bearing card, see page 127.
Page 79: Store/Recall Index Menu
Menu description Store/Recall index menu The Store/Recall index menu is activated by the Store/Recall menu button in the Setup index menu. Figure 52 - Store/Recall index menu The Store/Recall index menu is used for storing either a sequence or single display pictures. The stored pictures can easily be recalled for evaluation or comparing schools.
Page 80: System Test Index Menu
Simrad SP70 System Test index menu The System Test index menu is activated by the Test menu button in the Setup index menu. Figure 53 - System Test index menu The following parameters are available: • Test Config. - Only to be activated by qualified service engineers.
Page 81: Sort Modes Index Menu
Menu description Sort Modes index menu The Sort Modes index menu is activated by the Sort Modes menu button in the Setup index menu. Figure 54 - Sort Modes index menu The Sort Modes index menu is used for selection of the display modes to be activated by the four Mode buttons on the operating panel.
Page 82: Object Menu
Simrad SP70 Object menu The Object menu is accessed using the Object button over the roller ball on the operating panel, or the right hand mouse button if an optional mouse is installed. Figure 55 - Object menu As most of the Object menu functions may be selected directly on the operating panel, this menu is mainly used when operating the sonar from an optional mouse.
Page 83 Menu description Figure 56 - Object menu (extended) Inspect When Inspect is selected, a submenu in the menu field with detailed information on the object at the cursor opens. Same function can be obtained by selecting an Objects Index menu. Delete When Delete is selected, the object will be deleted.
Page 84: View Menu
Simrad SP70 View Menu The View menu is accessed using the View button over the roller ball on the operating panel, or the centre mouse button if an optional mouse is installed. Figure 57 - View menu Activating the view menu in the Catch Data page, will display the following Reduced View menu.
Page 85 Menu description Make Same Size When Make Same Size is selected, window areas tiled vertically will acquire the same width. Grey scale data This command changes the display from a colour presentation to a black- and- white. The number of shades of grey and the number of different colours used will be the same.
Page 86: View Index Menus
Simrad SP70 View Index menus The View Index menus are activated from the lower line in the View Menu, which is accessed using the View button on the operating panel. The index menus are shown with vertical index cards on the right hand side in the menu field, and the menus can easily be removed by a Close button in the lower part of the index menu field.
Page 87: Geoview Index Menu
Menu description GeoView index menu The GeoView index menu is activated with the View menu button in the horizontal views. Figure 59 - GeoView index menu The following parameters are available: Scale, see page 147. → • Ship to centre - Moves the ship symbol to the centre of the view.
Page 88: Verticalview Index Menu
Simrad SP70 VerticalView index menu The VerticalView index menu is activated with the View menu button in the vertical views. Figure 60 - VerticalView index menu The following parameters are available: Zoom, see page 152. → Zoom Scale, see page 153.
Page 89: Echoview Index Menu
Menu description EchoView index menu The EchoView index menu is activated with the View menu button in the Echosounder view. Figure 61 - EchoView index menu The following parameters are available: Expansion, see page 145. → Start Range, see page 148. →...
Page 90: Trawlview Index Menu
Simrad SP70 TrawlView index menu The TrawlView index menu is activated with the View Menu button in the Trawl View. Figure 62 - TrawlView index menu The following parameters are available: Zoom, see page 152. → Zoom Scale, see page 153.
Page 91: Lowerview Index Menu
Menu description LowerView index menu The LowerView index menu is activated with the View menu button in the lower view of the Dual mode. Figure 63 - LowerView index menu The following parameters are available: Scale, see page 147. → •...
Page 92: Catchview Index Menu
Simrad SP70 CatchView index menu The CatchView index menu is activated with the View Menu button in the Catch View. Figure 64 - CatchView index menu The following parameter is available: Range (CatchView index menu), see page 146. → • Help - Displays the information you are now reading.
Page 93: Warnings And Alarms
Menu description Warnings and alarms Message Bar The Message Bar button is located in the System test index menu and activates the corresponding submenu. Figure 65 - Message Bar submenu The Message Bar submenu is used for selecting the level on which the warnings and alarms should be given.
Page 94: Warnings Index Menu
Simrad SP70 Warnings index menu The Warnings index menu is activated from the Message Bar. Figure 67 - Warnings index menu The Warnings index menu will display error messages. The message browsing dialogue lists all messages for the selected message category. The messages are time tagged and displayed in a descending order.
Page 95: Operator Alarms Index Menu
Menu description Operator alarms index menu The Operator alarms index menu is activated from the Message bar. Figure 68 - Operator alarms index menu The Operator alarms index menu will display error messages. The message browsing dialogue lists all messages for the selected message category.
Page 96: System Alarms Index Menu
Simrad SP70 System alarms index menu The System alarms index menu is activated from the Message Bar. Figure 69 - System alarms index menu The System alarms index menu will display error messages. The message browsing dialogue lists all messages for the selected message category.
Page 97: Errors Index Menu
Menu description Errors index menu The Errors index menu is activated from the Message Bar. Figure 70 - Errors index menu The Errors index menu will display error messages. The message browsing dialogue lists all messages for the selected message category.
Page 98: 4.10 Submenus
Simrad SP70 4.10 Submenus This chapter describes all submenus in the menu system. When the submenu for a menu button is selected, the available parameters for the actual button will be shown in the submenu. The menu settings marked with an asterisk, indicate the normal setting which perform well under normal conditions.
Page 99: Range
Menu description Range The Range button is located in the following index menus: • Horizontal • Vertical • Echosounder • Second Ping • Trawl Figure 71 - Range submenu Range is normally selected using the SP70 Operating Panel. The available choices are: 150, 300, 450,600, 900, 1200, 1500, 2000, 2500, 3500, 4500 and 6000 meters.
Page 100: Tilt
Simrad SP70 Tilt The Tilt button is located in the Horizontal index menu. Figure 72 - Tilt submenu The Tilt is normally controlled from the operating panel. On the standard version, the transducer can be tilted electronically from +10° up to - 60° down, and on the optional 90° tilt version, it may be tilted down to - 90°.
Page 101: Bearing (Horizontal)
Menu description Bearing (Horizontal) The Bearing button is located in the Horizontal index menu. Figure 73 - Bearing submenu The Bearing of the audio channel is normally controlled from the operating panel. The selected bearing is shown with a continuous white line out from the transducer position, and can be trained manually or automatically in any position.
Page 102: Bearing (Vertical)
Simrad SP70 Bearing (Vertical) The Bearing (Vertical) button is located in the Vertical index menu. Figure 74 - Bearing submenu The Bearing of the audio channel is normally controlled with the TRAIN buttons on the Operating Panel. The bearing of the...
Page 103: Gain
Menu description Gain The Gain button is located in the following index menus: • Horizontal • Vertical • Echosounder • Second Ping • Trawl Figure 75 - Gain submenu The Gain is normally selected from the operating panel. The gain has 51 values, numbered from 0 to 50, and the receiver gain is changed 1 dB per step.
Page 104: Pulse Form
Simrad SP70 Pulse Form The Pulse Form button is located in the following index menus: • Horizontal • Vertical • Echosounder • Second Ping • Trawl Figure 76 - Pulse Form submenu The Pulse Form submenu is used for selecting the form of the transmitter pulse.
Page 105 Menu description There is a selection between three different pulse lengths: short, normal and long. In addition the pulse length will change automatically in accordance with the selected range. The table shows the different pulse lengths for CW and FM. The pulse length in CW is given in milliseconds (ms).
Page 106: Tx Power
Simrad SP70 Tx Power The Tx Power button is located in the following index menus: • Horizontal • Vertical • Echosounder • Second Ping • Trawl Figure 77 - TX Power submenu The TX Power is used for selecting the transmitter output power.
Page 107: Ping Sector
Menu description Ping Sector The Ping Sector button is located in the Horizontal index menu and opens the corresponding submenu. Figure 78 - Ping Sector submenu The Ping Sector is defined as the sector covered by one ping. The size of the sector can be selected between 360° (Omni) and 11° (single beam).
Page 108: Frequency (Option)
If only the standard 26 kHz frequency is installed, Simrad offers a one- month free test period for the multiple frequencies. 850--164186 A...
Page 109: Tvg (Time Variable Gain)
Menu description TVG (Time Variable Gain) The TVG button is located in the following index menus: • Horizontal • Vertical • Echosounder • Second Ping • Trawl Figure 80 - TVG submenu The TVG controls the gain in the signal amplifier. The gain is weakest just after the ping, and increases in accordance with time (and therefore range).
Page 110: Agc (Automatic Gain Control)
Simrad SP70 AGC (Automatic Gain Control) The AGC button is located in the following index menus: • Horizontal • Vertical • Echosounder • Second Ping • Trawl Figure 81 - AGC submenu The AGC (Automatic Gain Control) adjusts the gain in the sonar’s preamplifier dependant on the strength of the incoming...
Page 111: Rcg (Reverberation Controlled Gain)
Menu description RCG (Reverberation Controlled Gain) The RCG button is located in the following index menus: • Horizontal • Vertical • Echosounder • Second Ping • Trawl Figure 82 - RCG submenu The RGC (Reverberation Controlled Gain) regulates the receiver gain individual for each of the 64 receiving beams.
Page 112: Pp Filter
Simrad SP70 PP Filter The PP Filter button is located in the following index menus: • Horizontal • Vertical • Echosounder • Second Ping • Trawl Figure 83 - PP- filter submenu The PP Filter (Ping- to Ping filter) reduces unwanted noise and echoes from the screen.
Page 113: Audio Volume
Menu description Audio volume The Audio volume button is located in the Horizontal and Vertical index menus. Figure 84 - Audio Volume submenu The Audio Volume in the loudspeaker can be selected in 10 steps. The audio channel which represent this signal, is shown with a continual white line, and can be trained by the training controls.
Page 114: Palette
Simrad SP70 Palette The Palette button is located in the Display index menu and activates the corresponding submenu. Figure 85 - Palette submenu The Palette submenu is used for the selection of background colours and day/night brightness of the display.
Page 115: Display Gain
Menu description Display Gain The Display Gain button is located in the Display index menu and activates the corresponding submenu. Figure 86 - Display gain submenu The Display Gain increases or decreases the presentation of the echo colours in the display unit. In order to adjust the receiver gain, refer to the individually gain in the horizontal and vertical index menus.
Page 116: Colour Threshold
Simrad SP70 Colour Threshold The Colour Threshold button is located in the Display index menu and activates the corresponding submenu. Figure 87 - Colour Threshold submenu The Colour Threshold function is used for reducing the number of echo colours on the display. The strength of the echoes is presented by a scale of 16 or 64 colours on the display.
Page 117: Colours
Menu description Colours The Colours button is located in the Display index menu and activates the corresponding submenu. Figure 88 - Colours submenu The Colours strength of the echo presentation can be selected with three different colour scales. Under normal conditions, the NORMAL colours will give the best dynamic in the echo presentation.
Page 118: Panel Backlight
Simrad SP70 Panel Backlight The Panel backlight button is located in the Display index menu and activates the corresponding submenu. Figure 89 - Panel Backlight submenu The Panel Backlight controls the illumination on the keyboard on the operating panel in 8 steps (0 – 7).
Page 119: Language
Menu description Language The Language button is located in the Display index menu and activates the corresponding submenu. Figure 90 - Language submenu The Language menu is used for selecting the language of the menu text. Note that the on- line help text always will be in English.
Page 120: Units
Simrad SP70 Units The Units button is located in the Display index menu and is used for selecting the desired units on the display Figure 91 - Units menu The following Units options are available: • Range - Sets units for range •...
Page 121 Menu description Equipment This parameter sets units for Equipment. Figure 93 - Equipment submenu The following Equipment options are available: • Meter • Fathoms • US survey foot Depth This parameter sets units for Depth. Figure 94 - Depth submenu The following Depth options are available: •...
Page 122 Simrad SP70 Speed This parameter sets units for Speed. Refer to figure 95. → Figure 95 - Speed submenu The following Speed options are available: • m/s (metres per sec) • knots • km/h (kilometres per hour) Position This parameter sets units for Position.
Page 123 Menu description Temperature This parameter sets units for Temperature. Refer to figure 97. → Figure 97 - Temperature submenu The following Temperature options are available: • Celsius • Fahrenheit 850--164186 A...
Page 124 Simrad SP70 Menu The Menu button is located in the Display index menu and activates the corresponding submenu. Figure 98 - Menu submenu The Menu selection is used for selecting different levels of complexity of the menu system. 850--164186 A...
Page 125: Gear
Menu description Gear The Gear button is located in the Setup index menu and activates the Gear submenu. Figure 99 - Gear submenu The Gear menu is used for selecting the type of fishing gear and to get the right size and position of the gear on the display. In the next chapter “Edit Gear”...
Page 126: Edit Gear (Purse)
Simrad SP70 Edit Gear (Purse) The Edit gear (Purse) button is located in the Setup index menu and activates the Edit Gear purse submenu when one of the purse funtions is designated using the Gear button. Figure 100 - Edit...
Page 127 Menu description Length Figure 102 - Width submenu The following options are available: • - (minus button) - Reduces the selected value. • + (plus button) - Increases the selected value. • Close - Closes the submenu selecting the displayed value. •...
Page 128: Edit Gear (Trawl)
Simrad SP70 Edit Gear (Trawl) The Edit gear button is located in the Setup index menu and activates the Edit Gear submenu. Figure 104 - Edit Gear submenu The following options are available: • Distance - • Depth - • Height - •...
Page 129 Menu description Depth Figure 106 - Depth submenu The following options are available: • - (minus button) - Reduces the selected value. • + (plus button) - Increases the selected value. • Manual - Enables manual input of the selected value. •...
Page 130 Simrad SP70 Width Figure 108 - Width submenu The following options are available: • - (minus button) - Reduces the selected value. • + (plus button) - Increases the selected value. • Manual - Enables manual input of the selected value.
Page 131: School Data
Menu description School Data The School Data button is located in the Setup index menu. Figure 110 - School Data submenu The School Data menu is used to obtain information of the volume estimation of a school in the automatic target tracking program.
Page 132: Edit School
Simrad SP70 Edit school The Edit School button is located in the Setup index menu and activates the School Configuration submenu. Figure 111 - Edit School Data submenu The Edit School submenu displays the species of fish and its presently selected density. The density for the school volume estimation is based on kg/m@ school area.
Page 133: Stabilizer
Menu description Stabilizer The Stabilizer button is located in the Setup index menu. Figure 113 - Stabilizer button This function will only be operative if the optional stabilizer is connected. The stabilizer may be switched ON and OFF in the menu.
Page 134: Movements
Simrad SP70 Movements The Movements button is located in the Setup index menu. Figure 115 - Movements submenu The Movements function makes it possible to estimate the position of a tracked school at a given time (from one to ten minutes).
Page 135: Track Window
Menu description Track Window The Track Window button is located in the Setup index menu. Figure 116 - Track Window submenu The Track Window command enables the operator to adjust the track window size. A larger track window will enable the system to track a large target more easily, but the system will be more susceptible to background noise.
Page 136: External Synchronizing
The External Synchronizing button is located in the Setup index menu and activates the corresponding submenu. Figure 117 - External Synchronizing submenu The External synchronization function makes it possible to eliminate interference from other Simrad sonars on board the vessel. 850--164186 A...
Page 137: Default Setting
Setting dialogue The Default Setting function makes it possible to delete the memory of the selected settings and restore the Simrad Factory Default settings. These settings are marked with an asterisk in the different submenus and will perform well under normal condition.
Page 138: Slant Range/True Range
Simrad SP70 Slant Range/True Range The Slant Range/True Range button is located in the Cosmetics index menu. Slant Range Figure 119 - Slant Range In the Slant Range presentation the distance to the target is measured along the tilt angle.
Page 139: Bearing Card
Menu description Bearing Card The Bearing Card button is located in the Cosmetics index menu. Figure 122 - Bearing Card The Bearing Card is shown as short lines for each 10th degree along the outermost circle of the sonar view. It is updated when the heading of own ship has changed more than 1 degree.
Page 140: Compass Card
Simrad SP70 Compass Card The Compass Card button is located in the Cosmetics index menu and has an on/off function. Figure 123 - Compass Card ON The Compass Card is shown as short lines for each 10th degree along the outermost circle of the sonar view. A triangle symbol indicates each 45th degree.
Page 141: Distance Rings
Menu description Distance Rings The Distance Rings button is located in the Cosmetics index menu. Figure 124 - Distance Rings ON The Distance Rings is shown as dotted rings, each with a range readout on the left- hand side of the display centre. 850--164186 A...
Page 142: Vrm (Variable Range Marker)
Simrad SP70 VRM (Variable Range Marker) The VRM button is located in the View Area index menu. Figure 125 - VRM (Variable Range Marker) ON The VRM (Variable Range Marker) consists of an adjustable range ring with range readout and can be used for any type of distance marking relative to the vessel.
Page 143: Bow Marker
Menu description Bow Marker The Bow Marker button is located in the Cosmetics index menu. Figure 126 - Bow Marker ON The Bow Marker is a dotted line drawn from the bow of the own ship symbol equal to the vessel’s heading. 850--164186 A...
Page 144: Track History
Simrad SP70 Track History The Track History button is located in the Cosmetics index menu and activates the corresponding submenu. Figure 127 - Track history submenu Track History lines show the movement history of own ship as a line after the symbols. When Track History is selected, the length in time of the Track History lines can be set.
Page 145: Minute Marker
Menu description Minute Marker The Minute Marker button is located in the Cosmetics index menu. Figure 128 - Minute Marker button Minute markers are shown as small circles on the history lines of the ship. 850--164186 A...
Page 146: Wind Marker
Simrad SP70 Wind Marker The Wind Marker button is located in the Cosmetics index menu. Figure 129 - Wind Marker ON The Wind Marker is shown as an arrow drawn from the Compass Card pointing towards the centre of the display. It indicates from which direction the wind blows, and has a fixed length (not scaled according to the wind’s speed).
Page 147: Vertical Ring
Menu description Vertical Ring The Vertical Ring button is located in the Cosmetics index menu. Figure 130 - Vertical Ring button The Vertical Ring shows the selected range of the vertical slice as a white circle in the horizontal presentation. This will then be an indication of which distance a target should be presented in the vertical view.
Page 148: Store
Simrad SP70 Store The Store button is located in the Store/Recall index menu. Figure 131 - Store button The Store button is used for storage of a sequence loop or single display pictures, which can be selected in the Store mode menu.
Page 149: Recall
Menu description Recall The Recall button is located in the Store/Recall index menu. Figure 133 - Recall button When Recall is selected in the menu, the button can be used to start/stop of the recorded sequence, or for selection of new single pictures.
Page 150: Time And Date
Simrad SP70 Time and Date Time and Date functions are battery powered and stored in the memory when the sonar is switched off. Figure 135 - Time and date submenu The submenu is common for changing time and date settings. For time adjustments, use the cursor and select the actual digit.
Page 151: Transducer
Menu description Transducer The Transducer button is located in the Status menu. Figure 136 - Transducer submenu The Transducer position is normally selected from the operating panel, and in addition to the LED indicators on the panel, the transducer position will be indicated in the status menu. The OFF, UP, MIDDLE and DOWN functions in the transducer submenu correspond to their respective buttons on the Operating Panel and make it possible to make the selections via the roller- ball.
Page 152: Heading
Simrad SP70 Heading The Heading button is located in the Status view. Figure 137 - Heading submenu The Heading readout is a repetition of the connected course gyro input. Manual heading input may be used if signals from external sensors are missing.
Page 153: Speed
Menu description Speed The Speed button is located in the Status view. Figure 138 - Speed submenu The Speed readout is a repetition of the connected speed input source, which can be a separate speed log input or data from the connected (D)GPS.
Page 154: Data Source
Simrad SP70 Data Source The Data Source button is located in the Vertical- and Trawl- View index menus and activates the corresponding submenu. Figure 139 - Data Source submenu The Data Source menu is used for selecting the bearing source of the vertical views.
Page 155: Direction Indicator
Menu description Direction Indicator The Direction Indicator button is located in the Vertical- and Trawl- View index menus and activates the corresponding submenu. Figure 140 - Direction Indicator submenu The Direction Indicator menu will be shown if the data source for the Vertical- and Trawl- Views are selected to INDICATOR.
Page 156: Range (Echoview)
Simrad SP70 Range (EchoView) The Range (EchoView) button is located in the EchoView index menu and activates the corresponding submenu. Figure 141 - Range submenu The Range function is used to select the range of the vertical expansion in the Echo View.
Page 157: Expansion
Menu description Expansion The Expansion button is located in the EchoView index menu and activates the corresponding submenu. Figure 142 - Expansion submenu The Expansion function is used to expand the echo view around the trawl symbol or the bottom. To expand around the bottom, an external echosounder must be connected.
Page 158: Range (Catchview)
Simrad SP70 Range (CatchView) The Range (CatchView) button is located in the CatchView index menu. Figure 143 - Range submenu The Range in the CatchView may be selected manually or automatically. In Manual, the range scale can be selected between 200 meters and 1000 meters as indicated in the submenu.
Page 159: Scale
Menu description Scale The Scale button is located in the GeoView and LowerView index menus and activates the corresponding submenu. Figure 144 - Scale submenu The Scale of the horizontal presentations may be selected between 25% and 200%, where 100% is the default scale, 850--164186 A...
Page 160: Start Range
Simrad SP70 Start Range The Start Range button is located in the EchoView index menu and activates the corresponding submenu. Figure 145 - Start Range submenu The Start Range function is used to select the depth for the vertical expansion in the Echo View.
Page 161: Target Track (View Area)
Menu description Target Track (View area) The Target Track button is located in the GeoView and LowerView index menus. Figure 146 - Target Track submenu Target Track lines shows the movement history of targets as a line after the respective symbols. They are shown as straight line segments drawn between each position fix, with optional minute markers to be added for each minute along the line.
Page 162: Wind Direction
Simrad SP70 Wind Direction The Wind Direction button is located in the Setup index menu and activates the Wind Direction submenu Figure 147 - Wind Direction submenu The Wind Direction marker can be selected in the Cosmetics index menu. The wind marker is show in the outer area of the echo presentation as a white arrow.
Page 163: Wind Speed
Menu description Wind Speed The Wind Speed button is located in the Setup index menu and activates the Wind Speed submenu. Figure 148 - Wind Speed submenu The Wind Speed is not used as a parameter in the sonar, but is only a readout if a wind sensor is connected.
Page 164: Zoom
Simrad SP70 Zoom The Zoom button is located in the Vertical- and Trawl View index menus and activates the corresponding submenu. Figure 149 - Zoom submenu The Zoom function is used to zoom up vertical view around the trawl symbol or the bottom. To zoom up around the bottom, an external echo sounder must be connected.
Page 165: Zoom Scale
Menu description Zoom Scale The Zoom Scale button is located in the Vertical- and Trawl View index menus and activates the corresponding submenu. Figure 150 - Zoom Scale submenu The Zoom Scale is used for scaling the zoom around the Trawl symbol or the bottom.
Page 166: 4.11 Option Installation
→ Note that all options are pre- programmed into the standard sonar version, and that Simrad offer a 1- month free test period for each option. When ordering a permanent option installation, a code word will be released from Simrad.
Page 167 Menu description • Add License String is used for the permanent option installation. Pressing the menu button will activate the On- Screen Keyboard which is used to type the 32 character code word for the permanent option installation: Figure 153 - On- screen Keyboard •...
Page 168: Maintenance
For location and replacing of these, refer to the chapter for the unit in question. Major repairs and complete overhaul of the sonar, should be left to an authorized Simrad service engineer. Wheelhouse units Cleaning The units should be kept clean and dry.
Page 169: Transceiver Unit
Maintenances Transceiver unit Dust filter There is a dust filter in the bottom of the Transceiver Unit. To avoid overheating, this should be inspected, and if necessary, cleaned once every third month. The dust filter is accessible from the outside of the Transceiver Unit, by unscrewing the eight finger nuts in the bottom of the unit.
Page 170: Hull Unit
Simrad SP70 Hull unit General The sonar hull unit should be under continuous watch as a part of the vessel’s machinery. As it may be exposed to severe strain because of pitching and vibrations, it should be inspected for loose parts.
Page 171: Cleaning The Transducer
Maintenances Cleaning the transducer The transducer normally needs little attention. However, the transducer face should be inspected and cleaned when docking. Do not use strong solvents, but a normal synthetic soap and water. Marine growth should be carefully removed with fine- grade sandpaper or emery paper.
Page 172: Hoisting And Lowering With Hand Crank
Simrad SP70 hoisting spindle should lubricated with MOLYBDENUM DISULPHIDE GREASE. Topping up the shaft sleeve through the grease nipple is only required if the shaft is dry of lubrication, or if water tends to force its way up along the shaft. Remember to open the pressure let- down plug when topping up.
