6. Connect the Footstand

To connect the footstand to the support bar, follow these steps.

Locate the three hooks on the footstand.

Step 1

Position the hooks so that they align with the two open

Step 2

slots on the support bar.

Note

Insert the footstand hooks into the support bar and

Step 3

push in slightly to make the connection.

Slots on the support bar

Hooks on the footstand

Insert and rotate footstand to connect to support bar

There are four positions in each of the three

sets of open slots on the support bar. This lets

you choose the angle of the footstand.
