Wren Kitchens INFINITY Fittings Manual page 7

Adjusting the drawer frontal height
To adjust the height of the frontal, use a
screwdriver to loosen the screws on both
sides of the inside of the drawer box.
Adjust the frontal height, then re tighten the
screws to lock.
Push the supplied cover caps onto the
adjustment screw heads.
Attaching the frontal
The frontal should be re-attached to the unit
by clipping the hinges onto the hinge plates.
The bar of the hinge needs to be positioned
into the hooks on the hinge plate. Then the
rear of the hinge pushed to the hinge plate
until it clicks.
Adding the door buffers
Position 1x door buffer at the top and bottom
corners of the unit, as illustrated in the image.
