Appendix A: Protector Radioisotope Hood Components
Item Quantity
8A 1
8B 1
10A 1
10B 1
11A 1
11B 1
12A 1
12B 1
12C 1
12D 4
12E 4
13A 1
13B 1
13C 1
13D 1
14 4
15 2
16 2
17 2
18 4
19 4
20 2
21A 1
22 1
23 1
50
Part No. Description
9721901 Lamp, Fluorescent (T8 x 3') – use on 4' & 8' Hoods
9721900 Lamp, Fluorescent (T8 x 4') – use on 5' & 6' Hoods
1302300 Switch, Rocker
1327500 Switch, Plug (Fills cutout when switch is not used)
9818400 Access Cover
9825100 Label, Access Cover (includes all three corner labels)
9810800 Side Panel, 24" internal deep hoods – NOT SHOWN
9810801 Side Panel, 30" internal deep hoods – NOT SHOWN
9810802 Side Panel, 36" internal deep hoods – NOT SHOWN
1916400 Nut, Retainer #10-24 – NOT SHOWN
1885512 Screw, Machine #10-24 x .75 Truss Head Stainless – NOT SHOWN
9860000 Air Foil 4'
9860001 Air Foil 5'
9860002 Air Foil 6'
9860003 Air Foil 8'
1861400 Pulley, Front or Rear, 1-3/16 Dia. – NOT SHOWN
4949902 Cable, Sash 130" – NOT SHOWN
9741900 Sheave, (Rear 8') – NOT SHOWN
1663200 Bumper, Rubber – NOT SHOWN (upper sash bumper)
9742100 Bronze Bearing, Flanged Rear – NOT SHOWN
1920100 Clamp, Cable Replacement – NOT SHOWN
1972100 S-Hook – NOT SHOWN (to attach weight to cable)
99463XX Wiring Harness, Main
9807600, 01, Front Panel, 4', 5', 6', 8'
02, 03
9724500 Sash Stop Kit
