Labconco Protector 4882200 User Manual page 45

Chapter 7: Modifying Your Protector Radioisotope Fume Hood
Installing Additional Service
Fixtures
Additional service fixtures can be installed. The fume
hood is factory set to accept up to four valves per side,
but the liner is not drilled for extra fixtures. Contact
Labconco Customer Service for information.
Figure 7-2 - Knob Figure 7-3 - Valve
Figure 7-4 – Stainless Connectors
Installing Guardian™ Digital
Airflow Monitor or Guardian™
Jr. Airflow Monitor
The Guardian Digital Airflow Monitor P/N 9743211
continuously monitors face velocity through the fume
hood opening. The Guardian Jr. Airflow Monitor P/N
9743202 continuously monitors airflow through the
exhaust. The fume hood right corner post is factory
prepared to mount either monitor. Contact Labconco
Customer Service to order.
Figure 7-5 Figure 7-6
41
Product Service 1-800-522-7658
