nFUSE ECE Lightbar
®
QTY
1
OPTIONAL MOUNTING HARDWARE*
1 Vehicle Specific Hook Kit / Hardware
2 Fixed Height Mounting Brackets w/ Hardware
3 Flat Mount Hardware Kit
4 Headache Brackets w/ Hardware
OPTIONAL BACKLIGHT MODULE
1 Backlight Power Cable, 1 Per Module
*Components and Mounting Hardware will vary with each
Lightbar depending on vehicle specified on order form.
INPUT VOLTAGE RANGE
OPERATING TEMPERATURE
ELECTRICAL PROTECTION
MATERIAL
OVERALL DIMENSIONS
WIRING
STANDBY CURRENT
Amps @ 12.8V
STANDBY CURRENT
Watts @ 12.8V
LENGTH
42"
48"
54"
60"
72"
CERTIFICATION
ECE R65 Category TA2
ECE R65 Category TB2
ECE R65 Category TR2
ECE R148 2A
ECE R148 R1-S1
Unpack Lightbar
1. Remove lightbar from box and packaging.
2. Save packaging for later shipping.
3. Check components/contents.
4. Please reference these instructions for proper wiring and installation.
4
800-338-7337 | soundoffsignal.com
nFUSE ECE Lightbar built to your specifications
®
TECHNICAL SPECIFICATIONS
REVERSE POLARITY, TRANSIENT VOLTAGE, OVER-VOLTAGE, HIGH-TEMPERATURE
BASE PLATE: ALUMINUM ALLOY, POLYCARBONATE OUTER LENSES
Power Cable: 15ft, 10AWG Wires, (+) RED, (-) BLACK Data Line: 22AWG GREEN
Power Cable: 25ft, 10AWG Wires, (+) RED, (-) BLACK Data Line: 22AWG GREEN
Backlight Power Cable: 15ft, 22AWG Wires, 2x (+) RED, 2x (-) BLACK
IGNITION ON: 0.012 Amps per module, IGNITION OFF: <0.002 Amps
IGNITION ON: 0.15 Watts per module, IGNITION OFF: <0.03 Watts
MAX # OF MODULES
16
18
20
22
26
ECE R10
CONTENTS
COMPONENT
OPTIONAL CONTROL EQUIPMENT
COMPONENTS
Universal BOB (LIN)
Universal BOB (CAN)
24 Pin Harness
4 Pin Harness
5 Pin Harness
10-32Vdc
-40˚C to +65˚C (-40˚F to +149˚F)
THERMAL FOLD-BACK
2.28"H X 12.35"D (58.4mm H X 315mm D)
MAX CURRENT @ 12.8V
11.2 Amps
12.6 Amps
14.0 Amps
15.4 Amps
18.2 Amps
RED, AMBER, BLUE, WHITE, GREEN
Breakout Box
LIN (Standard)
Qty.
1
0
1
1
0
MAX CURRENT @ 25.6V
6.9 Amps
7.7 Amps
8.6 Amps
9.5 Amps
11.2 Amps
APPLICABLE COLORS
AMBER
BLUE
RED
AMBER
RED
Tools Required for Installation
• 7/16" Socket with ratchet
• Phillips Head Screwdriver
• Drill bit #30
nFUSE
Breakout Box
CAN System
Qty.
0
1
1
1
1
