Soundoff Signal nFUSE Installation Instructions Manual page 16

nFUSE ECE Lightbar
®
CONNECTION OF LIGHTBAR BREAKOUT BOX TO SOUNDOFF SIGNAL SIREN:
Note: Requires PC configuration app to map siren control switches to lightbar functions. Plug one end of the RJ-45 cable into the corresponding jack on
the siren amplifier..
ETSA481CSR or ETSA482CSR
CN6
ETSA481RSP, ETSA482RSP, ETSA461HPP, ETSA462HPP
CN3
ETSA5100/5200
SoundOff Central® Software Universal Breakout Box ID Settings
When using more than one lightbar universal breakout box (UBOB) with SoundOff Central Software, set the ID number for
each UBOB using the dip switches and then configure the lightbars accordingly in the Software.
1. Select Lightbars Tab on
the main SETUP Page.
16
800-338-7337 | soundoffsignal.com
CN2
CN8
2. Under Lightbars tab, select the EXTERNAL tab
to see UBOB list. The number after the UBOB is
the ID needed.
Breakout Box
Lightbar
CN5
RJ-45 Splitter
Breakout Box
UNIVERSAL BREAKOUT BOX
Lightbar
3. Hover cursor over the
Universal Breakout Box ID Information.
Siren Controller
Lightbar
- BACK
nFUSE
to open up
ECE Lightbar English
®
