Soundoff Signal NEXUS TECHNOLOGY nFORCE Installation Instructions

NEXUS TECHNOLOGY
nFORCE LED Interior Lightbar
9 8 7
2020 Ford PI Utility, Rear
G
F
E
D
C
B
WARNING
A
•HIGH CURRENT interconnects must be properly terminated. Poor crimp quality can cause heat
9 8 7
build-up and fire. Follow crimp connector manufacturer instructions.
•DO NOT install this product or route any wires in the Air Bag Deployment Zone. Refer to vehicle
Owner's Manual for deployment zones.
•Do NOT use system to disconnect headlights, brake lights or other safety equipment.
•Unit may become hot to touch during normal operation.
•Failure to properly install connectors, fuses or wiring may cause vehicle failure or fire.
•Installation must only be performed by trained technician. Installer must determine vehicle wiring
configuration and proper integration of system.
•Use proper wire gauge. All power wires connecting to positive (+) or negative (-) battery terminal
or local chassis ground (-) must be sized to supply at least 125% of max. current and properly fused at
power source.
•Install protective grommets when routing wire through firewall or metal.
1.800.338.7337 / www.soundoffsignal.com
1.
6 5 4
6 5 4
Installers and users must comply with all applicable federal, state and local laws regarding use and installation of warning devices.
To review our Limited Warranty Statement & Return Policy for this or any SoundOff Signal product, visit our website at www.soundoffsignal.com/tech-services/returns/.
If you have questions regarding this product, contact Technical Services, Monday - Friday, 8 a.m. to 5 p.m. ET at 1.800.338.7337 (press #4).
Questions or comments that do not require immediate attention may be emailed to techservices@soundoffsignal.com.
3 2 1
G
F
E
D
C
B
A
3 2 1
NOTICE:
Improper use or installation may void warranty coverage.
E N H A N C I N G S A F E T Y T H R O U G H I N N O VAT I O N
INSTALLATION:
1. Remove the plastic rectangular fascia located on the inside
of the rear hatch of the vehicle.
2. Orient the Plastic Fascia Drill Template so that the trimmed
corner is lined up with the bottom right corner when the
template is on the passenger side of the fascia, as seen in
Fig. 1.
3. Drill the pilot hole in the passenger side of the plastic
fascia. It is recommended to use a 1/16" drill bit for the
pilot hole.
4. Flip Plastic Fascia Drill Template over, as shown in Fig. 1
(print side facing down,) to drill the pilot hole in the driver
side of the plasic fascia.
5. Realign the Plastic Fascia Drill Template onto the passenger
side of the fascia. Then, drill out the 7/16" hole.
6. Flip Plastic Fascia Drill Template over, print side facing
down, to drill out the 7/16" hole on the driver side.
CONTENTS
QTY COMPONENT
1 2020 FORD UTILITY REAR SHROUD
2 HANGING BRACKETS
2 SHROUD STANDOFFS
2 2.5" SCREWS
4 SELF-TAPPING SCREWS
1 PLASTIC FASCIA DRILL TEMPLATE (002LA1060)
1 DRIVER SIDE DRILL TEMPLATE (002LA1062)
1 PASSENGER SIDE DRILL TEMPLATE (002LA1059)
1 PRODUCT WARNING CARD
1 INSTALLATION INSTRUCTION SHEET
WARNING
!
This product contains high intensity LED devices.
To prevent eye damage, DO NOT stare into the
light beam at close range.
nFORCE Interior Lightbar 2020 Ford Utility REAR 0819
