Racelogic VB2SX10 User Manual page 69

Inputs
CAN Bus
VCI CAN mode
Racelogic modules mode
Digital
Brake/Event Trigger
On/Off Logging control
Environmental and physical
Weight
Size
Operating Temperature
Storage Temperature
Industrial Protective Class (with case closed)
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_II/Discontinued_VBOX_II_versions/
User_Guide_VBOX_II_(VB2SX5%2C_VB2SX10%2C_VB20SL3)/15_-_VBOX_II_Technical_Properties/
Format; Motorola
Up to 16 channels from any external CAN module
Up to 20 channels from any combination of ADC02,
ADC03, FIM02, TC8, Yaw sensor or CAN01
Selectable signal polarity. 16 bit timer capture with 5 μs
resolution
Remote log control from hand-held switch
Approx 500 g
119 mm x 128 mm x 30 mm
-30°C to +60°C
-40°C to +80°C
IP 64
VBOX_II_Technical_Specification
