Racelogic VB2SX10 User Manual page 59

Connector 6 - SERIAL (Lemo 5 PIN)
(Setup / Upgrade, Second CAN Bus Connector)
PIN
1
2
3
4
5
Chassis
User_Guide_VBOX_II_(VB2SX5%2C_VB2SX10%2C_VB20SL3)/15_-_VBOX_II_Technical_Properties/VBOX_II_PIN_OUTS
I/O
O
I
I/O
I/O
I/O
I
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_II/Discontinued_VBOX_II_versions/
Function
RS232 Tx GPS (Tx Data from GPS
engine)
RS232 Rx GPS (Rx Data to GPS
engine)
CAN High
(direct connection between ports 5
and 6)
CAN Low
(direct connection between ports 5
and 6)
Power +
Ground
