Racelogic VB2SX10 User Manual page 57

Connector 4 - DIG I / O (Lemo 3 PIN)
(Wheel Speed and Brake Trigger Inputs)
PIN
1
2
3
Chassis
User_Guide_VBOX_II_(VB2SX5%2C_VB2SX10%2C_VB20SL3)/15_-_VBOX_II_Technical_Properties/VBOX_II_PIN_OUTS
I/O
I
I
I
I
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_II/Discontinued_VBOX_II_versions/
Function
NC
NC
Brake Trigger
Ground
57
