GPS Status
No Satellite Lock
Full Lock
Antenna A only SAT Lock
Antenna A and B SAT
Lock*
Antenna A and C SAT
Lock*
* SL twin / triple antenna units only
If a DGPS mode is enabled, it is indicated by the middle indicator light with one of the following messages.
DGPS Mode
WAAS, SBAS or EGNOS Differential correction
40 cm Differential correction from Base station
Logged File name:
When an SD card is inserted the file name of the logged file appears on the screen whilst data is being logged.
-
OK
-
-
-
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_II/Discontinued_VBOX_II_versions/
User_Guide_VBOX_II_(VB2SX5%2C_VB2SX10%2C_VB20SL3)/03_-_VBOX_II_Display_Screen_Overview
Front Panel Light Status
SAT (flashing)
-
RTK (flashing)
RTK
RTK (flashing)
Light Status
WAAS
40 cm
RTK (flashing)
-
RTK (flashing)
RTK (flashing)
RTK
