Note that for comparison, the VBOX YAW02 or IMU rate sensor has an RMS noise of 0.05 degrees per second,
so it should be noted that the Slip Angle sensor calculated YAW rate is significantly noisier than a solid state
sensor for yaw rate measurement.
Outputs
CAN Bus
Bit rate
Identifier type
Data available
Analogue
Voltage range
Default setting *
Accuracy
Update rate
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_II/Discontinued_VBOX_II_versions/
User_Guide_VBOX_II_(VB2SX5%2C_VB2SX10%2C_VB20SL3)/15_-_VBOX_II_Technical_Properties/
Format; Motorola
125 kbit/s, 250 kbit/s, 500 kbit/s and 1 Mbit/s selectable
baud rate
Standard 11 bit or extended 2.0 B
Satellites in View, Latitude, Longitude, Velocity,
Heading, Altitude, Vertical velocity, Distance,
Longitudinal acceleration & lateral acceleration,
Distance from trigger, Trigger time, trigger Velocity, True
heading, Slip angle, Pitch Angle, Yaw Rate, Lateral
Velocity, Roll Angle
–5 V to +5 V DC
Velocity
0.0125 Volts per km/h (0 to 400 km/h)
0.1 km/h
• 20 Hz - VB2SX, VB20SL, VB20SL3
• 10 Hz - VB2SX10
• 5 Hz - VB2SX5
