Operation
6. Check for correct inflation of the trailer tires. For
maximum tire pressures, refer to Specifications.
7. See Figure 3-56. Inspect the wheel lugs. Tighten
or replace any lugs that are loose or missing. If a
tire has been removed for axle service or replaced,
tighten the lugs, in the order shown, to the follow-
ing specifications:
4
2
Figure 3-56. Tightening Wheel Lugs
a. Start all lug nuts by hand.
b. First pass: tighten to 20-25 ft-lbs (27-33 Nm).
c. Second pass: tighten to 50-60 ft-lbs (67-81 Nm).
d. Third pass: tighten to 90-120 ft-lbs (122-162 Nm).
NOTE: After the first road use, torque the lug nuts in
sequence.
8. Maximum recommended speed for highway towing
is 65 mph (105 km/h). Recommended off-road
towing speed is not to exceed 10 mph (16 km/h) or
less, depending on the terrain.
38
1
3
5
003754
Lifting the Unit
Proceed as follows to prepare the unit for lifting:
1. Verify the equipment being used to lift the unit is in
good condition and has sufficient capacity. For
approximate weights, refer to Specifications.
2. Close and lock all hoods and doors.
3. See
Figure 3-57. Stow the mast and lights in the
travel position as shown.
4. Always remain aware of people and objects around
the unit while preparing, maneuvering, and lifting
the unit.
• When lifting the unit, attach any slings, chains, or
hooks directly to the central lift point (A). The
central lift point is located on top of the enclosure,
connected to a lift structure inside the unit.
A
B
Figure 3-57. Lifting Points
• Use the forklift pockets (B) with care. Lift directly
from the rear. Avoid approaching the unit at an
angle, as this can permanently damage the forklift
pockets, tires, or cabinet. Verify any obstructions
are clear of the forklift tines before lifting.
