6. See 3-7. Turn ignition switch to GLOW
Figure
PLUG position and hold for 10 to 15 seconds
Figure 3-7. Activate Glow Plug
IMPORTANT NOTE: Do not hold ignition switch in
GLOW PLUG position for more than 15 seconds.
7. See 3-8. Turn ignition switch to START
Figure
position and hold (10 seconds maximum) until
engine cranks and starts.
Figure 3-8. Crank Engine
IMPORTANT NOTE: Do not crank engine for more
than 10 seconds.
8. See
Figure 3-9. Release ignition switch. It moves
to the RUN position.
Figure 3-9. Release Key
IMPORTANT NOTE: If unit does not start after 10
seconds of cranking, turn ignition switch to STOP
position and wait 30 seconds. Then, repeat steps 6–7
as necessary.
Owner's Manual for Mobile Light Tower
9. Begin using lights and receptacles (if equipped), in
accordance with the following:
•
To operate lights, see
Controls.
•
To operate 120 V convenience receptacles, see
Customer
Equipped).
Starting Unit—Power Zone
Autolite Controls (MANUAL
Mode)
009951
NOTE: If the engine was run out of fuel or the fuel tank
was drained, it may be necessary to purge the fuel lines
before starting. See the OEM engine manual supplied
with the unit.
1. Open unit hood.
2. See
Figure
equipped) to position 2.
Figure 3-10. Flex Switch—Position 2
3. Close unit hood.
4. See Figure
009952
Figure 3-11. Controller Power ON (I)
5. See
Figure
Wait for engine to start.
009953
Figure 3-12. Engine START-STOP Button
Operating Lights—Analog
Convenience Receptacles
3-10. Switch the flex switch (if
3-11. Switch controller power to ON (I).
3-12. Press the START-STOP button.
B C
A
Operation
(If
010585
010588
010582
