General Information
®
Power Zone Autolite
A
Figure 2-13. Optional Power Zone Autolite Controls
A
AC circuit breaker—light fixture (4 locations)
B AC circuit breaker
Controls export power (if equipped)
C DC circuit breaker (3 locations)
D
Controller power switch
E Main circuit breaker
F Mast UP-DOWN switch (if equipped)
G Engine hour meter
Displays how many hours engine has run
H Power Zone Autolite controller
18
(If Equipped)
C
B
010576
Power Zone Autolite with Import Power (If
Equipped)
A
D
E
M
F
G
H
Figure 2-14. Optional Power Zone Autolite Controls
With Optional Import Power
A GFCI breaker (if equipped)
B
AC circuit breaker—light fixture (4 locations)
C AC circuit breaker
Controls export power (if equipped)
D
DC circuit breaker (3 locations)
E Controller power switch
F Main circuit breaker
G Mast UP-DOWN switch (if equipped)
H
Engine hour meter
Displays how many hours engine has run
J Power Zone Autolite controller
K
Outlet receptacle
L Inlet receptacle
M Engine/Utility power selector switch (flex switch)
C
D
B
L
015210
