Wren Kitchens Infinity Plus Base Unit Fittings Manual page 10

Fitting the drawer cover caps
(Infinity)
Fit the drawer cover caps over the drawer
side adjustment.
Adjusting the frontal horizontally
(Infinity Plus)
Use the fixing clips, which are found under
the drawer's front, to adjust the drawers.
Step 1 - Press the fixing clips halfway to meet
the runners on the underside of the drawer.
Step 2 - Slide the drawer to the left or right to
adjust.
Step 3 - To lock the fontal in place, by
releasing the fastening clips on both side of
the drawer.
Adjusting the frontal height
(Infinity Plus)
To adjust the height of the frontal, use a
screwdriver as required at points 1 and 2.
Step 1 - Loosen both of the screws at point 1.
Step 2 - Turn the screw at point 2 to adjust
the frontal's height.
Step 3 - Once in the desired position re-
tighten the screws at point 1.
Page 10
