Wren Kitchens LINEA Base Unit Fittings Manual page 8

Drilling the unit and wall
Drill 2 holes through both the rear top rail
and the wall at the marked locations. The size
of the holes will be determined by the size of
wall fixing required.
For guidance on the appropriate wall fixing
for each wall type, please consult the "Room
Preparation Guide."
Place the wall fixing within the holes in the
wall.
No screws are provided for attaching the unit to the wall.
This is due to variations in wall construction.
Inserting the screws
Insert the screws into the drilled holes and
tighten to the wall.
Before attaching the units together, ensure that the profie cutout of both units align.
Securing to adjacent units
Clamp together the two units, checking the
front edges are level and flush.
Using the screws provided, 1x30mm screw
should be fixed into each corner of the unit
side.
The screws can be concealed by placing
them behind the shelf or behind the hinge
plates. The cover caps can be used to hide
any visible screw heads that remain.
