Adjusting the frontal
(Linea)
Adjust frontal to suit, as shown in the image.
Point 1 - Will adjust the frontal left and right.
Point 2a - Will lock/unlock point 2b.
Point 2b - Will adjust the frontal up and down.
Point 3 - Will adjust the frontal releasing
fixing clip. Screw while applying downward.
pressure to release.
Fitting the drawer cover caps
(Linea)
Fit the drawer cover caps over the drawer
side adjustment.
Adjusting the frontal horizontally
(Milano)
Use the fixing clips, which are found under
the drawer's front, to adjust the drawers.
Step 1 - Press the fixing clips half way to meet
the runners on the underside of the drawer.
Step 2 - Slide the drawer to the left or right to
adjust.
Step 3 - To lock the fontal in place, by
releasing the fastening clips on both sides of
the drawer.
