Wren Kitchens LINEA Base Unit Fittings Manual page 11

Adjusting the frontal height
(Milano)
To adjust the height of the frontal, use a
screwdriver as required at points 1 and 2.
Step 1 - Loosen both of the screws at point 1.
Step 2 - Turn the screw at point 2 to adjust
the frontal's height.
Step 3 - Once in the desired position re-
tighten the screws at point 1.
Cleaning the unit
Finally, the unit should be thoroughly
cleaned to remove any debris that may have
accumulated during the installation.
Store the plinth clips, plinth vent and the remaining 15mm screws.
These will be used later when attaching the plinth.
Store the L-brackets.
These will be used later when installing the worktop (laminate or timber).
