Wiring terminals should be connected firmly to the terminal board. Loose
⑩.
connection is forbidden.
After the electrical installation is finished, please use wire clamps to secure the
⑪.
power cord, connection wire of indoor and outdoor units and the
communication cords. Make sure the wires are not clamped too tight.
The wire gauge of power cord should be large enough. Damaged power cord
⑫.
or other wires must be replaced by specialized wires. Wiring work must be
done according to national wiring rules and regulations.
2.3.2 Electrical Parameters
2.3.2.1 Wire Specifications and Fuse Capacity
Model
Indoor unit
Model
IGZPAC35V2NO-1
IGZPAC50V2NO-1
IGZPAC71V2NO-1
IGZPAC85V2NO-1
IGZPAC100V2NO3-1
IGZPAC125V2NO3-1
IGZPAC140V2NO3-1
IGZPAC160V2NO3-1
NOTES:
Fuse is located on the main board.
①.
Power supply
V/Ph/Hz
220-240V ~50/60Hz
Power supply
V/Ph/Hz
220-240V ~50/60Hz
380-415V 3N~50/60Hz
36
Min. sectional
Fuse
area of power
capacity
A
3.15
Circuit Min. sectional
breaker area of power
capacity
A
16
16
20
20
16
16
16
16
cord
mm²
1.0
cord
mm
2
1.5
1.5
2.5
2.5
1.5
1.5
1.5
1.5
