- Page 1 User's manual (Translation of original language) N420944A - Rev.03 - 07/2024 >OSMO< ECA844 - EWA844 - EEB749 - EFB749 - EGB749 - B10842 - B4V842 - B3V151...
- Page 2 By following the suggestions contained in this manual, the product you have purchased will operate without problems giving you optimum room temperatures with minimum energy costs. INNOVA S.r.l. Conformity Refer to the Installation Manual of the paired unit.
-
Page 3: Table Of Contents
TABlE OF CONTENTS TABLE OF CONTENTS Coding p. 5 1.1 Coding accessories . - Page 4 TABlE OF CONTENTS 4.1.2 Display ......... . p. 12 4.1.3 Keys functions .
-
Page 5: Coding P
LED electronic control panel with touch interface, wall-mounted complete with thermostat and room temperature and relative humidity EFB749II probe with integrated WiFi module, App Innova Butler. Cable connec- tion. Colour white LED electronic control panel with touch interface, wall-mounted complete with thermostat and room temperature and relative humidity EGB749II probe. -
Page 6: General Information P
GENERAl INFORMATION GENERAL INFORMATION 21 About the manual I nthefigures This manual was written to provide all the explanations for the correct management of the appliance. 1 The numbers indicate the individual components. This instruction manual forms an integral part of the A The capital letters indicate component assemblies. T he white numbers in black marks indicate a se- device and therefore must be carefully preserved and must ALWAYS travel with it, even if you transfer the de-... -
Page 7: General Warnings
GENERAl INFORMATION Coding It contains section by control mode and information on the It addresses all recipients. use of the main functions. It contains the list of products and/or accessories referred to in the manual. It addresses all recipients. General information It contains useful information for the control of the unit via It addresses all recipients. -
Page 8: Unit With Touchpad Cod Eca844 - Ewa844 P
UnIT WITH TOUCHpAD COD. ECA844 - EWA844 U NITWITHTOUCHPADCOD.ECA844-EWA844 31 Interface 311 Description • handle with care avoiding strong impacts or falling on hard surfaces The solution with touch pad is recommended for the • do not placing obstacles between the remote control prevalent use in cooling. and the device while you are using the remote The display on the appliance allows you to: If other devices are being used within the premises that • show the operating status are operated by remote control (TVs, radios, stereos, •... -
Page 9: Put In Stand-By The Control
UnIT WITH TOUCHpAD COD. ECA844 - EWA844 Correct use of the remote control: In heating function the symbols is alight with setpoint • point the front of the remote towards the unit’s dis- higher than the room temperature. play, the buzzer will emit a beep and a message will appear on the display to confirm that the command 325 Cooling only mode has been enabled • the maximum range to send commands is about 8 To select the Cooling operation metres ►... -
Page 10: Basic Menu
Wi-Fi pairing. To set the air probe regulation ► press to confirm ► select The device remains visible on the INNOVA App for ► press to change settings the first 15 minutes after the device is switched on. ► increase or decrease the value with the icons The function is only available for wall controls with Wi-Fi connection code EFB749. -
Page 11: Operating The Unit If The Remote Control Is Not Available
UnIT WITH TOUCHpAD COD. ECA844 - EWA844 34 Warnings 341 Operating the unit if the remote control is not available If you lose the remote control, the batteries run out or the remote stops working, you can be operate the device with the keys on the touch-screen display on-board the ma- chine. 342 Troubleshooting For the user it is important to distinguish any malfunction or performance levels that differ from the system’s stand- ard operating values (see technical specifications). The most common problems can be easily solved by the user by performing certain simple tasks (see the Troubleshoot- ing paragraph), while some system alarms require that you... -
Page 12: M7 Series Controls Eeb749 - Efb749 - Egb749 P
M7 SERIES COnTROLS EEB749 - EFB749 - EGB749 M 7SERIESCONTROLSEEB749-EFB749-EGB749 41 Interface 411 Description They are fitted with: • internal memory with data saving even in case of M7 series LED electronic control panels with touch inter- shut-down or power outage face for wall installation allow: • room temperature control After 20 seconds after the last action the panel bright- •... -
Page 13: Main Functions
M7 SERIES COnTROLS EEB749 - EFB749 - EGB749 42 Main functions 421 General start-up 425 Heating only mode Before the activation: To select the Heating operation Make sure that the remote control is connected to the ► press for about 2 seconds mains. The symbol on indicates the Heating function enable. -
Page 14: Menu Items
M7 SERIES COnTROLS EEB749 - EFB749 - EGB749 433 S etprobeoffsetRH To navigate in the menu ► use the icons Modify only after real deviations from an actual meas- Toselectamenuitemandtoconfirmthechanges urement with professional instrumentation have been made established. ► press the icon Confirming the change takes you to the next item. To set the RH probe regulation ►... -
Page 15: Long Period Shut-Down
► press appears to enable Wi-Fi pairing. appears to reset Wi-Fi credentials. ► press to confirm The device remains visible on the INNOVA App for ► press to confirm Credentials have been reset. the first 15 minutes after the device is switched on. -
Page 16: Preliminary Warnings
TROUBlESHOOTING TROUBLESHOOTING 51 Preliminary warnings For detailed information on accessories please re- Follow the instructions below: fer to the "Coding accessories" p. 5 section. ► disconnect the device from power supply immediate- Shouldyouencounteranyoftheanomaliesbelow: ► close the water taps • the ventilation does not start even if the water circuit ► contact immediately an authorized technical support is filled with hot or cold water center or qualified staff • the device is losing water in heating mode •... -
Page 17: Preliminary Warnings
MAINTENANCE MAINTENANCE Routine maintenance is essential to keep the device always efficient, safe and reliable over time. 61 Preliminary warnings Before each cleaning and maintenance intervention: Warnings: ► disconnect the device from the power mains by turn- • Do not lean or sit on the fancoil to avoid damaging ing the system master switch to "OFF" the appliance. ► wait for the components to cool down in order to •... -
Page 18: Suggestions For Energy Saving
MAINTENANCE Cover cabinet Plastic tabs Air intake filter Toremovethefilter: ► Distance the bottom of the cover cabinet by pulling it toward you ► push up the plastic tabs on the bottom of the filter ► Unhook the filter from its housing ► remove the filter by pulling it downwards Toreassemblethefilter: ► proceed in reverse order Check that the filter is fitted correctly. It is forbidden to use the device without its mesh filter. Tocleanthefilters: ► use a vacuum cleaner ► aspirate dust ►... -
Page 19: Technical Information P
TECHNICAl INFORMATION TECHNICAL INFORMATION 71 Operating limits Operating limits u.d.m. Heating Cooling Minimum room relative humidity Maximum room relative humidity Minimum room air temperature °C Maximum room air temperature °C... - Page 20 INNOVA S.r.l. Via I Maggio 8 - 38089 Storo (TN) - ITAlY tel. +39.0465.670104 – fax +39.0465.674965 info@innovaenergie.com...
