- Page 1 INSTALLATION, USE AND MAINTENANCE MANUAL 2.0 RINNOVA VERTICAL - Floor standing -...
-
Page 2: Table Of Contents
CONNECTIONS ..................................18 COMMISSIONING AND METHOD OF USE ............................19 OPERATION OF THE CONTROL PANEL ON THE WIFI MACHINE AND REMOTE CONTROL ............. 19 TURNING THE UNIT ON AND OFF ............................20 Innova Srl Page 2 Manual 2.0 RINNOVA VERTICAL... - Page 3 ALARMS ......................................26 GENERALITY ................................... 26 PROBLEMS WITHOUT ERROR INDICATION ON THE DISPLAY ....................26 TABLE OF ALARMS SIGNALED BY DISPLAY ..........................27 NOTES AND INFORMATION MAINTENANCE ........................... 28 NOTE ...................................... 28 Innova Srl Page 3 Manual 2.0 RINNOVA VERTICAL...
-
Page 4: Generality
Do not put R410A into the atmosphere: R410A is a fluorinated greenhouse gas, referred to in the Kyoto protocol, with a global warming potential (GWP) = 1975. 1.3 SYMBOLOGY The symbols shown in the following booklet allow you to quickly provide information necessary for the correct use of the unit. Safety symbols Innova Srl Page 4 Manual 2.0 RINNOVA VERTICAL... -
Page 5: Warnings
Make sure that the earth connection is made; do not ground the appliance on distribution pipes. Momentary surges of high intensity could damage the unit Innova Srl Page 5 Manual 2.0 RINNOVA VERTICAL... -
Page 6: Compliance
There are 2 ePM1 filters on the extracted and injected air; The filter on the supply air is placed after the coil to completely filter any impurities of the input air. On the outside air there is a Coarse pre- filter that protects the cleanliness of the unit; Innova Srl Page 6 Manual 2.0 RINNOVA VERTICAL... -
Page 7: Main Components Of The Unit
Remote panel to be purchased optionally with WIFI or MODBUS RTU for connection up to 10m from the unit for the recessed versions; 1.8 MAIN COMPONENTS OF THE UNIT Innova Srl Page 7 Manual 2.0 RINNOVA VERTICAL... -
Page 8: Packaging And Transport
1.11 DISASSEMBLY AND DISPOSAL Do not disassemble or dispose of the product yourself. Disassembly, demolition, disposal of the product must be carried out by authorized personnel in compliance with local regulations. Innova Srl Page 8 Manual 2.0 RINNOVA VERTICAL... -
Page 9: Installation
-The appliance is not directly above a household appliance (television, radio, refrigerator, etc.), or above a heat source -In the environment chosen for the installation there must be: - connections of the external air ducts; - 230V single-phase electrical connection -connection for condensate drain Innova Srl Page 9 Manual 2.0 RINNOVA VERTICAL... -
Page 10: Unit Positioning
Drill the 6 holes for anchoring the bracket of Innova Srl Page 10 Manual 2.0 RINNOVA VERTICAL... - Page 11 Ensure sufficient space for carrying out maintenance activities: the opening of the unit cover (front) must be guaranteed. Assembly Innova Srl Page 11 Manual 2.0 RINNOVA VERTICAL...
- Page 12 The drilling position is shown in the installation template. 1 - Mounting bracket 2-Anchor holes 3- Anti-lifting bracket Mounting on fixing bracket Innova Srl Page 12 Manual 2.0 RINNOVA VERTICAL...
-
Page 13: Condensate Drain Connection
The insulation must be inserted up to the entrance to the external condensate drain pipe embedded in the wall 1 - Wall section 2- Insulation 3- Emergency drain 4- Condensate drain hose Condensate drain connection Innova Srl Page 13 Manual 2.0 RINNOVA VERTICAL... -
Page 14: Areaulic Connections
For the correct connection of the air ducts, refer to the following diagram and the stickers placed on the unit. Unit aeraulic connection diameters table Unit 2.0 RINNOVA VERTICAL Ø External air mm Ø Expulsion mm 160mm Air flow configurations 2.0 RINNOVA VERTICAL REAR VIEW Innova Srl Page 14 Manual 2.0 RINNOVA VERTICAL... -
Page 15: Assembly Of External Grids
Keep in mind that the grilles open when the outside air flow is activated to allow the cooling or heating function. For their testing it is therefore essential to operate the air conditioner to cool or heat Mounting external grids Innova Srl Page 15 Manual 2.0 RINNOVA VERTICAL... -
Page 16: Electrical Connections
The connections are inside the electrical compartment, positioned in the lower left part where the terminal block with power supply and ON OFF command; 1 - Cable entry 2 - Terminal block Electrical connections Innova Srl Page 16 Manual 2.0 RINNOVA VERTICAL... -
Page 17: Inserting The Remote Control Batteries
To insert the battery, open the special snap door located in the lower part of the remote control. The battery must be inserted carefully respecting the polarity. Close the snap door once the battery is inserted Remote control batteries Innova Srl Page 17 Manual 2.0 RINNOVA VERTICAL... -
Page 18: Electrical Diagram
CP- REMOTE ON OFF Provides an external connection to enable the unit as a presence or window contact; Comes with a deck supplied; Connections Innova Srl Page 18 Manual 2.0 RINNOVA VERTICAL... -
Page 19: Commissioning And Method Of Use
- giving it strong shocks or dropping it on hard surfaces - leaving it exposed to sunlight Wi-Fi machine board panel Remote controller Innova Srl Page 19 Manual 2.0 RINNOVA VERTICAL... -
Page 20: Turning The Unit On And Off
By setting this operation, the appliance sets itself up in such a way as to obtain optimal comfort in the air-conditioned room. Depending on the set temperature, the air conditioner automatically selects the operating mode (cooling or heating), and the ventilation speed based on the room temperature and the detected air quality; Innova Srl Page 20 Manual 2.0 RINNOVA VERTICAL... -
Page 21: Ventilation Only Function
Press and hold the season change button for at least 3 seconds to change the status of the season; The operation must be carried out to activate the correct logics: Logic symbols: SUN - WINTER SNOWFLAKE - SUMMER Season Change Innova Srl Page 21 Manual 2.0 RINNOVA VERTICAL... -
Page 22: Timer Function
-The unit provides for the operation of a UVC lamp with germicidal action placed in the section where the new air enters; The lamp is activated permanently together with the activation of the fans; Innova Srl Page 22 Manual 2.0 RINNOVA VERTICAL... -
Page 23: Maintenance
If the conditions of the filters allow it, they can be cleaned using a vacuum cleaner or a low pressure compressor. View for filter extraction Innova Srl Page 23 Manual 2.0 RINNOVA VERTICAL... -
Page 24: Prefilter Replacement
View for filter extraction 6.3 LAMP MAINTENANCE To carry out maintenance on the UVC lamp; Remove the upper grille and the front grille; Remove the two fixing screws of the front panel under the grille; Innova Srl Page 24 Manual 2.0 RINNOVA VERTICAL... - Page 25 Carry out the operation with care and delicacy; Reposition the lamp, making sure it is well coupled with the relevant lamp holder; Reposition the front covers, the front panel and the grills; View for lamp maintenance Innova Srl Page 25 Manual 2.0 RINNOVA VERTICAL...
-
Page 26: Alarms
Noise coming from the ducts Check for cracks in the intake / inlet / exhaust pipes Vibrations Panels that vibrate Check the integrity of the aluminum panels and profiles of the unit Innova Srl Page 26 Manual 2.0 RINNOVA VERTICAL... -
Page 27: Table Of Alarms Signaled By Display
It is not possible to activate any operation of the appliance. failure CP presence contact open The device is activated only if the contact is closed. Check the connection of the terminals. Innova Srl Page 27 Manual 2.0 RINNOVA VERTICAL... -
Page 28: Notes And Information Maintenance
