Circontrol eVolve Smart Series User Manual page 21

1 0 — M A X I M U M T E M P E R A T U R E E R R O R
When the Charge Point's temperature is above a certain value, the status LED light
bar flashes in a sequence of eleven blinks. If this is the case, the Charge Point will
not be operating, temperature is too high to charge, so you will have to wait until the
operating temperature is reached. Then Charge Point starts charging again.
1 1 — M I N I M U M T E M P E R A T U R E E R R O R
When the Charge Point's temperature is below a certain value, the status LED light
bar flashes in a sequence of twelve blinks. If this is the case, the Charge Point will
not be operating, temperature is too low to charge, so you will have to wait until the
operating temperature is reached. Then Charge Point starts charging again.
1 2 — T A M P E R E R R O R
This means that the Charge Point has been opened accidentally or without pulling
out the tamper (Maintenance position).
11
Blink Sequence
12
Blink Sequence
Fixed LED Bar
21
