- Page 1 Installation Manual eNext Park...
-
Page 2: Revision Log
Revision log Date Version Description 06/2024 v2.2 eNext Park T Two model addition 02/2024 v2.1 Changes in the following sections: 1, 2, 5 ,6 — — Previous versions... - Page 3 C O P Y R I G H T I N F O R M A T I O N This document is copyrighted, 2024 by Circontrol, S.A. All rights are reserved. Circontrol, S.A. reserves the right to make improvements to the products described in this manual at any time without notice.
- Page 4 Here’s the guide to install your eNext...
-
Page 5: Table Of Contents
1 — So, hello! 2 — Before installation A - Important safety instructions B - Electrical wiring considerations 3 — Overview 4 — Dimensions 5 — Installation A - Minimum distances B - Opening C - Positioning D - Fixing E - Wiring F- Verification 6 —... -
Page 6: So, Hello
It is mandatory to follow the basic security information supplied in this manual to ensure safe and proper installation. Failure to follow safety instructions may involve personal injury, equipment damage and danger of death. CIRCONTROL is not responsible for events arising from such breach. THE FOLLOWING SYMBOLS ARE USED FOR IMPORTANT... - Page 7 • Complies with IEC 61851, Electric vehicle conductive charging system (IEC 61851-1 and IEC 61851-21-2). • Complies with IEC 62196, Plugs, socket-outlets, vehicle couplers and vehicle inlets (IEC 62196-1 and IEC 62196-2). • Complies with Directives: 2014/35/EU, LVD;2014/30/EU, EMC. Complies with The Electrical equipment (safety) regulations 2016 •...
-
Page 8: Before Installation
• Do not use this unit if the enclosure the warranty will be void. or the EV connector is broken, cracked, open, or shows any other indication of damage. CIRCONTROL — eNext Park — Installation Manual... -
Page 9: B) Electrical Wiring Considerations
Electrical wiring considerations Take into consideration this section before start wiring connections of the Charge Point. 1 - E L E C T R I C A L P R O T E C T I O N S Charge Point may not include elements of electrical protection. If this equipment has internal electrical protections, they are installed for each socket-outlet for the protection of the user against an electrical failure, according to the international standard IEC 61851-1:2017. -
Page 10: Overview
Overview What’s included: Charge Point Quick Installation Guide Allen wrench Ethernet cable gland 2.5 mm NOTE: The configuration of cable glands and caps may vary depending on the model. CIRCONTROL — eNext Park — Installation Manual... - Page 11 7 — LCD 2 — Cable glands 5 — Wall support holes 8 — RFID reader 3 — Ethernet cable 6 — Closing box holes gland Only available in eNext Park T Two Plugs may vary depending on the model...
-
Page 12: Dimensions
Dimensions Dimensions in mm CIRCONTROL — eNext Park — Installation Manual... - Page 13 52,5 44,8 79,8 52,5 39,5 20,5 This measurement may vary...
-
Page 14: Installation
Tools: Screw driver Ratchet Driller Tap drill 6/8M 2.5mm Allen Ratchet tool can be used to open/close the Charge Point if required by the condi- tions of installation. CIRCONTROL — eNext Park — Installation Manual... -
Page 15: Minimum Distances
• Please comply with your country regulations. • The Charge Point shall be installed on a wall or on Circontrol accessories. • When installing the unit, some space shall be reserved for usability, maintenance and safety reasons. The picture below shows the recommended minimum distances: 700 mm ≤... -
Page 16: B) Opening
Open the eNext using an Allen wrench. 2.5 mm Allen wrench Screw DIN-7380-2 M4x14 INOX Sealing washer DIN 7712 4.8 14MM INOX Use the ratchet tool to open / close in conditions that hinder access CIRCONTROL — eNext Park — Installation Manual... - Page 17 RJ45 Screw In case of having the eNext Park T Two model, it will incorporate a hinge. Consequently, simply remove the screws on the right side and open the PCB plastic support to have access to the Ethernet connection and the wall screw hole.
-
Page 18: C) Positioning
Positioning Drill the wall. Drill bit M 6/8 700 mm ≤ y ≤ 1000 mm Dimensions in mm Fixing Place the unit on the previous pierced points and fix it with screws. CIRCONTROL — eNext Park — Installation Manual... -
Page 19: E) Wiring
Wiring Insert the power cable. In case of having the eNext Park T Two model, there are two possibilities. Circontrol recommends to use the upper supply entry for indoor installations and bottom supply entry for outdoor installations. Use provided cable glands in order to mantain the IP protection... - Page 20 At least once a year it is recommended to carry out the verification of the installation grounding by qualified personnel when the terrain is drier. CIRCONTROL — eNext Park — Installation Manual...
- Page 21 THREE-PHASE CHARGE POINT - TWO CONNECTORS • Connect to the 400VAC. • If the Power Supply is Single-Phase, connect L1 and N. Protections Protections Protecciones Protecciones Protections Protections Schützungen Schützungen Protezione Protezione Ochrony Ochrony 1.5 - 1.8 Nm 1.5 - 1.8 Nm Terminal block maximum cross-section: 10 mm Type of cable allowed by the terminal block: Copper, Aluminium...
-
Page 22: F- Verification
6 — C H E C K T H E B E A C O N I N D I C A T O R S All beacon indicators should light properly. The behaviour of eNext Park T Two is slightly different. Here are both references:... - Page 23 Other models: P L U G S T A T E B E A C O N C O L O R A v a i l a b l e G r e e n C h a r g i n g B l u e F a u l t R e d...
-
Page 24: Technical Data
Low Temperature Kit Operating humidity 5% to 95% Non-condensing Maximum temperature for eNext Park T Two. For all other models, the maximum temperature is +45ºC. Equipment to be installed outdoor shall be provided with the Low Temperature Kit in order to comply with the IEC 61851-1:2017... - Page 25 Depending on the model, some components may vary. Please check availability with your local supplier. Cable cross section recommended by Circontrol. However, the final cross section must be calculated by a qualified technician taking into account the specific conditions of installation and the local regulations.
-
Page 26: Need Help
Need help? CIRCONTROL — eNext Park — Installation Manual... - Page 27 In case of any query or if further information is required, please contact our Post-Sales Department. support@circontrol.com www.circontrol.com (+34) 937 362 940 (+34) 937 362 941...
- Page 28 CIRCONTROL eNEXT PARK INSTALLATION MANUAL A comprehensive guide on how to install and verify your eNext Park. Scan me to download the User Manual CIRCONTROL S.A. - ALL RIGHTS RESERVED...
