6 — W E L D E D C O N T A C T E R R O R
An internal short-circuit has been detected. In this case, the status LED light bar
flashes in a sequence of seven blinks.
7 — L O C K I N G S Y S Y E M E R R O R
This may occur if the connector is not properly connected to the socket-outlet. In this
case, the status LED light bar flashes in a sequence of eight blinks.
8 — C O M M U N I C A T I O N E R R O R
This means that there has occurred a communication error. If this is the case, the
status LED light bar flashes in a sequence of nine blinks.
9 — N O I N P U T V O L T A G E E R R O R
This means that there is not input voltage going throw the Mode 3 PCB. If this is the
case, the status LED light bar flashes in a sequence of ten blinks.
20
7
Blink Sequence
8
Blink Sequence
9
Blink Sequence
10
Blink Sequence
