Fiber Solution
NetWay4E1BT Series
4-port Hardened 802.3bt
4PPoE Switches
Models Include:
NetWay4E1BTWP
- 4-port Hardened 802.3bt 4PPoE Switch
and Power Supply/Charger
- NEMA4/4X, IP66 rated Outdoor enclosure.
NetWay4E1BTWPX
- 4-port Hardened 802.3bt 4PPoE Switch
and Power Supply/Charger
- NEMA4/4X, IP66 rated Outdoor enclosure.
- Accommodates up to four (4)
12VDC/4AH batteries.
NetWay4E1BTWPN
- 4-port Hardened 802.3bt 4PPoE Switch
(uses external power supply).
- NEMA4/4X, IP66 rated Outdoor enclosure.
Installation Guide
DOC#: NetWay4E1BT Rev. 031723
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
NetWay4E1BTX
- 4-port Hardened 802.3bt 4PPoE Switch and
Power Supply/Charger
- NEMA1 rated Indoor enclosure.
NetWay4E1BTPL
- 4-port Hardened 802.3bt 4PPoE Switch
and Power Supply/Charger
- Backplane version.
NetWay4E1BTB
- 4-port Hardened 802.3bt 4PPoE Switch
- Board Only.
More than just power.
TM
Advertisement
Table of Contents
Related Manuals for Altronix NetWay4E1BT Series
Summary of Contents for Altronix NetWay4E1BT Series
- Page 1 Fiber Solution NetWay4E1BT Series 4-port Hardened 802.3bt 4PPoE Switches Models Include: NetWay4E1BTWP NetWay4E1BTX - 4-port Hardened 802.3bt 4PPoE Switch - 4-port Hardened 802.3bt 4PPoE Switch and and Power Supply/Charger Power Supply/Charger - NEMA4/4X, IP66 rated Outdoor enclosure. - NEMA1 rated Indoor enclosure.
-
Page 2: Table Of Contents
Battery Backup ............pg. 4 Recommended Altronix Power Sourcing Equipment ....... pg. 5 Recommended Altronix SFP Modules . -
Page 3: Overview
Overview: Altronix NetWay4E1BT Series Hardened 802.3bt 4PPoE Switches are equipped with one (1) 1Gb SFP port and four (4) POE IEEE802.3af/3at/3bt PoE ports rated at 90W each, limited to 240W or 320W total power, depending on a model. Features: Agency Listings: Indicators (LED): •... -
Page 4: Installation Instructions
Note: When batteries are not used, a loss of AC will result in the loss of output voltage. Note: When using two 12V LiFePO 4 (lithium iron phosphate) batteries, check with manufacturer specifications that batteries can be connected in series. For outdoor battery backup, battery enclosure must have sufficient ventilation. - 4 - NetWay4E1BT Series Installation Guide... -
Page 5: Recommended Altronix Power Sourcing Equipment
Filtered and electronically regulated output. Short circuit and thermal overload protection. Recommended Altronix SFP Modules: Altronix P1MM, P1SM10, P1AB2K and P1GCE are hot-pluggable SFP fiber transceiver modules and are readily usable with all Altronix Spectrum fiber optic equipment for 1Gb transmission rates. -
Page 6: Typical Applications Drawings
Estimated distances are based on starting voltage of 56VDC and accounts for a 10 volt drop. All distances are per IEEE 802.3at standard for device power requirements of minimum 44VDC and leave an approximate 2 volts for safety and flexibility. - 6 - NetWay4E1BT Series Installation Guide... - Page 7 Separate Switch Inlets 115/230VAC IP Device IP Device Input (802.3af / 802.3at / 802.3bt) (802.3af / 802.3at / 802.3bt) IP Device IP Device (802.3af / 802.3at / 802.3bt) (802.3af / 802.3at / 802.3bt) NetWay4E1BT Series Installation Guide - 7 -...
-
Page 8: Wall Mount Installation
This installation should be made by qualified service personnel. This product contains no serviceable parts. PMK1 and PMK2 outdoor pole mount kits are designed to simplify the installation of Altronix outdoor rated power supplies and accessories housed in models WP1, WP2, WP3 and WP4 NEMA rated enclosures. PMK1 and PMK2 can be mounted on 2”... -
Page 9: Mechanical Drawings And Dimensions
PADLOCK LATCH ATTACHED WITH RIVETS (Ø 0.375” (9.5mm) PADLOCK EYE) 8.00” (203.2mm) Ø 0.32 (8.1mm) MOUNTING HOLE TYP. 4 PLACES 10-32 X 0.375” (9.5mm) BRASS INSERT (X4) 10-32 X 0.25” (6.4mm) BRASS INSERT (X2) NetWay4E1BT Series Installation Guide - 9 -... - Page 10 ATTACHED WITH RIVETS. Ø 0.375 PADLOCK EYE 14.54” (369.3mm) 14.00” (355.6mm) SECTION A-A 12.23” (310.6mm) 0.125” (3.2mm) MOUNTING PLATE END VIEW Ø 0.32” (8.1mm) WALL MOUNTING HOLE X 4 10-32 X 0.250 BRASS INSERT 4 PLCS. 12.00” (304.8mm) - 10 - NetWay4E1BT Series Installation Guide...
- Page 11 (30.5mm) 0.75” 0.75” 12.5” (317.5mm) 1.20” 1.20” (19.1mm) (19.1mm) (30.5mm) (30.5mm) 11.0” (279.4mm) 0.9375” (23.8mm) 1.40” 1.40” (35.6mm) (35.6mm) 0.9375” (23.8mm) 3.25” (82.6mm) 3.25” (82.6mm) 1.0” (25.4mm) 1.0” 1.0” 10.5” (266.7mm) (25.4mm) (25.4mm) NetWay4E1BT Series Installation Guide - 11 -...
- Page 12 10.75” x 8.875” x 2.375” (273.1mm x 225.4mm x 60.3mm) 8.875” (225.4mm) 8.25” (209.5mm) 0.25” (6.4mm) Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty...
