Sharp MultiSync ME982 User Manual page 48

Community name:
The default setting of community name is "public". It is read-only. You can set community names for up to 3 settings.
When "SNMP v3" is selected in "Version", configure the settings below.
USER NAME 1-3
USER1 to 3 can be registered.
USER NAME ........................................Configure the username to be used in SNMPv3.
SECURITY LEVEL ...............................Set the security level.
SECURITY LEVEL
No Auth/No Private
Auth/No Private
Auth/Private
Trap:
Sending error message to a specified address when an error occurs in the monitor.
Check Box
Temperature
Name Settings
Click on "NAME" on the left-hand column below HOME.
MONITOR NAME Allows you to customize the monitor's name, up to a maximum of 16 characters long. This name
is shown when searching for devices on the network when using an application such as NaViSet
Administrator. Giving the monitor a unique name allows it to be easily identified when viewing a list of
monitors on the network. The default name is the monitor's model name.
HOST NAME Type in the hostname of the network to the monitor.
Up to 15 alphanumeric characters can be used.
Network Service Settings
Click on "NETWORK SERVICE" on the left-hand column below HOME.
PJLink CLASS Set a class for PJLink*.
NOTE: PJLink is a network interface standard that JBMIA established.
https://pjlink.jbmia.or.jp/index.html
This monitor is available for class1 and class2 command.
NOTIFY FUNCTION Enable or disable a notification of the monitor network condition. This function is only for class2.
ENABLE
NOTIFY ADDRESS Set an IP ADDRESS to which the monitor network status will be sent. This function is only for class2.
PJLink PASSWORD Set a password for PJLink*. The password must be max. 32 characters long. Do not forget your
password. If you forget your password, consult your supplier.
HTTP PASSWORD Set a password for the HTTP server. The password must be max. 32 characters long.
HTTP PASSWORD An HTTP PASSWORD is required when logging into the HTTP server.
ENABLE Set the monitor name as the USER NAME when entering the password.
*What is PJLink?
PJLink is a standardization of protocol used for controlling devices of different manufacturers. This standard protocol was
established by Japan Business Machine and Information System Industries Association (JBMIA) in 2005.
The device supports all commands of PJLink.
Authentication protocol
No (User name)
MD5 or SHA1
MD5 or SHA1
Explanation
Temperature abnormal
Message encryption
No
No
DES or AES
Error code
0xA0, 0xA1, 0xA2
English−48
