Truflo — TKS | TK3S Series
®
In-Line Paddle Wheel Flow Meter Sensor

Safety Information

■ De-pressurize and vent system prior to installation or removal
■ Confirm chemical compatibility before use
■ DO NOT exceed maximum temperature or pressure specifications
■ ALWAYS wear safety goggles or face-shield during installation and/or service
■ DO NOT alter product construction
Warning | Caution | Danger
Indicates a potential hazard. Failure to follow all warnings
may lead to equipment damage, injury, or death.
Note | Technical Notes
Highlights additional information or detailed procedure.
Please ensure that the Instruments are not to be subject to water hammer or pressure spikes! Always
Pressure Test System with H2O Prior to Initial Start-Up
Before installation be certain the appropriate instrument has been selected considering operating pressure, full scale pressure,
wetted material requirements, media compatibility, operating temperature, vibration, pulsation, desired accuracy and any other
instrument component related to the service application including the potential need for protective attachments and/or special
installation requirements. Failure to do so could result in equipment damage, failure and/or personal injury. Ensure only qualified
personnel are permitted to install and maintain this instrument.
Pressurize System Warning
Sensor may be under pressure, take caution to vent system prior to installation or removal. Failure to do so may result in equipment
damage and/or serious injury.
Please Ensure Full Pipe
TK Series can be installed in a horizontal or vertical direction. Please ensure enough length of straight pipe to avoid intensified
turbulent flow that can effect readings.
Min 10x Pipe Diameters Upstream 3x Pipe Diameters Downstream (See Page 10)
A Bag Filter or Y Strainer Filtering Device upstream to Avoid the Paddle Wheel from being damaged by the solids or fibers - max
10% Particle Size - Not to Exceed .5mm Cross Section or Length. Please do not flush the pipe after the Flow Meter is installed with
compressed air this may damage the ceramic shaft and will void warranty.
24-0564 © Icon Process Controls Ltd.
Personal Protective Equipment (PPE)
Always utilize the most appropriate PPE during
installation and service of Truflo
Pressurized System Warning
Sensor may be under pressure. Take caution to vent system
prior to installation or removal. Failure to do so may result
in equipment damage and/or serious injury.
products.
®
2
