Safety Information; Technological Progress; Introduction - Icon Process Controls truflo UltraFlo H2O Series Operating Manual

UFM-H2O Series
Ultrasonic Flow Meter

Safety Information

Warning | Caution | Danger
Indicates a potential hazard. Failure to follow all
warnings may lead to equipment damage, injury, or
death
Note | Technical Notes
Highlights additional information or detailed
procedure.
Intended Use
®
The flow meter UltraFlo
®
The UltraFlo is not intended for use in medical applications.
The volume flow meter UltraFlo
"Safety specifications for electrical measurement, control and laboratory devices").
The manufacturer is not liable for any injury, damage or harm due to inappropriate or unintended use or modifications of the flow
meter. Conversions and/or changes to the flow meter may only be made, if they are expressly performed in accordance with the
operating instructions in this operating manual.
Personnel for Installation, Commissioning and Operation
Assembly, electrical installation, commissioning and maintenance of the flow meter must be carried out by qualified,
trained personnel. The qualified personnel must have read and understood the operating instructions in this
operating manual and must follow the operating instructions in this manual.
The installer has to ensure that the flow meter is correctly connected according to the electrical connection diagrams
in this operating manual.
Serious injury or death from electric shock may occur if wiring, installation, disassembly or removal of wires is
performed while electrical power is energized

Technological Progress

The manufacturer reserves the right to revise, alter, or modify the flow meter to the most current technology without special prior notice.
Further information about the latest updates and potential additions to these operating instructions are available from
www.iconprocon.com

Introduction

®
The UltraFlo H2O series ultrasonic water meter is a new type of water meter specially designed for agricultural irrigation, garden
management and water resources monitoring.
The water meter has some advantages, such as low cost, high measurement accuracy, low power consumption, stable and reliable
operation and so on. The thickness of the water meter is only 2 inches(50.8mm), which saves installation space, and the IP68 scheme is
adopted for all parts so that the water meter can be used in various harsh environment. The uniquestructure of the water meter makes
the measurement basically free from the influence of water quality and pressure loss, which is a major breakthrough in the agricultural
irrigation water measurement.
®
The UltraFlo H2O Series Flow Meter utilizes ultrasonic technology to maximize water efficiency. It has no moving parts, and is
lightweight making it an excellent choice for plastic piping systems. The UltraFlo
against corrosive environments and flooded wet conditions
(Battery Operated)
should only be used for measuring the flow of pure, homogeneous liquids.
®
is built in accordance with industry standard EN 61010 regulations (corresponds to VDE 0411
IMPORTANT!
indicates situations or cases which, if not avoided,
could result in damage or failure of the Products
equipment.
Do Not Use Tools
Use of tool(s) may damage product beyond repair
and potentially void product warranty.
®
H2O all plastic design provides excellent protection
