Truflo — TKS | TK3S Series
®
In-Line Paddle Wheel Flow Meter Sensor
Programming Relay
STEPS
Home Screen
1
Relay Set Point
2
Hysterisis
3
K-Factors for TK Series (V1)
Size
¼"
⅜"
½"
¾"
1"
1½"
2"
3"
4"
⚠ K-Factor is Pre-Programmed
K-Factors for TK Series (V2)
Size
½"
¾"
1"
1½"
2"
2½"
24-0564 © Icon Process Controls Ltd.
DISPLAY
▶
��
3 Sec .
▶
▶
LPM GPM
547 2079
300 1140
127.6 484.9
81.8 310.8
55.1 209.4
18.8 71.4
10.2 38.8
4.7 18
2.1 8
K-Factor
127.6
81.8
55.1
18.8
10.2
6.0
Select/Save/Continue
F
Home Screen
Enter Relay Set Point
Factory Default: 100
Range: 0 ~ 999.9
Enter Hysterisis Value
Factory Default: 1.0
Range: 0 ~ 99.9

Min/Max Flow Rates

Pipe Size (O.D.)
DN08 (¼")
DN10 (⅜")
DN15 (½")
DN20 (¾")
DN25 (1")
DN40 (1½")
DN50 (2")
DN65 (2½")
DN80 (3")
DN100 (4")
Move Selection Left
OPERATION
LPM | GPM LPM | GPM
0.3m/s min. 10m/s max.
0.6 | 0.16 12
1.8 | 0.48 50
3.5 | 1.0 120
5.0 | 1.5 170
9.0 | 2.5 300
25.0 | 6.5 850
40.0 | 10.5 1350
60.0 | 16.0 1850
90.0 | 24.0 2800
125.0 | 33.0 4350
Change Digit Value
| 3
◀ SS Only
| 13
◀ SS Only
| 32
| 45
| 79
| 225
| 357
| 357
| 739
| 1149
