Summary of Contents for Icon Process Controls truflo TIB Series
- Page 1 TIB SERIES TIB Series Battery Flow Meter...
- Page 2 Flow Meters are not to be subject to water hammer or pressure spikes! WARNING! Before installation be certain the appropriate gauge has been selected considering operating pressure / full scale pressure / proof pressure, wetted material requirements, media compatibility, operating temperature, vibration, pulsation, desired accuracy and any other flow meter component related to the service application.
- Page 3 TIB SERIES...
-
Page 4: Display Functions
TIB SERIES Pressure vs. Temperature Long Service Life Note: Ceramic Rotor | Bushings Sensor Body Integrated Solid State Electronics 4 Blade ETFE (Tefzel ® ) Rotor Zirconium Ceramic Rotor Pin Display Functions TIB Series r = Flow Rate 3 Secs to change display from Flow Rate to Flow Total... - Page 5 SERIES Press for Decrease Value for Increase Value & Press Press Press to Change Digit STEPS DISPLAY RANGE OPERATION Home Screen Current Flow Rate | Total Press & Hold & 3 sec Programming Lock Out Feature Screen Lock : Factory Default Press LCK= '1' Locked K Factor...
- Page 6 SERIES Max Flow Rates Pipe Size 0.3m/s min. 10m/s max. 2" | DN50 40.0 | 10.5 357.0 | 1350.0 2 ½" | DN60 60.0 | 16.0 1850 | 357 3" | DN80 90.0 | 24.0 2800 | 739 4" | DN100 125.0 | 33.0 4350 | 1149 6"...
- Page 7 SERIES...
- Page 8 Do Not Use Display to Tighten Gauges are not to be subject to water hammer or pressure spikes! WARNING! Before installation be certain the appropriate gauge has been selected considering operating pressure / full scale pressure / proof pressure, wetted material requirements, media compatibility, operating temperature, vibration, pulsation, desired accura-cy and any other gauge component related to the service application (including the potential need for protective attachments and/or special installation requirements).
- Page 9 TIB SERIES Hand Tighten Retention Cap Do Not Use Display Display Rotates 330 Degrees Do Not Use Display to Tighten...
- Page 10 SERIES Battery Replacement | V Series Remove Cover Insert Screw Driver into Slot Remove Polycarbonate Lid Battery Remove 1 Battery Remove Screws Carefully Remove Display Module Reassemble Remove Battery Pack Replace Battery Pack...
- Page 11 SERIES Remove Polycarbonate Lid Insert Screw Driver into Slot Remove the 2 Screws...
- Page 12 TIB SERIES Battery Operated Paddle Wheel Flow Meter Entire Way Until...
- Page 13 TIB SERIES Battery Operated Paddle Wheel Flow Meter Dimensions V Series 3.62 in 3.62 in [91.9 mm] [91.9 mm] 4.36 in 4.36 in TIB Series [110.7 mm] [110.7 mm] 3.96 in [100.7 mm] 2.66 in [67.5 mm] 2.66 in [67.5 mm] H Series TIB Series TIB Series...
- Page 14 Warranty Icon Process Controls Ltd warrants to the original purchaser of its products that such products will be free from defects in material and workmanship under normal use and service in accordance with instructions furnished by Icon Process Controls Ltd for a period of one years from the date of sale of such products.
-
Page 15: Instrumentation Equipment
™ ICON Corrosion-Free Instrumentation Equipment PROCESS CONTROLS...
