- Page 1 — 250B Series ® Battery Powered Liquid Level Display Quick Start Manual 250B Series Liquid Level Display LP100 Junction Box Connected to Sensor Quick Connect Cable Grip Sensor Cable Sensor to Display Liquid Tank 24-0344 © Icon Process Controls Ltd.
-
Page 2: Symbol Explanation
If in the case of a unit malfunction there is a risk of a serious threat to the safety of people or property additional, independent systems and solutions to prevent such a threat must be used. ■ Do not attempt to disassemble, repair or modify the unit yourself. The unit has no user serviceable parts. 24-0344 © Icon Process Controls Ltd. -
Page 3: Front Panel Description
Accuracy 0.1% @ 250ºC Operating Temperature -20 - 158ºF | -29 - 70ºC Storage Temperature -20 - 158ºF | -29 - 70ºC Body Material Polycarbonate Mouting Wall Mount Protection Class NEMA 4X | IP67 24-0344 © Icon Process Controls Ltd. -
Page 4: Wiring Diagram
Optional Sensor Latching Switch* Turn Off +ve -ve *Optional ■ Temporary Deadman : Non-Latching Switch ■ Latching Switch : Need to turn off manually when the device is not in use. Dimensions 130.5 112.0 24-0344 © Icon Process Controls Ltd. - Page 5 2 Sec. 20mA Value ▶ Enter 20mA (High Level) Value �� Press to change digit 2 Sec. Press to advance to next digit Menu ▶ Main Menu �� 2 Sec. Main Display ▶ Main Display 24-0344 © Icon Process Controls Ltd.
- Page 6 Icon Process Controls Ltd for a period of one year from the date of sale of such products. Icon Process Controls Ltd obligation under this warranty is solely...
