Truflo — TKS | TK3S Series
®
In-Line Paddle Wheel Flow Meter Sensor

Technical Specifications

General
Operating Range
Pipe Size Range
Linearity
Repeatability
Fluid
Flow Velocity
Low Cut
Operating Pressure
Range Ability
Response Time
Flow Total Meter
Repeatability
Accuracy
Wetted Materials
Sensor Body
O-Rings
Rotor Pin | Bushings
Paddle | Rotor
Electrical
Frequency
Supply Voltage
Supply Current
Max. Temperature/Pressure Rating – Standard and Integral Sensor | Non-Shock
PVC
PP
PVDF
316 SS
Operating Temperature
PVC
PP
PVDF
316 SS
Outputs
NPN Pulse | 1 Amp Relay
Display
LED | Flow Rate
Standards and Approvals
UL | CE | FCC | RoHS Compliant
See Temperature and Pressure Graphs for more information
24-0564 © Icon Process Controls Ltd.
0.3 to 33 ft/s
¼ to 4" **
±0.5% of F.S @ 25°C | 77°F
±0.5% of F.S @ 25°C | 77°F
Water or Chemical Liquid-Viscosity Range: .5-20 centistokes
10 m/s max.
0.3 m/s min.
150 Psi (10 Bar) @ Ambient Temp |Non-Shock
10 : 1
Real Time
Range = 0~999999 ; Unit = Gallon or Liter or Ton (KL) Selectable
Range = 0.0~999.9 ; Unit = GPM or LPM or CMH Selectable
± 0.5% of F.S. @ 25°C
PVC (Dark) | PP (Pigmented)
FKM | EPDM* | FFKM*
Zirconium Ceramic | ZrO2
ETFE Tefzel
®
49 Hz per m/s nominal
9 to 30 VDC ±10% regulated
<1.5 mA @ 3.3 to 6 VDC
180 Psi @ 68°F | 40 Psi @ 140°F
180 Psi @ 68°F | 40 Psi @ 190°F
200 Psi @ 68°F | 40 Psi @ 240°F
200 Psi @ 180°F | 40 Psi @ 300°F
32°F to 140°F
-4°F to 190°F
-40°F to 240°F
-40°F to 300°F
0.1 to 10 m/s
DN08 to DN100
| PVDF (Natural) | 316 SS
15 Hz per ft/s nominal
<20 mA @ 6 to 24 VDC
12.5 Bar @ 20°C
12.5 Bar @ 20°C
14 Bar @ 20°C
14 Bar @ 82°C
0°C to 60°C
-20°C to 88°C
-40°C to 115°C
-40°C to 148°C
| 2.7 Bar @ 60°C
| 2.7 Bar @ 88°C
| 2.7 Bar @ 115°C
| 2.7 Bar @ 148°C
*Optional
** ¼" - ⅜" SS Only
