Truflo — TKS | TK3S Series
®
In-Line Paddle Wheel Flow Meter Sensor
1.77
Dimensions
C
C
Procedure to Rotate Display
1
Flow Meter & Transmitter
Using an allen key loosen the 2 screws
located on either side of the display.
4
Rotate Display 90°.
24-0564 © Icon Process Controls Ltd.
1.77
L
2.2
C
2
OP2 FTM OP1 GPM
Pull the Screws | Do Not Remove!
5
Pipe Size
½" DN (15)
¾" DN (20)
1" DN (25)
1½" DN (40)
2" DN (50)
D
Flow Meter & Transmitter
OP2 FTM OP1 GPM
Lower Display.
Pipe Size L (inch) d (inch) L (inch) D (inch) d (inch)
½" DN (15) 5.48 0.84 5.48 0.84 1.07
¾" DN (20) 6.12 1.05 6.12 1.05 1.36
1" DN (25) 6.76 6.76 1.32 1.68 1.32
1½" DN (40) 7.66 7.66 1.91 2.33 1.91
2" DN (50) 8.40 2.38 8.40 2.86 2.38
1.8
C
3
OP2 FTM OP1 GPM
Lift the Display.
6
Tighten Allen Screws | Snug Tight
Do Not Over-Tighten!
D (inch) C (inch) C (inch) H (inch)
2.73
1.07 1.61 1.61
2.08 1.36 2.08 2.96
2.36 1.68 3.08 2.36
3.26 2.33 3.87 3.26
2.86 4.33 4.72 4.33
