Truflo — TKS | TK3S Series
®
In-Line Paddle Wheel Flow Meter Sensor

Product Description

The TK Series in-line plastic paddle wheel flow meter has been
engineered to provide long-term accurate flow measurement in
tough industrial applications.
The paddle wheel assembly consists of a engineered Tefzel
paddle and micro-polished zirconium ceramic rotor pin
and bushings. High performance Tefzel
materials have been selected due to their excellent
chemical and wear resistant properties.
New ShearPro
®
Contoured Flow Profile
?
Reduced Turbulence = Increased Longevity
?
78% Less Drag than Old Flat Paddle Design*
?
*Ref: NASA "Shape Effects on Drag"
Tefzel Paddle Wheel
®
Superior Chemical And Wear Resistance vs PVDF
?
Zirconium Ceramic Rotor | Bushings
Up to 15x the Wear Resistance vs Regular Ceramic
?
Integral Rotor Bushings Reduce Wear
?
and Fatigue Stress
ShearPro Through-Pin Design
®
Eliminates Finger Spread
?
No Lost Paddles
?
Increased Temp. Rating
?
360° Housing Protects Rotor
?
Finger Spread = LOST
Unprotected Rotor
vs. Competitor 'A'
24-0564 © Icon Process Controls Ltd.
and Zirconium
®
Design
TKS
®
M12 Quick
Connection
TK3S
TKS
Thermal Plastic
True Union Design
Rotates 360º
316 Stainless
Steel
vs. Flat Paddle
High Impact
Enclosure
Bright LED
Display
(Flow)
Flanged
Connection
Sanitary Connection
TK3S
316 SS
