Fault codes and fault LEDs
Fault code Fault LEDs
0-14-0
ON
ON
0-14-1
ON
Correction action for 0-14-0 faults
1. Set the torch-lock switch to the yellow lock (X) position and then back to the green "ready to fire"
position.
2. Do a quick restart.
3. Install the Hypertherm cartridge again.
Correction action for 0-14-1 faults
1. When this fault occurs, you can continue to cut or gouge, but you must set the output current (A)
and the operating mode manually.
2. Lightly blow air into the Hypertherm cartridge to remove all dust or other contamination.
Powermax45 SYNC® Service Manual
Torch LED Description
This fault shows when you install a Hypertherm
cartridge, and it cannot send data to the plasma
power supply. This fault code stops the system
from operating.
Electrical noise can cause a bad data connec-
tion. For example, high frequency electrical noise
Flashes
from TIG welders can cause interference. Keep
yellow
electrical noise in the work area as low as possi-
ble.
To prevent possible damage to the workpiece
and Hypertherm cartridge, the system automati-
cally:
• Sets the output current to 45 A.
• Sets the operating mode to Cut mode.
• Sets the output gas pressure to cut pressure.
If necessary, you can manually change these set-
tings to cut without a data connection.
This fault shows when a Hypertherm cartridge
cannot send data to the plasma power supply for
some reason. This fault code does not stop the
system from operating. This error code occurs
most likely due to poor Hypertherm cartridge
installation.
811480
Troubleshooting for fault codes
Stops the system
from operating?
Yes
No
