Troubleshooting for fault codes
Fault codes and fault LEDs
Fault code Fault LEDs
0-12-1
0-12-2
ON
0-12-3
Corrective action for 0-12-0, 0-12-1, and 0-12-2 faults
1. For optimum system performance, make sure that the inlet gas pressure stays between 7.6 bar – 8.3
bar (110 psi – 120 psi) while gas is flowing.
Never use more than the maximum gas pressure of 9.3 bar (135 psi).
2. Which fault code do you see?
0-12-1 Increase the inlet gas pressure from the gas supply source.
0-12-2 Decrease the inlet gas pressure from the gas supply source.
0-12-3 Adjust the inlet gas pressure from the gas supply source as necessary.
3. Make sure that the gas lines do not have kinks, blockages, or other damage.
4. Do a gas test to find if the plasma power supply's actual output gas pressure is lower than the set
pressure by more than an acceptable quantity.
Refer to Do a gas test on page
5. If the fault continues, examine the gas system and the solenoid valve by doing the troubleshooting
steps in Troubleshooting for low gas pressure faults on page
Troubleshooting for Hypertherm cartridge installation faults
(0-14-n)
Symptom
An 0-14-n fault identifies a condition where the Hypertherm cartridge is not functioning or recognized
properly.
90
Torch LED Description
CNC The output gas pressure is too low.
use only
The output gas pressure is too high.
The output gas pressure is not stable.
27.
811480
Stops the system
59.
Service Manual
from operating?
No
