1. OVERVIEW
NCV-20NDN Series is a converter which operates as the slave unit (group 2 only server) of the open field
network "DeviceNet".
NCV-20NDN Series can be combined with a multi-type (MRE) or linear-type (VLS) of ABSOCODER to convert
the detected absolute position data to binary code for output. The master unit can read the data by accessing IN
data.
This manual explains how to use the NCV-20NDN.
For more details of the master unit, refer to your master unit manual.
For more details of "DeviceNet", refer to the DeviceNet Specification.
If the configuration tool is needed the NCV-20NDN definition file (EDS file), contact your NSD representative.
● Converter model code
NCV-20N DN [ ] [ ]
Converter
series name
Compatible with
"DeviceNet"
Applicable sensor
Multi-turn type ABSOCODER
MP: MRE-32SP062, MRE-G[ ]SP062
Linear type ABSOCODER sensor
LW: VLS-[ ]PW
LY: VLS-[ ]PY
