3. SPECIFICATIONS
3-1. Converter Specifications
(1) General Specification
Items
Power supply voltage
Power consumption
Insulation resistance
Withstand voltage
Vibration resistance
Ambient operating temperature
Ambient operating humidity
Ambient operating environment
Ambient storage temperature
Grounding
Construction
Outside dimension (mm)
Mass
(2) Performance Specification
Items
Converter model
Applicable sensor
Total number of divisions
Position detection format
Number of detection axes
Position data sampling time
Monitor LED
Operation function on the
panel
Applicable standard
±
24VDCV 10% (including ripple)
10W or less
20 M-Ohms or more between external DC power terminals and ground
(by 500 VDC insulation resistance tester)
500 VAC, 60Hz for 1 minute between external DC power terminal and
ground
20m/s 10 to 500Hz, 10cycles of 5 minutes in 3 directions,
2
conforms to JIS C 0040 standard
0 to +55°C (No freezing)
20 to 90 %RH (No condensation)
Free from corrosive gases and excessive dust
-10 to +70°C
Must be securely grounded (ground resistance of 100 ohm or less)
Book-shelf type within enclosure, DIN rail mountable
39(W) x 155(H) x 93(D) Refer to dimensions for details.
Approx. 0.4kg
NCV-20NDNMP
MRE-32SP062
MRE-G[ ]SP062
([ ]: 64/128/160/256/320)
131072(2 )
17
Position data output status
Converter status
Network status
Sensor disconnected error
Sensor data error
Memory error
Low power error
Zero point setting press button
Error clear press button
Node address setting switch
Baud rate setting switch
Specifications
Specifications
NCV-20NDNLW
VLS-256PWB
VLS-512PWB
VLS-1024PW
65536(2 )
16
Absolute
1
1ms
: D0-D23
: MS (Module Status)
: NS (Network Status)
: SE
: DE
: ME
: PF
: ZPS
: CLR
: NA
: DR
CE Marking (EMC directive)
6
NCV-20NDNLY
VLS-512PYB
VLS-1024PYB
VLS-2048PY
131072(2 )
17
