NSD ABSOCODER NCV-20NDNMP Specifications & Instruction Manual page 40

9-2-2. Bit configuration of the setting status
The bit configuration of the Attribute ID41 (0x29) setting status for the Position Sensor object is indicated
in this section.
Bit
Position data increase
0
1-7
9-2-3. Bit configuration of the error information
The bit configurations of the attribute ID44 (0x2C) error information and the attribute ID45 (0x2D) error
detection item for the Position Sensor object are indicated in this section.
Bit
0 Sensor data error (DE)
Sensor disconnected
1
error (SE)
2-11
12 Low voltage error (PF)
-5V power supply
13
error (N5PF)
14 Memory error (ME)
15
Name
0: CW
direction 1: CCW
Fixed at 0
－
Name Description of attribute ID44
0: No error
1: Error is detected
0: No error
1: Error is detected
Fixed at 0
－
0: No error
1: Error is detected
0: No error
1: Error is detected
0: No error
1: Error is detected
Fixed at 0
－
Description
34
Note
Description of attribute ID45
Fixed at 1 (support)
Fixed at 1 (support)
Fixed at 0
Fixed at 1 (support)
Fixed at 1 (support)
Fixed at 1 (support)
Fixed at 0
