FUNCTION INSTRUCTION &
INSTRUCTION FOR USE
① LCD screen：
Display the current brightness, control mode, light effect mode, light parameters,
scene number, and channel value of the light.
Channel number
Scene number
(lights up when the light is set to
scene mode)
Brightness
Current Adjustable Parameters
② Mode types and functions：
Press the mode button to switch between the control modes, which are: Rotate
mode, Master mode, Slave mode, APP mode and DMX mode.
Rotate mode: The brightness and color temperature can be adjusted through the
compound knob.
Master mode: The brightness, color temperature and channel can be adjusted
through the composite knob and other light that are slaved to the master channel
channel can be controlled synchronously.
Slave mode: The channel number can be adjusted by the compound knob. When
the channels number of the slave and the master are the same, they can be
synchronously controlled by the master.
APP mode: The channel number can be adjusted through the compound knob, and
the light can be adjusted through the mobile APP.
DMX mode: Connect to the DMX console and adjust the settings through the DMX
console.
③ Adjust brightness (BRG): Range 0%~100%
Rotate mode or master mode: Switch to brightness adjustment by pressing the
composite knob, and turn the composite knob to adjust the brightness.
APP mode: Connect to the APP and adjust the brightness through the APP.
In DMX mode, adjust the brightness through the DMX console.
10
Battery power
Control mode
(Only display the current
control mode)
Correlated Color Temperature /
Time parameter
(Only display current adjustable
parameters.)
