DESCRIPTION OF
PRODUCT CONTROL KEYS
6
DC IN
1
Power input.
2
ON/OFF Switch.
3
LCD display screen: display the current mode and parameters settings of the light.
4
Compound knob: long press for 2 seconds to switch the light effect mode
(CCT/SCENE), short press to switch to the parameter that needs to be adjusted,
rotate the knob to adjust the light effect's parameter.
5
Mode button: Switch between different control mode.The modes include:
rotate, slave, master, APP.
6
DMX interface: DMX console input and output.
3
OFF
1
ON
2
9
MODE
5
BRG
CCT
4
